MARINE DIGITAL MEDIA RECEIVER
RÉCEPTEUR MÉDIA AUDIO MARIN
RECEPTOR DE MEDIOS DIGITALES MARINO
MVH-MS512BS
Important (Serial number)
The serial number is located on the bottom of this unit. Be sure to record this number on the
enclosed warranty card before the unit is installed.
Important (Numéro de série)
Le numéro de série se trouve au bas de cet appareil. Veillez à noter ce numéro sur la carte de
garantie fournie avant d'installer l'appareil.
Importante (Número de serie)
El número de serie se encuentra en la parte inferior de esta unidad. Asegúrese de anotar
este número en la tarjeta de garantía que se adjunta antes de instalar la unidad.
Guide de démarrage rapide
Guía de inicio rápido
Quick start guide
QRD3705-C

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MVH-MS512BS and is the answer not in the manual?

Questions and answers

Related Manuals for Pioneer MVH-MS512BS

Summary of Contents for Pioneer MVH-MS512BS

  • Page 1 MARINE DIGITAL MEDIA RECEIVER RÉCEPTEUR MÉDIA AUDIO MARIN RECEPTOR DE MEDIOS DIGITALES MARINO MVH-MS512BS Quick start guide Guide de démarrage rapide Guía de inicio rápido Important (Serial number) The serial number is located on the bottom of this unit. Be sure to record this number on the enclosed warranty card before the unit is installed.
  • Page 2 (DEMO OFF). Before You Start Thank you for purchasing this PIONEER product To ensure proper use, please read through this guide and the Operation Manual before using this product. It is especially important that you read and observe WARNINGS and CAUTIONS in this guide. Please keep the guide in a safe and accessible place for future reference.
  • Page 3 FEDERAL COMMUNICATIONS COMMISSION SUPPLIER’S DECLARATION OF CONFORMITY Product Name: MARINE DIGITAL MEDIA RECEIVER Model Number: MVH-MS512BS Responsible Party Name: PIONEER ELECTRONICS (USA) INC. SERVICE SUPPORT DIVISION Address: 2050 W. 190TH STREET, SUITE 100 TORRANCE, CA 90504, U.S.A. Phone: 1-800-421-1404 URL: http://www.pioneerelectronics.com The Safety of Your Ears is in Your Hands Get the most out of your equipment by playing it at a safe level—a level that lets the sound come through...
  • Page 4 You may contact Pioneer directly as follows: Do not ship your unit in for repair without contacting Pioneer first. Units sent without a return authorization number will be refused.
  • Page 5 ACC position No ACC position WARNING • Use this unit with a 12-volt battery and negative grounding only. Failure to do so may result in a fire or malfunction. • To prevent a short-circuit, overheating or malfunction, be sure to follow the directions below.

  • Page 6: Power Cord

    Rear output (STD) or middle range output (NW) Front output (STD) or high range output (NW) Antenna input Fuse (10 A) Wired remote input Pioneer marine wired remote control (CD-ME300) can only be connected (sold separately). Subwoofer output SiriusXM Connect Vehicle Tuner (sold separately) Power cord...
  • Page 7 Important In the above case, two 4 Ω subwoofers wired in parallel will represent a 2 Ω load. To power cord input Left Right Front speaker (STD) or high range speaker (NW) Rear speaker (STD) or middle range speaker (NW) White White/black Gray...

  • Page 8: Power Amp (Sold Separately)

    Power amp (sold separately) Perform these connections when using an optional amplifier. System remote control Connect to blue/white cable. Power amp (sold separately) Connect with RCA cables (sold separately) To rear output (STD) or middle range output (NW) Rear speaker (STD) or middle range speaker (NW) To front output (STD) or high range output (NW) Front speaker (STD) or high range speaker (NW) To subwoofer output...
  • Page 9 WARNING • Carefully select a dry mounting location where the unit will not come into contact with water/liquids, which may cause internal damage. • Not SAE J1171 or UL-1500 certified; Installed unit must be isolated from gasoline fuel source in compliance with 33 CFR §183.410 - Ignition protection, and boat manufacturer instructions.
  • Page 10 DIN mount installation Insert the supplied mounting sleeve into the dash panel. Secure the mounting sleeve by using a screwdriver to bend the metal tabs (90°) into place. Dash Panel Mounting sleeve • Make sure that the unit is installed securely in place.

  • Page 11: Installing The Microphone

    Removing the unit (installed with the supplied mounting sleeve) Remove the trim ring. Trim ring Notched tab • Releasing the front panel allows easier access to the trim ring. • When reattaching the trim ring, point the side with the notched tab down. Insert the supplied extraction keys into both sides of the unit until they click into place.
  • Page 12 WARNING It is extremely dangerous to allow the microphone lead to become wound around the steering column or shift lever. Be sure to install the microphone in such a way that it will not obstruct operation. It is recommended to use cable clamps (sold separately) to arrange the lead.

  • Page 13: Basic Operation

    Basic operation MVH-MS512BS M.C. (multi-control) dial USB port SRC (source)/OFF DISP (display) BAND/ Display window Detach button (navigation)/LIST BASS AUX input jack (3.5 mm stereo jack)
  • Page 14 About the main menu You can adjust various settings in the main menu. Press the M.C. dial to display the main menu. Turn the M.C. dial to select one of the categories below, then press to confirm. • FUNCTION settings •...

  • Page 15: Setup Operation

    Setup operation When you turn the ignition switch to ON after installation, the setup menu appears in the display. WARNING Do not use the unit in standard mode when a speaker system for network mode is connected to the unit. Do not use the unit in network mode when a speaker system for standard mode is connected to the unit.

  • Page 16: Tuner Operation

    SPEAKER MODE Switch between two operation modes: the 2-way network mode (NETWORK) and the standard mode [STANDARD], (STANDARD) according to the connections you have [NETWORK] established. After selecting the appropriate mode, turn the M.C. dial to select [YES], then press to confirm. •...
  • Page 17 Press a number button (1/ to 6/ ). Best stations memory (BSM) After selecting the band, press the M.C. dial to display the main menu. Turn the M.C. dial to select [FUNCTION], then press to confirm. Turn the M.C. dial to select [BSM], then press to confirm. To store stations manually While tuned to the station you want to store, press and hold one of the number buttons (1/...

  • Page 18: Bluetooth Connection

    Insert the stereo mini plug into the AUX input jack. Press SRC/OFF to select [AUX IN] as the source. Bluetooth connection Up to two Bluetooth mobile devices can be connected simultaneously. Turn on the Bluetooth function of the device. Select the unit name shown in the device display. Make sure the same 6-digit number appears on this unit and the device.
  • Page 19 To exit voice recognition mode, press BAND/ Making a connection with Pioneer Smart Sync Pioneer Smart Sync is the application that intelligently brings your maps, messages, and music together. WARNING Do not attempt to operate the application while driving. Make sure to stop your boat in a safe location before attempting to use the controls on the application.
  • Page 20 − For devices other than a USB-connected Android device, press SRC/OFF to select any source and press and hold the M.C. dial. − For iPhone, launch Pioneer Smart Sync on the mobile device. Preparing for the SiriusXM Satellite Radio service Press SRC/OFF to select [SIRIUSXM].
