imou
Cell Pro
User's Manual
V1.0.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Cell Pro and is the answer not in the manual?

Questions and answers

Related Manuals for IMOU Cell Pro

Summary of Contents for IMOU Cell Pro

  • Page 1 Cell Pro User's Manual V1.0.0...

  • Page 2: Foreword

    Foreword General This user’s manual (hereinafter referred to be "the Manual") introduces the operation of imou app. Safety Instructions The following categorized signal words with defined meaning might appear in the Manual. Signal Words Meaning Indicates a medium or low potential hazard which, if not avoided, WARNING could result in slight or moderate injury.
  • Page 3  All the designs and software are subject to change without prior written notice. The product updates might cause some differences between the actual product and the Manual. Please contact the customer service for the latest program and supplementary documentation. ...

  • Page 4: Important Safeguards And Warnings

    Important Safeguards and Warnings Electrical Safety  All installation and operation should conform to your local electrical safety codes.  The power source shall conform to the Safety Extra Low Voltage (SELV) standard, and supply power with rated voltage which conforms to Limited power Source requirement according to IEC60950-1.
  • Page 5 protection effect.  It is recommended to ground the device to enhance reliability.  Do not touch the image sensor (CMOS) directly. Dust and dirt could be removed with air blower, or you can wipe the lens gently with soft cloth that moistened with alcohol. ...

  • Page 6: Regulatory Information

    Regulatory Information The regulatory information herein might vary according to the model you purchased. Some information is only applicable for the country or region where the product is sold. FCC Information Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.
  • Page 7 Risk of explosion if battery is replaced by an incorrect type. Dispose of used batteries according to the instructions. Privacy Protection Notice As the device user or data controller, you might collect personal data of others such as face, fingerprints, car plate number, Email address, phone number, GPS and so on.

  • Page 8: Table Of Contents

    1 Introduction ............................1 1.1 General............................1 1.2 Features ............................1 2 Getting Started ............................2 2.1 Registering imou Account ......................2 2.2 Adding Base Station ........................5 2.3 Pairing Camera ..........................9 3 App Operation ............................11 3.1 Managing Devices ........................11 3.2 Live Interface ..........................

  • Page 9: Introduction

    Introduction 1.1 General imou Cell Pro network camera guards your home 24 hours with PIR detection and mobile phone alarm push. It provides high-definition live video, and supports data transmission and operation through the imou app. You can also view the live video and perform monitoring configuration remotely on your mobile phone.

  • Page 10: Getting Started

    Getting Started This chapter introduces how to add the device to your network with the imou app. If you already have imou account, go to "2.2 Adding Base Station." 2.1 Registering imou Account Step 1 Download and install the imou app from Google Play or App Store. See Figure 2-1.
  • Page 11 Figure 2-2 Notifications After the notifications, the log in interface is displayed. See Figure 2-3. Getting Started 3...
  • Page 12 In the log in interface (see Figure 2-3), tap Sign up, and then select your country/region. Click Next, and then the Sign up interface is displayed. See Figure 2-4. You need a valid email address to register imou account. Getting Started 4...

  • Page 13: Adding Base Station

    The system indicator stays on with white light for 10 s, and then off, which means the base station is connected to the network. Step 2 Connect your phone to your Wi-Fi network, and then log in the imou app, the Device interface is displayed. See Figure 2-5. Getting Started 5...
  • Page 14 Figure 2-5 Device Step 3 Click + in the center of the screen or at the upper right corner. The Device adding interface is displayed. See Figure 2-6. This operation requires camera access. See "3.4.3 Setting Access." Getting Started 6...
  • Page 15 Figure 2-6 Device adding Step 4 Scan the QR code on the label or enter the device SN manually. You can tap the lightning sign on the upper right corner to open flashlight. Step 5 After scanning is finished, you need to configure the device password. See Figure 2-7. The password is used to manage the access to your device and data, please keep it properly and change it regularly for safety concerns.
  • Page 16 Figure 2-7 Configure password Step 6 Tap Next, The Add successfully interface is displayed. See Figure 2-8. Getting Started 8...

  • Page 17: Pairing Camera

    Figure 2-8 Add successfully Step 7 Configure the name of the base station and the DST as needed, and then tap Complete. The time zone and DST configurations have influences on the app function, please  configure properly. If you have more than one device, follow from step 3 to add them one by one. ...
  • Page 18 time.  Keep the distance of the base station and the camera within 30 cm (12 inches) during pairing. Getting Started 10...

