EL2316D Two Door Controller
User Guide
EL2315D & EL2316D
USER GUIDE
(Revision 1.1.21)
ELID SDN BHD
Revision 1.1.21
0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EL2316D and is the answer not in the manual?

Questions and answers

Related Manuals for Elid EL2316D

Summary of Contents for Elid EL2316D

  • Page 1 EL2316D Two Door Controller User Guide EL2315D & EL2316D USER GUIDE (Revision 1.1.21) ELID SDN BHD Revision 1.1.21...
  • Page 2 EL2315D & EL2316D Controller User Guide DOOR ACCESS CONTOLLER USER GUIDE SYSTEM INITIALIZATION TO COLD START TO PROGRAM THE MASTER CARD TO PROGRAM THE ENGINEERING CARD SETTING CARD TYPE SETTING DISPLAY TYPE SETTING EL2000 MODE SETTING CONTINUOUS SWIPING SETTING CARD SIZE SETTING CLEAR SECURITY 1.10...
  • Page 3 EL2315D & EL2316D Controller User Guide TEST MENU SAVE PARAMETER CLEAR MEMORY USER MENU TEST MENU CARD MENU TRANSACTION MENU DOOR MENU SENSOR MENU OUTPUT MENU PIN ENTRY MENU CLEAR MEMORY Revision 1.1.21...
  • Page 4 EL2315D & EL2316D Controller User Guide DOOR ACCESS CONTROLLER Programming Keypad Layout Revision 1.1.21...

  • Page 5: System Initialization

    EL2315D & EL2316D Controller User Guide CHAPTER 1 1. SYSTEM INITIALIZATION TO COLD START Hold down keys "A” on the keypad and simultaneously switch off and then switch back on the power supply. (Alternatively, hold down keys "A” on the keypad and press the reset switch while power is on.)
  • Page 6 EL2315D & EL2316D Controller User Guide EL2k Swip TO PROGRAM THE MASTER CARD Press <A> key, in order to set the master card number. EL2316D SET-UP Mast card 000000 You should key in 6-digit master card number followed by the <#> key.
  • Page 7 EL2315D & EL2316D Controller User Guide EL2316D SET-UP Eng card 000000 You should key in 6-digit Engineering card number followed by the <#> key. SETTING CARD TYPE Press <C> key to choose the type of reader and card format you wish to use.
  • Page 8 EL2315D & EL2316D Controller User Guide Code Details WIEG Wiegand Reader, with 26-bit Wiegand format PROX Proximity Reader, with ELID format EPRX Diester Reader, with 48 bit Diester format FWIE Free Wiegand Reader, with 32bit format MatrixPIN Keypad Reader only Limits of bit settings for Card Type 5 (Wiegand 34+) The Wiegand 34+ card type allows for the integration of different reader formats into a unified card size.
  • Page 9 EL2315D & EL2316D Controller User Guide Card Size Reader Combination Mifare ER928 + ER938 ER928 + C17T ER928 + ER938 + C17T SETTING DISPLAY TYPE Press <D> key to select “DISPLAY TYPE” command. EL2316D SET-UP Disp Type ER5S Revision 1.1.21...
  • Page 10 EL2315D & EL2316D Controller User Guide SETTING EL2000 MODE Press <#> key from main screen and on the second screen of main menu press <A> to select “EL2000 MODE” command. EL2000 Alrm Outp Emulate YES  6 outputs will emulate EL2000, being used for duress alarm, door open alarm, door shunt, sensor alarm and sensor armed.
  • Page 11 EL2315D & EL2316D Controller User Guide Card Swiping Continuous YES  User are allowed to swipe even when the door is open. NO  The reading is disable until the door is closed. SETTING CARD SIZE Press <C> to select “CARD SIZE” command. This command is for setting the data capture window of a Free Format.
  • Page 12 EL2315D & EL2316D Controller User Guide Limits of bit settings (Free Wiegand) Limits Symbol No. of Bits Max no. of bits to make up a card number 40 (000000~999999) Max bits to be taken for reading a card number Max offset bits to read a card number SETTING CLEAR SECURITY Press <D>...

