IDEC MICROSmart FC6A Series Instruction Sheet

INSTRUCTION SHEET
Bluetooth Communication Cartridge
This sheet provides brief operating instructions of the MICROSmart
programmable controller. For details, see the FC6A Series MICROSmart
User's Manual.
Safety Precautions
Special expertise is required to use the MICROSmart.
●
Read this instruction sheet and the user's manual to make sure of
correct operation before starting installation, wiring, operation,
maintenance, and inspection of the MICROSmart.
Keep this instruction sheet where it can be accessed by the end user.
●
All MICROSmart modules are manufactured under IDEC's rigorous
quality control system, but users must add backup or failsafe provisions
to control systems use the MICROSmart in applications where heavy
damage or personal injury may be caused if the MICROSmart should
fail.
●
Install the MICROSmart according to the instructions described in this
instruction sheet and the user's manual.
Improper installation will result in falling, failure, or malfunction of the
MICROSmart.
●
Make sure that the operating conditions are as described in the user's
manual. If you are uncertain about the specifications, contact IDEC
before using the MICROSmart.
●
In this instruction sheet, safety precautions are categorized in order of
importance from Warning and Caution:
Warning notices are used to emphasize that improper operation may
cause severe personal injury or death.
Caution notices are used where inattention might cause personal injury or
damage to equipment.
● Turn off the power to the MICROSmart before starting installation,
removal, wiring, maintenance, or inspection on the MICROSmart.
Failure to turn off the power may cause damage, electrical shocks or fire
hazard.
● Emergency stop and interlocking circuits must be configured outside
the MICROSmart. If such a circuit is configured inside the MICROSmart,
failure of the MICROSmart may cause disorder of the control system,
damage, or accidents.
●
SUITABLE FOR USE IN CLASS 1, DIVISION 2, GROUPS A,B,C AND D
HAZARDOUS LOCATIONS, OR NONHAZARDOUS LOCATIONS ONLY.
Cet appareil convient uniquement à ľemploi dans des zones dangereuses
●
de classe 1, groupes A,B,C et D; ou dans des zones non dangereuses.
●
WARNING - EXPLOSION HAZARD - DO NOT DISCONNECT
EQUIPMENT WHILE THE CIRCUIT IS LIVE OR UNLESS THE AREA IS
KNOWN TO BE FREE OF IGNITABLE CONCENTRATIONS.
Avertissement: risque d'explosion. Ne pas débrancher ľappareil tant que
●
le circuit est sous tension, ou à moins ďêtre certain que lieu ďutilisation
soit exempt de concentrations inflammables.
●
THIS EQUIOMENT IS AN OPEN -TYPE DEVICE MEANT TO BE
INSTALLED IN AN ENCLOSURE SUITABLE FOR THE ENVIRONMENT
THAT IS ONLY ACCESSIBLE WIHT THE USE OF A TOOL OR KEY.
Cet appareil doit être installé dans un boîtier qui est adapté à
●
ľenvironnement ďutilisation et uniquement accessible avec un outil
ďouverture ou une clé.
FC6A Series
B-1997(5)
