CD PORTABLE SYSTEM
RC-EZ55B
Thank you for purchasing a JVC product.
Before operation, please read the instructions
Warnings, Cautions and Others
CAUTION
To reduce the risk of electrical shocks, fire, etc.:
1. Do not remove screws, covers or cabinet.
2. Do not expose this appliance to rain or moisture.
CAUTION — STANDBY/ON
Disconnect the mains plug to shut the power off
completely (the STANDBY lamp goes off). When installing
the apparatus, ensure that the plug is easily accessible.
The STANDBY/ON
disconnect the mains line.
• When the System is on standby, the STANDBY lamp
lights red.
• When the System is turned on, the STANDBY lamp
goes off.
The power can be remote controlled.
EN
©2007 Victor Company of Japan, Limited
carefully.
INSTRUCTIONS
button!
button in any position does not
LVT1773-001A
[B]

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RC-EZ55B and is the answer not in the manual?

Questions and answers

Summary of Contents for JVC RC-EZ55B

  • Page 1 CD PORTABLE SYSTEM RC-EZ55B Thank you for purchasing a JVC product. Before operation, please read the instructions carefully. INSTRUCTIONS LVT1773-001A Warnings, Cautions and Others CAUTION To reduce the risk of electrical shocks, fire, etc.: 1. Do not remove screws, covers or cabinet.
  • Page 2 CAUTION • Do not block the ventilation openings or holes. (If the ventilation openings or holes are blocked by a newspaper or cloth, etc., the heat may not be able to get out.) • Do not place any naked flame sources, such as lighted candles, on the apparatus.
  • Page 3 Caution: Proper Ventilation To avoid risk of electric shock and fire, and to prevent damage, locate the apparatus as follows: 1 Front: No obstructions and open spacing. 2 Sides/ Top/ Back: No obstructions should be placed in the areas shown by the dimensions below.
  • Page 4 (Business users) If you wish to dispose of this product, please visit our web page www.jvc-europe.com to obtain information about the take-back of the product. [Other Countries outside the European Union] If you wish to dispose of this product, please do so in...
  • Page 5 SAFETY INSTRUCTIONS “SOME DOS AND DON’TS ON THE SAFE USE OF EQUIPMENT” This equipment has been designed and manufactured to meet international safety standards but, like any electrical equipment, care must be taken if you are to obtain the best results and safety is to be assured. Do read the operating instructions before you attempt to use the equipment.
  • Page 6 • A small amount of power is always consumed even while on standby. CAUTION • Only use JVC power cord provided for this unit to avoid malfunction or damage to the unit. • Remove batteries when using the power cord.
  • Page 7: Playable Discs/Files

    CASSETTE TAP ABOUT DISC/FILE/ CASSETTE TAPE Playable discs/files MP3 folders/tracks configuration Playable discs/files This unit plays back MP3 tracks as follows. Discs CDs with one of the marks below on Hierarchy the surface. Level 1 Level 2 Level 3 Level 4 Level 5 Discs CDs with one of the marks below on...
  • Page 8: Notes On Cassette Tapes

    MP3 folders/tracks configuration This unit plays back MP3 tracks as follows. Hierarchy Level 1 Level 2 Level 3 Level 4 Level 5 Folder with its play order MP3 track with its play order Notes on cassette tapes • Type-I tape is recommended for playback on this unit.
  • Page 9: Care And Maintenance

    REFERENCES Care and maintenance To get the best performance from the unit, keep your discs, tapes and mechanism clean. Cleaning the unit • Disconnect the power cord and remove all the batteries before cleaning. • Wipe off stains with a soft cloth. If the unit is heavily stained, wipe it with a cloth soaked in water-diluted neutral detergent and wrung well, then wipe clean with a dry cloth.
  • Page 10 Open the cassette holder and clean the heads, capstan and pinch roller with a cleaning kit (available at an audio store). Do not use thinner or benzine for cleaning. After cleaning, make sure that the cleaning fluid has dried completely before loading a cassette. Head (recording/playback) Pinch roller Erasure head...
  • Page 11: Troubleshooting

