Samsung OM46B Quick Setup Manual

Quick Setup Guide
OM46B OM55B
* The colour and the appearance may differ depending on the product, and the content in the manual is subject to change without
prior notice to improve the performance.
* Download the user manual from the following Samsung Website for further details.
http://www.samsung.com/displaysolutions
Checking the Components
(1) Quick Setup Guide (2) Warranty card (Not available in some locations) (3) Regulatory guide (4) Power cord
(5) Batteries (AAA x 2) (Not available in some locations) (6) Remote Control (7) External ambient light sensor (8) External IR cable
Contact the vendor where you purchased the product if any components are missing.
Components may differ in different locations.
* Use either the back-side magnet or the double-sided tape depending on where you want to attach the external ambient light
sensor. The warranty for adhesiveness of the double-sided tape applies to first-time-use only.
Ports
Air outlet
Air inlet
Connects to MDC using an RS232C adapter.
1
Outputs sound to an audio device via an audio cable.
2
Connects to an external IR cable that receives signals from
3
the remote control.
Used to supply power to the external sensor board and to
4
receive signals from the ambient light sensor.
Connect to a USB memory device.
5
Wired LAN connection port used to connect an external
6
device such as a laptop to connect to the Internet.
Connects to MDC using a LAN cable.
Connects to MDC using a LAN cable.
7
Connects to a source device using a HDMI cable or HDMI-
8
DVI cable.
Connects to a PC using a DP cable.
9
Connects to another product using a HDMI cable.
0
