Summary of Contents for BE QUIET! DARK ROCK PRO 4
-
Page 2: Warranty
Listan GmbH & Co.KG . Biedenkamp 3a . 21509 Glinde Germany For further information contact us via e-mail: service@bequiet.com SCOPE OF DELIVERY Part name Quantity be quiet! Dark Rock Pro 4 cooler 135mm fan 120mm fan Intel backplate Intel mounting brackets Short AMD mounting brackets Cooler mounting bridge... - Page 3 We recommend removal of the cooler prior to transportation. January 2018 Part name Quantity AMD spacer nuts Mounting bracket fastening screws Intel/AMD mounting bridge fastening screws Intel backplate screws AMD backplate screws O-rings Cross-tip screwdriver Thermal paste Fan clips AM3 washers Y cable...
- Page 4 The following parts are needed for this: 1x Dark Rock Pro 4 CPU cooler (1), 1x 135mm fan (2), 1x 120mm fan (3), 2x Intel mounting brackets (5), 1x cooler mounting bridge (7), 4x Intel spacer nuts (8), 4x mounting bracket...
- Page 5 Position the cooler mounting bridge (7) centrally on the cooler (1). Next place the cooler unit over the CPU. Loosen both heatpipe caps that are found in the middle of the topside of the cooler (rotate as illustrated). Insert the Intel/AMD mounting bridge fastening screws (12) from above into the cooler mounting bridge (7) and then screw these alternately tight.
-
Page 6: Mounting The Backplate
The following parts are needed for this: 1x Dark Rock Pro 4 CPU cooler (1), 1x 135mm fan (2), 1x 120mm fan (3), 1x Intel backplate (4), 2x Intel mounting brackets (5), 1x cooler mounting bridge (7), 4x Intel 115X/1366 nuts (9), 4x... - Page 7 First remove the protective foil from the underside of the cooler. Spread the thermal paste (17) on the surface of the CPU. The amount supplied is sufficient for one or two applications. Caution: The thermal paste supplied is not suitable for human consumption.
- Page 8 The following parts are needed for this: 1x Dark Rock Pro 4 CPU cooler (1), 1x 135mm fan (2), 1x 120mm fan (3), 2x short AMD mounting brackets (6), 1x cooler mounting bridge (7), 4x AMD spacer nuts (10), 2x Intel/AMD mounting...
- Page 9 Position the cooler mounting bridge (7) centrally on the cooler. Next place the cooler unit onto the CPU. Loosen both heatpipe caps that are found in the middle of the topside of the cooler (rotate as illustrated). Insert the Intel/AMD mounting bridge fastening screws (12) from above into the cooler mounting bridge and then screw these alternately tight.
-
Page 10: Limited Warranty
Limited Warranty Per the terms and conditions of this limited warranty as given below, be quiet! warrants its new products to be free of defects resulting from faulty materials and faulty manufacturing for the length of the warranty period. I. APPLICABILITY This non-transferable warranty is applicable to newly purchased, previously unopened be quiet! products and is enforceable by only the original consumer purchaser.
