MARINE DIGITAL MEDIA RECEIVER
AUTORADIO NUMÉRIQUE NAUTIQUE
RICEVITORE MULTIMEDIALE DIGITALE PER IL SETTORE MARITTIMO
RECEPTOR DIGITAL DE MEDIOS NAVAL
DIGITALER MARINE-MEDIA RECEIVER
MARITIEME DIGITALE MEDIA-RECEIVER
MVH-MS510BT
Quick start guide
Guide de démarrage rapide
Guida rapida all'uso
Guía de iniciación rápida
Schnellstartanleitung
Snelstartgids
QRD3706-B

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MVH-MS510BT and is the answer not in the manual?

Questions and answers

Related Manuals for Pioneer MVH-MS510BT

Summary of Contents for Pioneer MVH-MS510BT

  • Page 1 MARINE DIGITAL MEDIA RECEIVER AUTORADIO NUMÉRIQUE NAUTIQUE RICEVITORE MULTIMEDIALE DIGITALE PER IL SETTORE MARITTIMO RECEPTOR DIGITAL DE MEDIOS NAVAL DIGITALER MARINE-MEDIA RECEIVER MARITIEME DIGITALE MEDIA-RECEIVER MVH-MS510BT Quick start guide Guide de démarrage rapide Guida rapida all’uso Guía de iniciación rápida Schnellstartanleitung...

  • Page 2: Before You Start

    (DEMO OFF)”. Before You Start Thank you for purchasing this PIONEER product To ensure proper use, please read through this guide before using this product. It is especially important that you read and observe WARNINGS and CAUTIONS in this guide. Please keep the guide in a safe and accessible place for future reference.
  • Page 3 • This product is evaluated in moderate and tropical climate condition under the Audio, video and similar electronic apparatus - Safety requirements, IEC 60065. If you experience problems Should this unit fail to work properly, please contact your dealer or nearest authorized PIONEER Service Station. * Please refer to connections for a connection Connections method.

  • Page 4: Power Cord

    Rear output (STD) or middle range output (NW) Front output (STD) or high range output (NW) Antenna input Fuse (10 A) Wired remote input Pioneer marine wired remote control (CD-ME300) can only be connected (sold separately). Subwoofer output Power cord Perform these connections when not connecting a rear speaker or middle range speaker lead to a subwoofer.
  • Page 5 Perform these connections when using a subwoofer without the optional amplifier. Important In the case of above, two 4 Ω subwoofers wired in parallel will represent a 2 Ω load. To power cord input Left Right Front speaker (STD) or high range speaker (NW) Rear speaker (STD) or middle range speaker (NW) White White/black...

  • Page 6: Power Amp (Sold Separately)

    Orange/white Connect to a boat’s illumination signal. Power amp (sold separately) Perform these connections when using the optional amplifier. System remote control Connect to blue/white cable. Power amp (sold separately) Connect with RCA cables (sold separately) To rear output (STD) or middle range output (NW) Rear speaker (STD) or middle range speaker (NW) To front output (STD) or high range output (NW)
  • Page 7 • Do not use unauthorized parts as this may cause malfunctions. • Consult your dealer if installation requires drilling of holes or other modifications to the boat. • Do not install this unit where: − it may interfere with operation of the boat. −...
  • Page 8 When not using the supplied mounting sleeve Line up the holes on the mounting bracket with the holes on the sides of the unit to attach the bracket. Screw in one screw on each side to hold the unit in place. Tapping screw (5 mm ×...

  • Page 9: Installing The Microphone

    Removing the unit (installed with the supplied mounting sleeve) Remove the trim ring. Trim ring Notched tab • Releasing the front panel allows easier access to the trim ring. • When reattaching the trim ring, point the side with the notched tab down. Insert the supplied extraction keys into both sides of the unit until they click into place.

  • Page 10: Basic Operation

    Slide the microphone base to detach it Install the microphone as follows. from the microphone clip. Microphone Microphone clip Microphone base Double-sided tape Clamp (sold separately) Basic operation MVH-MS510BT M.C. (multi-control) dial USB port SRC (source)/OFF DISP (display) BAND/ Display window (navigation)/LIST Detach button...
  • Page 11 About the main menu You can adjust various settings in the main menu. Press the M.C. dial to display the main menu. Turn the M.C. dial to select one of the categories below, then press to confirm. • FUNCTION settings •...

  • Page 12: Setup Operation

    Setup operation When you turn the ignition switch to ON after installation, the setup menu appears in the display. WARNING Do not use the unit in standard mode when a speaker system for network mode is connected to the unit. Do not use the unit in network mode when a speaker system for standard mode is connected to the unit.

  • Page 13: Tuner Operation

    SPEAKER MODE Switch between two operation modes: the 2-way network mode (NETWORK) and the standard mode [STANDARD], (STANDARD) according to the connections you have [NETWORK] established. After selecting the appropriate mode, turn the M.C. dial to select [YES], then press to confirm. •...
  • Page 14 Best stations memory (BSM) After selecting the band, press the M.C. dial to display the main menu. Turn the M.C. dial to select [FUNCTION], then press to confirm. Turn the M.C. dial to select [BSM], then press to confirm. To store stations manually While receiving the station you want to store, press and hold one of the number buttons (1/ to 6/ ) until it stops flashing.

  • Page 15: Bluetooth Connection

    Bluetooth connection Up to two Bluetooth telephones can be connected simultaneously. Turn on the Bluetooth function of the device. Select the unit name shown in the device display. Make sure the same 6-digit number appears on this unit and the device.
  • Page 16 Making a connection with Pioneer Smart Sync Pioneer Smart Sync is the application that intelligently brings your favorite marine application, messages, and music together in the boat. WARNING Do not attempt to operate the application while driving. Make sure to stop your boat in a safe location before attempting to use the controls on the application.

  • Page 17: Listening To Spotify

    − For devices other than the USB-connected Android device, press SRC/OFF to select any source and press and hold the M.C. dial. − For iPhone, launch Pioneer Smart Sync on the mobile device. Listening to Spotify® (Not available when [USB MTP] is set to [ON] in the SYSTEM settings.) Update the firmware of the Spotify application to the latest version before use.
  • Page 18 Pioneer vakuuttaa, että radiolaitetyyppi [*] on direktiivin Español: 2014/53/EU mukainen. Por la presente, Pioneer declara que el tipo de equipo EU-vaatimustenmukaisuusvakuutuksen täysimittainen radioeléctrico [*] es conforme con la Directiva 2014/53/UE. teksti on saatavilla seuraavassa internetosoitteessa: http:// El texto completo de la declaración UE de conformidad www.pioneer-car.eu/compliance...
  • Page 19 It-test kollu tad-dikjarazzjoni ta’ konformità tal-UE huwa disponibbli f’dan l-indirizz tal-Internet li ġej: http://www. pioneer-car.eu/compliance Slovenčina: Pioneer týmto vyhlasuje, že rádiové zariadenie typu [*] je v súlade so smernicou 2014/53/EÚ. Úplné EÚ vyhlásenie o zhode je k dispozícii na tejto internetovej adrese: http://www.pioneer-car.eu/ compliance Slovenščina:...
