Page 2: Installation
NF-A20 5V | User Manual Installation If you replace an existing fan, it is usually best to use the screws (or other mounting mechanisms) used for the original fan. Depending on the application, it may also be possible to use the supplied mounting screws or silicone anti-vibration mounts. - Page 3 Then pull the C side through the mounting holes of the case. If the long ends of the mounts are in the way, you can use scissors to cut them after installation. Note that this will then make them difficult to reinstall in the future.
- Page 4 Connection CAUTION: Being a 5V fan, the NF-A20 5V can not be run at 12V and will be damaged when used with typical 12V power sources such as PC mainboard fan headers. The NF-A20 5V features a standard 3-pin fan connector. However, please note that the fan can also be connected to standard 4-pin fan headers.
- Page 5 The black lead of the adaptor has to be matched with the original GND lead and the red adaptor cable with the original +5V lead. Many fan cables use the same colours as the OmniJoin adaptor, but please note that there is no guarantee for this, so make sure to correctly identify the GND and +5V leads of the original fan.
- Page 6 Wiederholen Sie Schritt 2 und 3 für die +5V Leitung. After you’ve fixed the original fan’s cable to the OmniJoin adaptor using the cable connectors, simply connect the NF-A20 5V to the adaptor in order to use it in your device.
-
Page 7: Cleaning And Maintenance
Please don’t use a vacuum cleaner as this may apply excessive force to the fan. In order to ensure flawless operation over many years of usage, the NF-A20 5V’s premium grade SSO2 bearing is fully sealed to prevent the entering of fine dust particles. - Page 8 We from Noctua always strive to achieve superior quiet cooling performance regardless of whether it’s a big 200mm fan or a small 40mm one. That’s why the NF-A20 5V sports many of the features and advanced aerodynamic design measures of our award-winning larger models, making it perhaps the most thoroughly optimised 200mm fan on the market.
- Page 9 NF-A20 5V. Should you have any further questions, our support team (support@noctua.at) will be glad to assist you at any time. Please also have a look at the regularly updated FAQs on our website: http://www.noctua.at/faqs...
- Page 10 Designed in Austria, Noctua’s premium cooling components are internationally renowned for their superb quietness, exceptional performance and thoroughgoing quality. Having received more than 6000 awards and recommendations from leading hardware websites and magazines, Noctua’s fans and heatsinks are chosen by more than a hundred thousand satisfied customers around the globe.