  • Page 19: App Operation

    3.1 Managing Devices This section introduces the Device interface. You can check all the current devices and add more devices. Run imou app, and the Device interface is displayed, all the current devices are listed. See Figure 3-1. Figure 3-1...
  • Page 20 Figure 3-2 Paired camera For the detailed introduction, see Table 3-1. Table 3-1 Device interface introduction Icon Introduction Add more devices to your account, for more details, see "2.2 Adding Base Station." Tap to view the camera battery status. Tap to view the connection quality. If the icon is , it means you are not using cloud service, and you can tap to view the cloud service plans...

  • Page 21: Live Interface

    Icon Introduction Configure the camera and imou app. See "3.5 Configuring imou App." 3.2 Live Interface In the Device interface (Figure 3-1), select a device to enter the Live interface. See Figure 3-3. Figure 3-3 Live For the detailed introduction, see Table 3-2.

  • Page 22: Full Screen

    Icon Introduction Switch to multi-channel live view, you can select four devices at most from all your devices. When under single-channel mode, you can also swipe left or right to switch between the four selected channels. Indicates the current stream resolution, tap to switch to HD, and tap again to switch back.

  • Page 23: Record History

    Figure 3-4 Full screen Tap anywhere on the screen to display or hide function buttons.  to go back to normal mode.  3.2.2 Record History You can view all the recorded videos as date and time. The camera requires either a flash drive connected to the base station or the cloud saving service to save recorded video.
  • Page 24 Figure 3-5 Record history Step 2 You can perform the following operations:  to view the videos saved in the cloud.  to view the videos saved in the flash drive that connected to the base station. Slide the time bar to select the time you need, or pinch the time axis to zoom in or out, which helps to find the recorded videos easier.
  • Page 25 Figure 3-6 Calendar Those dates with the sign indicate there were videos recorded. You can tap any date to view the video with time axis. , and then the file list interface is displayed. See Figure 3-7.  Figure 3-7 File list Tap any video to view, or you can tap the date above to select other date in the calendar.

  • Page 26: Configuring Camera

    3.3 Configuring Camera In the Live interface (Figure 3-3), tap The device setting interface is displayed. See Figure 3-8. Figure 3-8 Device setting You can view the camera information, configure alarm information, storage status, or rotate image. 3.3.1 Device information Step 1 In the device setting interface (Figure 3-8), tap the device name, and then the Device info interface is displayed.

  • Page 27: Alarm Information

    If the PIR detection is disabled, the camera would stop detecting any intruder, and you can  only view the live video on the imou app manually. App Operation 19...

  • Page 28: Storage Status

    3.3.3 Storage Status You can view or change the cloud storage plan. In the device setting interface (Figure 3-8), select Storage Status > Cloud Storage, and then the Storage Status interface is displayed. See Figure 3-11. Figure 3-11 Storage Status Tap Normal to view or change the cloud storage plan.

  • Page 29: Intrusion Alarm

    Figure 3-12 Message Personal Alert is reserved for future use.  Tap System to view system messages, including update and latest notices.  3.4.1 Intrusion Alarm You can quickly find the videos specifically recorded when the PIR detection is triggered within seven days;...

  • Page 30: Notification

    You can receive push messages on your phone when the PIR detection is triggered. See Figure 3-14. Figure 3-14 Push message Step 1 In iOS, select Settings > imou > Notifications, and then the Notifications interface is displayed. See Figure 3-15. App Operation 22...

  • Page 31: Setting Access

    The camera requires certain access to your phone when you need to scan, enable intercom or save local files to your phone. Step 1 In iOS, select Settings > imou, and then the access setting interface is displayed. See Figure 3-16. App Operation 23...

  • Page 32: Configuring App

    Figure 3-16 Access Step 2 Enable the access you need by tapping each switch. 3.5 Configuring imou App In the Device interface (Figure 3-1), select Me, and then the app configuration interface is displayed. See Figure 3-17. App Operation 24...

  • Page 33: Local Files

    Figure 3-17 App configuration Tap the head portrait to configure your account.  Select My Device, and then you can configure the base station information, perform cloud  upgrade, reset device password, or view the camera list. 3.5.1 Local Files You can view all the snapshots and videos you saved to the local file.

  • Page 34: Setting Prompt Period

    to edit all the files, you can share, save to your phone or delete.  Saving files to your phone requires photos access. See "3.4.3 Setting Access." 3.5.2 Setting Prompt Period You can set the time that you want to receive messages (3.4 Message) and push messages (3.4.2 Notification).
  • Page 35 Appendix FAQ 1. My phone changed. Download the imou app in your new phone and log in your account. 2. My router changed. Connect the base station to the LAN port of the new router. 3. I forgot my device password.
