Noctua NH-L12S Installation Manual

Hide thumbs Also See for NH-L12S:

Advertisement

Table of Contents

!
LGA1700, LGA1200 & LGA115x
Dear customer,
Thank you very much for choosing the Noctua NH-L12S.
Successor to the award-winning NH-L12, the NH-L12S is
a compact low-profile CPU cooler that combines excellent
compatibility, surprising efficiency and remarkable
flexibility.
Enjoy your NH-L12S!
This manual will guide you through the installation process of
the SecuFirm2™ mounting system step by step.
Prior to installing the cooler, please consult the compatibility
centre on our website (ncc.noctua.at) and verify that the
cooler is fully compatible with your motherboard.
Please also make sure that your PC case offers sufficient
clearance for the cooler and that there are no compatibility
issues with any other components (e.g. tall RAM modules).
Double check that the heatsink and fan clips do not make
contact with the VGA card, other PCIe cards, motherboard
heatsinks or any other components.
Noctua cannot be held responsible for any damage or losses
caused by compatibility issues.
Should you encounter any difficulties, please check the FAQs
on our website (www.noctua.at/faqs) and don't hesitate to
contact our support team at support@noctua.at.
Multilingual versions of this manual are available on our
website: www.noctua.at/manuals
Yours sincerely,
Roland Mossig, Noctua CEO

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NH-L12S and is the answer not in the manual?

Questions and answers

Related Manuals for Noctua NH-L12S

Summary of Contents for Noctua NH-L12S

  • Page 1 LGA1700, LGA1200 & LGA115x Dear customer, Thank you very much for choosing the Noctua NH-L12S. Successor to the award-winning NH-L12, the NH-L12S is a compact low-profile CPU cooler that combines excellent compatibility, surprising efficiency and remarkable flexibility. Enjoy your NH-L12S!

  • Page 2: Removing The Motherboard

    NOCTUA NH-L12S INSTALLATION MANUAL Required mounting parts: 1x NM-IBP4 2x NM-IMB3 backplate mounting bars 4x NM-ICS1 4x NM-ITS1 4x NM-IBT5 clip-on spacers thumb screws bolts 4x NM-IPS1 4x NM-IPS3 black plastic spacers for blue plastic spacers for LGA1200/115x LGA1700 Removing the motherboard...

  • Page 3: Attaching The Backplate

    Position 1: Position 2: LGA1200/115x LGA1700 Fix the bolts using the NM-ICS1 clip-on spacers. Note that 2 extra clip-on spacers are supplied in case any are lost or damaged when removing the bolts at a later point. Attaching the backplate Caution: The supplied backplate will install over the motherboard’s stock backplate, so the motherboard’s stock backplate must not be taken off.
  • Page 4 LGA1200/115x LGA1700 NM-IPS1 (black) NM-IPS3 (blue) Use hole position 1 for LGA1200/115x (LGA1150, LGA1151, LGA1155, LGA1156) and hole position 2 for LGA1700 (LGA17xx family): Position 1: Position 2: LGA1200/115x LGA1700 Caution: Make sure to use the correct hole position on both ends of the NM-IMB3 mounting bars so that they will not be misaligned.
  • Page 5 Caution: Choose the alignment of the mounting bars according to the desired final orientation of the cooler. Orientation A Orientation B Caution: Make sure that the curved sides of the mounting bars are pointing outwards. Fix the mounting bars using the four NM-ITS1 thumb screws.

  • Page 6: Fan Configuration

    Caution: Applying too much thermal paste will lower heat conductivity and cooling performance! Fan configuration The NH-L12S ships with the fan installed underneath the fins (low profile mode). Alternatively, you can take off the fan and install it on top of the fins to make more room for tall RAM or other components (high clearance mode).

  • Page 7: Transporting Your System

    Fastening the heatsink to the CPU Caution: Please first take off the protection cover at the bottom side of the heatsink. Then put the heatsink onto the CPU and screw it to the screw threads of the mounting bars. Perform 2-3 turns on each screw, then repeat until both are fully tightened.
  • Page 8 Therefore, we aim at providing the highest possible level of reliability and convenience by offering a warranty period of 6 years and direct, fast and straightforward RMA service. Should you encounter any problems with your NH-L12S, please don’t hesitate to contact our support team (support@noctua.at).
  • Page 9 LGA20xx Dear customer, Thank you very much for choosing the Noctua NH-L12S. Successor to the award-winning NH-L12, the NH-L12S is a compact low-profile CPU cooler that combines excellent compatibility, surprising efficiency and remarkable flexibility. Enjoy your NH-L12S! Yours sincerely, Roland Mossig, Noctua CEO...
  • Page 10 Required mounting parts: 2x NM-IMB3 mounting bars 4x NM-ITS1 4x NM-IBT2 thumb screws bolts Installing the mounting bars First screw the NM-IBT2 bolts into the screw threads of the LGA20xx socket frame. Then put the NM-IMB3 mounting bars onto the bolts. Caution: Choose the alignment of the mounting bars according to the desired final orientation of the cooler.
  • Page 11 Caution: Make sure that the curved sides of the mounting bars are pointing outwards. Fix the mounting bars using the four NM-ITS1 thumb screws. Caution: Gently tighten the screws until they stop, but do not use excessive force (max. torque 0.6 Nm). Applying the thermal paste If there are residual traces of thermal paste or thermal pads on your CPU, please clean them off first.
  • Page 12 Therefore, we aim at providing the highest possible level of reliability and convenience by offering a warranty period of 6 years and direct, fast and straightforward RMA service. Should you encounter any problems with your NH-L12S, please don’t hesitate to contact our support team (support@noctua.at).
  • Page 13 AMD (AM4 & AM5) Dear customer, Thank you very much for choosing the Noctua NH-L12S. Successor to the award-winning NH-L12, the NH-L12S is a compact low-profile CPU cooler that combines excellent compatibility, surprising efficiency and remarkable flexibility. Enjoy your Noctua NH-L12S!
  • Page 14 If your motherboard does not include a stock backplate, please contact our Noctua service team at support@noctua.at. Attaching the mounting bars Caution: Choose either the short NM-AMB6 or the long NM-AMB7 mounting bars according to the desired final orientation of the cooler.
  • Page 15 First put the plastic spacers onto the screw threads of the backplate, then fix the mounting bars using the four NM-ALS1 long screws. NM-AMB6 NM-AMB7 Caution: For the short NM-AMB6 mounting bars, make sure that the curved sides are pointing inwards. Caution: For the long NM-AMB7 mounting bars, make sure that the curved sides are pointing outwards.
  • Page 16 Caution: Applying too much thermal paste will lower heat conductivity and cooling performance! Fan configuration The NH-L12S ships with the fan installed underneath the fins (low-profile mode). Alternatively, you can take off the fan and install it on top of the fins to make more room for tall RAM or other components (high-clearance mode).
  • Page 17 NOCTUA NH-L12S INSTALLATION MANUAL Fastening the heatsink to the CPU Caution: Please first take off the protection cover at the bottom side of the heatsink. Then put the heatsink onto the CPU and screw it to the screw threads of the mounting bars. Perform 2-3 turns on each screw, then repeat until both are fully tightened.
  • Page 18 6 years and direct, fast and straightforward RMA service. Should you encounter any problems with your NH-L12S, please don’t hesitate to contact our support team (support@noctua.at). Please also consult the FAQ section on our website:...
