Hakko Electronics FR-811 Instruction Manual

Instruction Manual
Please read this manual before operating the Bottom heater.
1. PACKING LIST
Lamp cover
Bottom
heater
※The bottom heater (sold separately) can be connected to the HAKKO FR-811
with the connecting cable. Settings for the bottom heater are set using the
HAKKO FR-811.
2. SPECIFICATIONS
Power consumption
Effective heated area
Heater area dimensions
Dimensions
Weight (w/o cord)
* This product is protected against electrostatic discharge.
* Specifications and design are subject to change without notice.
3. WARNINGS, CAUTIONS AND NOTES
Warnings, cautions and notes are placed at critical points in this manual to direct
the operator's attention to significant items. They are defined as follows:
WARNING: Failure to comply with a WARNING may result in serious injury or death.
CAUTION : Failure to comply with a CAUTION may result in injury to the operator,
NOTE : A NOTE indicates a procedure or point that is important to the process
being described.
When powered, the preheater unit will become extremely hot, reaching possibly reaching
temperatures above 250℃ (523℉). Be sure of the following to avoid possible burns/fires
resulting from the failure to observe them.
● Do not touch the lamp cover. Also, do not place a metal object around the lamp cover.
● Do not use the product near an object that may readily catch fire.
● Inform all individuals nearby that the "product can be extremely hot and can
pose a hazard."
● Turn off the product and check to be sure it has sufficiently cooled before
replacing a part or storing the product.
● The unit is for a counter or workbench use only.
4. PART NAMES
Zone selector switch
Bottom heater
Thank you for purchasing the Bottom heater.
Keep this manual readily accessible for reference.
100V-500W 110V-610W 120V-730W
220V-1130W 230V-1240W
190(W) × 80(D) mm (7.5 × 3.2 in.)
248(W) × 140(D) mm (9.8 × 5.5 in.)
295(W) × 66(H) × 246(D) mm (11.6 × 2.6 × 9.7 in.)
2.1 kg (4.6 lb.)
or damage to the items involved. Two examples are given below.
Power receptacle
Fuse
Please check to make sure that all items
listed below are included in the package.
WARNING
Power switch
HEATER SELECT
Receptacle
Power cord
Connecting cable
ON
MAIN
OFF