    Troubleshooting If you are having a problem with this unit, check this list for a possible solution before calling for service. General Power does not come on. \ No power is supplied. Check the power cord connection or battery power. Playback sound is at a very low level.
  • Page 12 Radio Operations Hard to listen to broadcasts because of noise. \ Direction of the antenna is inappropriate. Adjust the antenna correctly. Disc Operations The disc does not play. \ The disc is placed upside down. Place the disc with the label side facing up. \ The disc or the lens is dirty.
  • Page 13: Specifications

    SPECIFICATIONS CD player CD capacity: Signal-to-noise ratio: 60 dB Dynamic range: 60 dB Tuner FM tuning range: 87.5 MHz – 108.0 MHz AM tuning range: 522 kHz – 1 629 kHz Antennas: Telescopic antenna for FM Ferrite core antenna for AM Cassette deck Frequency response: 100 Hz –...
  • Page 14 BASIC AND COMMON OPERATIONS How to use number buttons You can select a track number or preset number using the number buttons on the remote control. • To select the number 5, press “5. ” • To select the number 15, press “1, ” then “5. ” •...
  • Page 15: Setting The Clock

    Setting the clock There is a time limit in the following steps. If the setting is canceled before you finish, start from step 1 again. While on standby... Show the clock setting display. Main unit Remote control Press and hold Press and hold 0 : 0 0 Set the hour.
  • Page 16: Tape Operations

    TAPE OPERATIONS Playback procedure Select “TAPE” as the source. To stop playback Main unit Remote control • The tape also stops when it reaches its end. Open the cassette holder, then load a cassette. To pause playback ø Tape running direction •...
  • Page 17: Recording On A Tape

    Recording on a tape Prepare the recording source (radio or disc). • For the radio recording: Set the source to TUNER and tune in to a desired station. • For the disc recording: – Set the source to “CD” and load a disc. –...
  • Page 18: Erasing A Tape

    To use the beat-cut function When recording an AM broadcast, beats may occur. In this case, slide the BEAT CUT switch on the rear to select the beat-cut setting, 1 or 2. NOTES • It may be unlawful to record or play back copyrighted material without the consent of the copyright owner.
  • Page 19: Tuner Operations

    TUNER OPERATIONS Basic procedure Improving the FM reception When an FM stereo broadcast is hard to receive Select the band—FM or AM. or noisy, select monaural reception. Main unit Remote control While the STEREO indicator lights on the display Main unit •...
  • Page 20: Presetting Stations

    Presetting stations You can preset 24 FM and 16 AM stations. • There is a time limit in the following steps. If the setting is canceled before you finish, start from step 2 again. Tune in to the station you want to preset. Show the preset number selection display.
  • Page 21: Disc Operations

    DISC OPERATIONS Basic procedure Load a disc. To select a track Main unit Remote control Main unit • You can use the number buttons on the remote control to select a track directly. See “How to use number buttons” in “BASIC AND COMMON Start playback.
  • Page 22: Program Playback

    Program playback Up to 32 tracks can be programmed to play in a desired order. To program the playing order While playback is stopped... Show the program creation display. Main unit Remote control P R : 0 1 For MP3: Select a desired folder. Main unit Remote control Select a desired track.
  • Page 23: Repeat Playback

    To check the program contents Press PROGRAM repeatedly while playback is stopped. The folder number (for MP3) and the track number appear on the display. To edit the program 1 While playback is stopped, press PROGRAM repeatedly to select the program number of the track you want to replace.
  • Page 24: Random Playback

    Random playback Main unit Remote control • The RANDOM indicator lights on the display. To cancel random playback, press the same button again. The RANDOM indicator goes off. Display information While playback is stopped... For audio CD 4 8 : 5 0 Total number of tracks Total playing time For MP3...
