Noctua NH-U9S chromax.black Installation Manual

Hide thumbs Also See for NH-U9S chromax.black:

Advertisement

Table of Contents

!
LGA1700, LGA1200 & LGA115x
Dear customer,
Thank you very much for choosing the Noctua
NH-U9S chromax.black.
The NH-U9S chromax.black is an all-black version
of Noctua's award-winning NH-U9S premium-quality
quiet CPU cooler.
I'm confident that you will be able to sense some of
the research, attention and care we've put into making
this cooler.
Enjoy your NH-U9S chromax.black!
INSTALLATION MANUAL
This manual will guide you through the installation
process of the SecuFirm2™ mounting system step
by step.
Prior to installing the cooler, please consult the
compatibility centre on our website (ncc.noctua.at)
and verify that the cooler is fully compatible with your
motherboard.
Please also make sure that your PC case offers
sufficient clearance for the cooler and that there are
no compatibility issues with any other components
(e.g. tall RAM modules).
Double check that the heatsink and fan clips do not
make contact with the VGA card, other PCIe cards,
motherboard heatsinks or any other components.
Noctua cannot be held responsible for any damage or
losses caused by compatibility issues.
Should you encounter any difficulties, please check
the FAQs on our website (www.noctua.at/faqs)
and don't hesitate to contact our support team at
support@noctua.at.
Multilingual versions of this manual are available on our
website: www.noctua.at/manuals
Yours sincerely,
Roland Mossig, Noctua CEO