  • Page 13: Before Operation

    EL2315D & EL2316D Controller User Guide NO The controller in Secure Mode. After finishing the above set-up, you should press "*" key from the main screen to exit. The date/time should appear on the LCD and the red light on the reader should begin to flash.

  • Page 14: Engineering Menu

    EL2315D & EL2316D Controller User Guide CHAPTER 2 2. ENGINEERING MENU Note: To access the programming menu, Present the Master Card to Readers in Door 1, and key in the PIN 1. (Do not present the Master card to door 2. Door 2 readers will not accept the master card).
  • Page 15 EL2315D & EL2316D Controller User Guide TEST MENU SENSOR MENU  Test Keypad  Sensor Type  Test Reader  Operation Mode  Test Input  Delay Time  Test Output  Alarm Duration  Test Communication  Test 7-Segment OUTPUT MENU ...
  • Page 16 EL2315D & EL2316D Controller User Guide TO ENTER ENGINEERING MENU There are two methods to enter into programming mode: Present the Master Card to Readers in Door 1, and key in the PIN 1. (Do not present the Master card to door 2. Door 2 readers will not accept the master card).
  • Page 17 EL2315D & EL2316D Controller User Guide  The default release time is 005 seconds.  User can change from 001 to 200. SET L.R. TIME Dr1 005 Dr2 005 2.2.2 SHUNT ACTIVATION TIME (Shun T.)  Each time the door is validly open - as when a valid card is swiped, the Door Shunt Output is activated.
  • Page 18 EL2315D & EL2316D Controller User Guide 2.2.3 DOOR SENSOR (Dr Ssor)  To select the type of Door-Contact user wish to use, either Door-Open-Contact- Open (select: OPEN) or Door-Open-Contact-Closed (select: CLOSE). Set Door Param Door Ssor OPEN 2.2.4 PUSH BUTTON (Push exit) ...
  • Page 19 EL2315D & EL2316D Controller User Guide 2.2.5 PIN SELECT (PIN SEL)  User can choose to use PIN1 or PIN2.  PIN1: User can select their own PIN number for each card. PIN2: Pre-defined PIN. Set Door Param PIN Compare PIN 2 2.2.6 PIN ENTRY (PIN ENT)
  • Page 20 EL2315D & EL2316D Controller User Guide 2.2.7 VALID BUZZER (VALID BUZ)  This command is to allow you to enable or disable the buzzer sound for every valid card entry. Set Door Param Entry BUZ DOOR SENSOR DEBOUNCE (Dr Ssor) 2.2.8...
  • Page 21 EL2315D & EL2316D Controller User Guide 2.3 CARD MENU 2.3.1 DATABASE MODE (DB Mode)  This command allows you to choose whether the controller should store name of each card or not.  If name is to be stored, user can have 12 characters (including space) per name.
  • Page 22 EL2315D & EL2316D Controller User Guide Set DBASE Para Tran DB Size NORM 2.3.3 CARD SIZE (Crd Size)  Refer 1.8 Setting Card size on page 10. 2.3.4 DUAL CARD (Dual Crd)  In dual card mode, which is a high security mode, the controller will require 2 valid cards to be swiped before the request is granted.
  • Page 23 EL2315D & EL2316D Controller User Guide Auto Lock Rel On Valid Ent 2.3.6 SPECIAL CARD MODE (Spcl Crd)  CTYP: Defined by Card Type. Whether the card is recognize as special card or normal user card depends on how the card is encoded.
  • Page 24 EL2315D & EL2316D Controller User Guide 2.4 SENSOR MENU SENSOR TYPE (Ssr Typ) 2.4.1 Ssr Oprn Dly Alm Door  Enter the no of door for the sensor. Set Sensor Param Ssor Type  Choose the signal comes from a device either Normally Closed Contact (NC) or Normally Open Contact (NO).
  • Page 25 EL2315D & EL2316D Controller User Guide OPERATION MODE (Oprn Mod) 2.4.2 Ssr Oprn Dly Alm Door  Enter the no of door for the sensor. Set Sensor Param #1 Ssor Mod ALRM  Status Input (such as MOTOR ON/OFF) can be in either state both of that are normal in operation.
  • Page 26 EL2315D & EL2316D Controller User Guide Inhibit input. When programmed in the Inhibit mode, each time the sensor input is activated, the Reader will not open the door even when a valid card is swiped. An example is shown as below where 2 doors, controlled by 2 EL2315D are interlocked.
  • Page 27 EL2315D & EL2316D Controller User Guide DELAY TIME (Dly Time) 2.4.3  Delay Time is only applicable for alarm point and irrelevant to status point  To set the desired Delay Time, key in the value (in 2 digits) which may be any form 00-99 seconds.

