DIGITAL MEDIA RECEIVER
RECEPTEUR NUMERIQUE MULTIMEDIA
RICEVITORE MULTIMEDIALE DIGITALE
RECEPTOR DIGITAL DE MEDIOS
DIGITALER MEDIA RECEIVER
DIGITALE MEDIA-RECEIVER
MVH-S110UI
MVH-S110UIG
MVH-S11UI
MVH-S110UB
MVH-S110UBG
MVH-S110UBA
MVH-S110UBW
Guide de démarrage rapide
Guía de iniciación rápida
Quick start guide
Guida rapida all'uso
Schnellstartanleitung
Snelstartgids
QRD3657-A
Advertisement
Table of Contents
Related Manuals for Pioneer MVH-S110UI
Summary of Contents for Pioneer MVH-S110UI
- Page 1 DIGITAL MEDIA RECEIVER RECEPTEUR NUMERIQUE MULTIMEDIA RICEVITORE MULTIMEDIALE DIGITALE RECEPTOR DIGITAL DE MEDIOS DIGITALER MEDIA RECEIVER DIGITALE MEDIA-RECEIVER MVH-S110UI MVH-S110UBG MVH-S110UIG MVH-S110UBA MVH-S11UI MVH-S110UBW MVH-S110UB Quick start guide Guide de démarrage rapide Guida rapida all’uso Guía de iniciación rápida Schnellstartanleitung...
- Page 2 • This product is evaluated in moderate and tropical climate condition under the Audio, video and similar electronic apparatus - Safety requirements, IEC 60065. If you experience problems Should this unit fail to work properly, please contact your dealer or nearest authorized PIONEER Service Station.
- Page 3 Connections WARNING Important • When installing this unit in a vehicle without an ACC (accessory) position on the ignition switch, failure to connect the red cable to the terminal that detects operation of the ignition key may result in battery drain. ACC position No ACC position • Use of this unit in conditions other than the...
- Page 4 RCA pre-outs are stored in memory if the unit is disconnected from power supply. This unit Power cord input Rear output or subwoofer output Front output (Only for MVH-S110UI/S11UI/S110UIG) Antenna input Fuse (10 A) Wired remote input (Only for MVH-S110UI/S11UI/S110UIG) Hard-wired remote control adapter can be...
-
Page 5: Power Cord
(max. 300 mA 12 V DC). Blue/white Connect to the auto-antenna relay control terminal (max. 300 mA 12 V DC). Yellow/black (Only for MVH-S110UI/S11UI/S110UIG) If you use equipment with a Mute function, wire this lead to the Audio Mute lead on that... -
Page 6: Power Amp (Sold Separately)
Perform these connections when using the optional amplifier. System remote control Connect to blue/white cable. Power amp (sold separately) Connect with RCA cables (sold separately) To front output* Front speaker* To rear output or subwoofer output Rear speaker or subwoofer * Only for MVH-S110UI/S11UI/S110UIG... -
Page 7: Installation
Installation Important • Check all connections and systems before final installation. • Do not use unauthorized parts as this may cause malfunctions. • Consult your dealer if installation requires drilling of holes or other modifications to the vehicle. • Do not install this unit where: −... - Page 8 Dashboard Mounting sleeve • Make sure that the unit is installed securely in place. An unstable installation may cause skipping or other malfunctions. When not using the supplied mounting sleeve Line up the holes on the mounting bracket with the holes on the sides of the unit to attach the bracket.
- Page 9 Screw Bracket Removing the unit (installed with the supplied mounting sleeve) Remove the trim ring. Trim ring Notched tab • Releasing the front panel allows easier access to the trim ring. • When reattaching the trim ring, point the side with the notched tab down.
-
Page 10: Basic Operation
Basic operation MVH-S110UI/S110UIG/S11UI/S110UB/S110UBG/S110UBA/S110UBW BASS USB port M.C. (multi-control) dial SRC (source)/OFF DISP (display) Detach button Display window AUX input jack (3.5 mm stereo jack) BAND/ About the main menu You can adjust various settings in the main menu. Press the M.C. dial to display the main menu. - Page 11 Frequently used operations Purpose Operation Press SRC/OFF to turn on the Turn on the power power. Press and hold SRC/OFF to turn off the power. Turn the M.C. dial. Adjust the volume Press SRC/OFF repeatedly. Select a source Press DISP repeatedly. Change the display information Press BAND/ Return to the previous display/list...
-
Page 12: Setup Operation
Setup operation When you turn the ignition switch to ON after installation, [SET UP :YES] appears in the display. Press the M.C. dial. Turn the M.C. dial to select the options, then press to confirm. To proceed to the next menu option, you need to confirm your selection. Menu Item Description LANGUAGE... -
Page 13: Tuner Operation
Tuner operation Receiving preset stations Press SRC/OFF to select [RADIO]. Press BAND/ to select the band. [FM1] [FM2] [FM3] [MW]/[LW] Press a number button (1/ to 6/ ). Best stations memory (BSM) After selecting the band, press the M.C. dial to display the main menu. - Page 14 USB/iPod®/AUX operation NOTE MVH-S110UB/S110UBG/S110UBA/S110UBW is not compatible with Apple® devices. USB/iPod Open the USB port cover. Plug in the USB device/iPod using an appropriate cable. MTP connection A device installed with Android OS 4.0 or most of later versions can be connected to the unit via MTP, using the cable supplied with the Android device.
- Page 15 Turn the M.C. dial to select [P.APP AUTO ON], then press to confirm. Turn the M.C. dial to select [ON], then press to confirm. Connect this unit with the device via USB. Pioneer ARC APP on the Android device starts automatically.
-
Page 16: Listening To Spotify
Press SRC/OFF to select any source. Press and hold the M.C. dial. Pioneer ARC APP on the iPhone starts. NOTE If the connection fails, launch Pioneer ARC APP on the iPhone. Listening to Spotify® (Only compatible with Spotify installed on iPhone) NOTE MVH-S110UB/S110UBG/S110UBA/S110UBW is not compatible with Apple devices. - Page 17 Pioneer vakuuttaa, että radiolaitetyyppi [*] on direktiivin Español: 2014/53/EU mukainen. Por la presente, Pioneer declara que el tipo de equipo EU-vaatimustenmukaisuusvakuutuksen täysimittainen radioeléctrico [*] es conforme con la Directiva 2014/53/UE. teksti on saatavilla seuraavassa internetosoitteessa: http:// El texto completo de la declaración UE de conformidad www.pioneer-car.eu/compliance...
