- Page 1 Quick Start Guide Version 1.1.0...
-
Page 2: Package Content
Package Content Camera ×1 Mounting Template ×1 Mounting Bracket ×1 Screw and Anchor QSG ×1 Waterproof Connector ×1 Pack ×1 Power Adapter ×1... -
Page 3: Camera Introduction
Camera Introduction Disconnect the camera from the power before installation or taking out its SD card. Ethernet Port Power Port Wi-Fi Antenna Reset Button LED Indicator Micro SD Card Slot Microphone Spotlight Infrared LED Lens Speaker... - Page 4 Press and hold the reset button for 10 s to reset the camera. Double-press the reset button to enable camera’s hotspot. See the table below for definitions of camera’s LED behaviors. LED Indicator Status Device Status Power off/LED turned off Off...
-
Page 5: Setting Up Camera
Follow the steps below to add the camera to your Imou account. Step 1 Scan the following QR code or search "Imou Life" in Google Play or App Store to download and install the app. If you already use the app, make sure that you are using the latest version. - Page 6 Step 4 After the camera boots up, the LED indicator light flashes green (wire-free camera) or is on solid green (wired camera). If the LED indicator status goes wrong, reset the camera. Step 5 Follow the on-screen prompts to add the camera. Repeat the adding process if you have multiple cameras.
-
Page 7: Installing Camera
Installing Camera Make sure that the mounting surface is strong enough to hold at least three times the weight of the camera and the bracket. Ceiling Mount Mounting Surface Mounting Template (U-shaped) Wall Anchor Mounting Bracket Mounting Screw Camera Step 1 Peel off... - Page 8 Step 3 Secure the mounting bracket to the surface with included mounting screws. Step 4 Align on the top of the camera with on the bracket, then fit the two parts together. Step 5 Rotate the camera counterclockwise until it is locked. Make sure align with Step 6 Power on the camera and then adjust its angle properly.
- Page 9 Step 1 Peel off the rectangular mounting template and stick it to the desired installation area. Step 2 Drill holes into the mounting surface as the mounting template marks and then insert wall anchors as needed. Step 3 Secure the mounting bracket to the surface with included mounting screws.
- Page 10 Pole Mount Make sure that the pole is strong enough to hold at least three times the weight of the camera and the bracket. The hoops are not provided. Please prepare them in advance. Mounting Bracket Hoop Camera Step 1 Thread the hoop through the mounting holes on the bracket, then attach the bracket to the pole .
- Page 11 Step 2 Align on the top of the camera with on the bracket, then fit the two parts together. Step 3 Rotate the camera counterclockwise until it is locked. Make sure align with Step 4 Power on the camera and then adjust its angle properly.
- Page 12 Q: The device cannot boot up or work as expected? Check the LED indicator status. If the light is not in green, press and hold the reset button for 10 s to reset the camera. Q: How to connect the camera to another Wi-Fi network? If the camera is online, select Device Details >...
- Page 13 Q: Where are the recorded videos saved? If you have activated the cloud storage and installed a micro SD card, the recordings will be both saved to the card and cloud. If the cloud storage is deactivated, the recordings are saved to the SD card. Videos recorded during live view or playback is saved on your phone.
- Page 14 About the Manual - This manual is for reference only. The operation of the actual product shall prevail if there is any inconsistency. - All the designs and software are subject to change without prior written notice. - All trademarks and registered trademarks mentioned are the properties of their respective owners.