  • Page 28: Output Menu

    EL2315D & EL2316D Controller User Guide Alarm Duration 2.5 OUTPUT MENU OUTPUT TYPE (Outp Type) 2.5.1  GENERAL PURPOSE MODE (GP): the output can be activated manually by means of a special card or from a PC or by timer.
  • Page 29 EL2315D & EL2316D Controller User Guide If you have selected EVENT MODE, there are 4 modes available; SHORT (SHRT): Each event, defined by the command “OUTPUT EVENT” will cause the output to turn on for duration of 1 second TOGGLE (TOG): Each occurrence of an event will cause the output to toggle ON.OFF.ON.OFF etc.
  • Page 30 EL2315D & EL2316D Controller User Guide CODE MEANING OF CODE CODE MEANING OF CODE Valid Entry (IN) Output On Invalid Card Output Off Duress Alarm Exclude Sensor Invalid PIN Include Sensor Door Open Alarm Status On (Sensor #1) Pulse Door Open...

  • Page 31: Communication Menu

    EL2315D & EL2316D Controller User Guide  NOTE: if you have chosen any of the points to be “GP” instead of “EVENT”, then this command will have no effect on those points. 2.5.1 OUTPUT DURATION COMMAND (Out Dur)  This setting is to set the duration for which the output point is to stay activated when it is set to the “PULSE”...
  • Page 32 EL2315D & EL2316D Controller User Guide Set Comm Para Baud Rate 9600 2.6.2 UNIT NUMBER (Add No)  If the configuration is 1-door 2-reader, unit number can be set from 1 to 16.  If the configuration is 2-door 2 reader, unit number setting can be odd number only (01, 03, 05, 07, 09, 11, 13, 15).
  • Page 33 EL2315D & EL2316D Controller User Guide 2.7 TEST MENU 2.7.1 TEST KEYPAD (Test Keyp)  This is for testing the matrix keypad located on the controller, and not for EK9S reader keypad.  As any key is pressed, its value will be shown on the LCD display.
  • Page 34 EL2315D & EL2316D Controller User Guide 2.7.3 TEST INPUT (Test IN)  The display indicates the status of the Door Switch (DS), Push Button (PB), Sensor #1 (S1), and Sensor #2 (S2)  0=Contact Open, and 1= Contact Closed. DS 1 PB 0 S1 0 S2 0 2.7.4 TEST OUTPUT (Test OUT)
  • Page 35 EL2315D & EL2316D Controller User Guide > Output Test < 1 GP Output #1  Similarly, with other keys as listed below: - General Purpose Output #3 General Purpose Output #4 General Purpose Output #5 General Purpose Output #6 Door Lock –D1 Red LED –D1...
  • Page 36 EL2315D & EL2316D Controller User Guide 2.7.5 TEST COMMUNICATION (Test Com)  Echo Test: Used PC linked via EL70 to controller. Run a communication program such as HyperTerminal on the PC and set it to behave as a terminal.  Printer Test: the controller will send a stream of characters out of the serial port.
  • Page 37 EL2315D & EL2316D Controller User Guide 2.7.7 TEST MEMORY (Test RAM)  Press the <#> Key to commence testing >>> RAM TEST <<< Confirm ( * / # )  If all the pages of the Random Access Memory (RAM) are good. The display screen will show “GOOD RAM!”...

