  • Page 1 3-226-702-31 (1) FM/MW/LW Cassette Car Stereo Installation/Connections Instalace/Zapojení Instalacja/Podłączenia Kurma/Bağlantılar Установка/Подсоединение XR-CA400 XR-CA410 Sony Corporation © 2001 Printed in Thailand...
  • Page 2 × 2 × 2 Equipment used in illustrations (not supplied) Vybavení použité pro ilustrace (není součástí příslušenství) Wyposażenie wykorzystane w celach ilustracyjnych (nie załączone) Örneklerde kullanılan alet (beraberinde değil) Аппаратура, фигурирующая в иллюстрациях (не прилагается) Front speaker Power amplifier Přední reproduktor Zesilovač...
  • Page 3 AUDIO OUT BUS AUDIO IN BUS AUDIO IN BUS CONTROL IN BUS CONTROL IN BUS AUDIO IN Source selector* Přepinač zdroje* Selektor źródła* Kaynak selektörü* Селектор источника* BUS CONTROL IN * not supplied není součástí příslušenství nie załączone beraberinde değil не...
  • Page 4 (OFF) (RELEASE) 1 8 2 Bend these claws outward for a tight fit, if necessary. Je-li to nezbytné, ohněte tyto jazýčky směrem ven. 5 3 m Jeżeli jest to konieczne, należy odgiąć zaczepy mocujące na zewnątrz. Gerektiği takdirde bu tırnakları dışarı...
  • Page 5 1 8 2 5 3 m...
  • Page 6 Bend these claws outward for a tight fit, if necessary. Je-li to nezbytné, ohněte tyto jazýčky směrem ven. Jeżeli jest to konieczne, należy odgiąć zaczepy mocujące na zewnątrz. Gerektiği takdirde bu tırnakları dışarı doğru eğebilirsiniz. При необходимости отогните эти зажимные зубчики для обеспечения...
  • Page 8 Dashboard Fire wall Přístrojová deska Protipožární deska Deska rozdzielcza Ścianka przeciwpożarowa Konsol Güvenlik Duvarı Приборная доска Огнеупорная перегородка...
  • Page 9: Parts List

    Parts list (1) The numbers in the list are keyed to those in the instructions. Caution Handle the bracket 1 carefully to avoid injuring your fingers. Cautions • This unit is designed for negative earth 12 V DC operation only. •...
  • Page 10: Connection Example

    Connection example (2) Notes (2-A ) • Be sure to connect the earth cord before connecting the amplifier. • If you connect an optional power amplifier and do not use the built-in amplifier, the beep sound will be deactivated. Tip (2-B- For connecting two or more changers, the source selector XA-C30 (optional) is necessary.
  • Page 11: Mounting Example

    Precautions • Choose the installation location carefully so that the unit will not interfere with normal driving operations. • Avoid installing the unit in areas subject to dust, dirt, excessive vibration, or high temperature, such as in direct sunlight or near heater ducts. •...

This manual is also suitable for:

Xr-ca410