  • Page 38: Save Parameter

    EL2315D & EL2316D Controller User Guide 2.8 SAVE PARAMETER  This command allows you to save all the parameters that you have programmed in the secondary storage device, which will be retained even when power supply is switched off.  Press the <#> Key to confirm.
  • Page 39 EL2315D & EL2316D Controller User Guide CHAPTER 3 3. USER MENU Note: To access the programming menu, Present the Master Card to Readers in Door 1, and key in the PIN 1. (Do not present the Master card to door 2. Door 2 readers will not accept the master card).
  • Page 40 EL2315D & EL2316D Controller User Guide TRANSACTION MENU OUTPUT MENU  VIEW TRANSACTION  ON OUTPUT   PRINT TRANSACTION OFF OUTPUT   SECOND OUTPUT TIME ZONE  CLEAR TRANSACTION  LOG TRANSACTION COMMUNICATION MODE SENSOR MENU PIN ENTRY ...
  • Page 41 EL2315D & 2316D Controller User Guide 3.1 TIME MENU 3.1.1 SET DATE (Set Date) >>> SET DATE <<< 09 – 09 – 89     Day Month Year Day of the Week  The cursor will be blinking at the following filed. You may key in the new value. ...
  • Page 42 EL2315D & 2316D Controller User Guide 3.1.2 SET TIME (Set Tim) >>> SET TIME <<< 00 : 02 : 45    Hour Minute Second  The cursor will be blinking at the following filed. You may key in the new value. 3.1.3 SET HOLIDAY (Set HOL) >...
  • Page 43 EL2315D & 2316D Controller User Guide (From 1 to 20)  A total of 20 holidays may be preprogrammed, using the Set Hol. 3.1.4 SET TIMER (Set Tmr)  A total of 24 timers may be programmed for each door, each timer has two sets of start-stop times.
  • Page 44 EL2315D & 2316D Controller User Guide 3.1.5 ADJUST CLOCK (Adj Clk)  This command allows the user to calibrate the accuracy of EL2315D calendar clock.  It allows the user to add or subtract up to 60 seconds daily or weekly. Clock Adjust Method Clock Adjust...
  • Page 45 EL2315D & 2316D Controller User Guide 3.1.6 DAY LIGHT SAVING (Day light)  This command allow controller automatically adjust time one hour forward according to the day light saving start date and adjusted one hour backward according to the day light saving end date. ...
  • Page 46 EL2315D & 2316D Controller User Guide Install Cards Time Zon #01  Then the Time zone value is shown. You should choose which access time zone you want. Install Cards 000000 To 000000  Key in the starting number and ending number (provided number are sequential) of the card.
  • Page 47 EL2315D & 2316D Controller User Guide  You can select either to install cards in Door 1 or Door 2. Delete Cards 012345  Key in the starting number and ending number (provided number are sequential). 3.2.3 VIEW DATABASE (View DB) View User Cards Door #01 ...
  • Page 48 EL2315D & 2316D Controller User Guide View User Cards Page No : 01 There are 16 memory pages that you can select from for each door. 3.2.4 PRINT CARD DATABASE (Prt DB)  This command works in the same way as View Card Data Base, except that instead of showing the cards on the LCD screen, the cards are sent to the communication port.
  • Page 49 EL2315D & 2316D Controller User Guide Set Cust Code 0000 3.2.6 PROGRAMMABLE PIN (Prg PIN)  If PROG PIN set PIN 2, you are not allowed to change the PIN value the display will show “Not Allowed”  If PROG PIN set PIN 1 and you have not installed any card, the display will show “No Record Found”.
  • Page 50 EL2315D & 2316D Controller User Guide  If you wish to change the PIN number of a specified card, you need to search for the card in the correct page and then modify its value.  Default setting of the PIN value is 0000. Program PIN 0001 123456...

  • Page 51: Transaction Menu

    EL2315D & 2316D Controller User Guide  CLR D1DB – will clear database in door #1  CLR D2DB – will clear database in door #2 3.3 TRANSACTION MENU 3.3.1 VIEW TRANSACTION (View Trn) View Log 09/09 12:24 012345  You can select either to view data in Door 1 or Door 2. ...
  • Page 52 EL2315D & 2316D Controller User Guide  <F4> Print Alarm Individual – Print all abnormal transaction of a specific holder. 3.3.3 SECOND FIELD FOR TRANSACTION (Se- cond) Send Seconds? Second field OFF  OFF – controller will not send the second field to the software. ...
  • Page 53 EL2315D & 2316D Controller User Guide 3.3.5 LOG TRANSACTIONS (Log Trns)  This command is allows you to choose what events you wish to log in the transaction buffer.  The default setting is to record all events. If you desire to record only selected activities, you should change the setting to “NO”.
  • Page 54 EL2315D & 2316D Controller User Guide  PIN MODE (ON/OFF) – to set controller into the more secure mode of requiring PIN in addition to card. Anti 3.4.2 ANTI-PASSBACK COMMAND  OFF – Anti-Passback is not implemented.  TMR (Timer) – Anti-Passback by Timer. ...
  • Page 55 EL2315D & 2316D Controller User Guide  A card that has been used to gain access cannot be reused until a certain time elapsed.  This time delay is set using the Anti-Passback Setting command.  You may key in any value between 000 and 120 minutes. 3.4.4 AUTOMATIC LOCK RELEASE TIME ZONE COMMAND (ALR TZ) Set A.L.R.
  • Page 56 EL2315D & 2316D Controller User Guide Set PIN TZ 01 SUN:00 MON:01 3.4.6 KEYPAD LOCK OUT COMMAND  Determines the number of times that a person is allowed to make mistake in keying PIN number repeatedly before the card is taken out of service. 3.5 SENSOR MENU ...
  • Page 57 EL2315D & 2316D Controller User Guide 3.5.1 MANUAL OPERATION OF SENSING INPUTS  Exclude Sensor Command: You should enter the sensor number as before. Exclude Sensor Sensor # 1  Arm Sensor Command: Press <#> key to confirm.  Disarm Sensor Command: Press <#> key to confirm. 3.5.2 AUTOMATIC OPERATION OF SENSING INPUTS ...
  • Page 58 EL2315D & 2316D Controller User Guide Set Sensor TZ SUN:00 MON: 00      Sensor # Day Timer Day Timer 3.6 OUTPUT MENU 3.6.1 ON OUTPUT COMMAND  You are expected to key in any number from 1 to 6 as there are 6 output points.
  • Page 59 EL2315D & 2316D Controller User Guide 3.6.2 OFF OUTPUT COMMAND  The point selected will immediately turn off as an output. Off Output Output #1 3.6.3 SET OUTPUT TIME ZONE  The Set Output Time Zone command allows you to program the 6 outputs to be activated automatically according to timer settings.

  • Page 60: Communication Mode

    EL2315D & 2316D Controller User Guide 3.7 COMMUNICATION MODE  ENQUIRY MDOE – it is assumed that you have linked all controllers together via a communication bus to a PC running an Access Management Software like E.WIN, which allows you to remotely program and monitor all access functions. ...

  • Page 61: Clear Memory

    EL2315D & 2316D Controller User Guide Define PIN Code 0000 TZ:01 3.9 CLEAR MEMORY  This command is to clear all memory in User defined settings, and return them to default values. Revision 1.2.21...
