Ibanez PU3 Owner's Manual

① To avoid short circuit, electric shock, or malfunction
Do not disassemble or attempt to repair this unit.
Do not place this unit in locations of high temperature
or high humidity (such as nearby heating equipment,
in direct sunlight, in a bathroom, or on a wet floor).
Do not place this unit where it will be subjected to
heavy vibration.
Do not place this unit in dirty or dusty conditions.
Do not operate this unit with wet hands.
② To avoid damage
Do not apply excessive force to this unit. Do not drop
this unit.
③ Cleaning
Do not use thinner, alcohol, or other solvents to clean
this unit.
④ To prevent battery failure
Remove the battery if you won't be using this unit
for an extended period of time.
① The tuner turns on automatically when it is clipped
onto the headstock, and goes off automatically when
it is removed.
② The tuner will automatically turn off after 5 minutes
if left on the headstock.
③ When it is in tune, only the blue indicator on center
will flash up. When it is lower than the target pitch,
the red indicator on the left side will flash up. When
it is higher, the yellow indicator on the right side
will flash up.
- When the LCD becomes dim, please replace the
battery promptly.
- The power must be turned off while the battery is
replaced.
- Make sure the polarity when replacing the battery ((+)
mark should face up).
Tuning mode : Chromatic
Tuning notes : A, A#, B, C, C#, D, D#, E, F, F#, G, G#
Tuning range : A0 (27.5 Hz) - C8(4186 Hz)
Calibration : A4 = 440 Hz
Accuracy : ±1cent
Power supply : Lithium battery (CR2032) x 1
Dimensions : 48(W) x 44(D) x 27(H) mm
Weight : 24g (Including battery)
* Design and specifications are subject to change
without notice for improvement.
CLIP-ON TUNER
OWNER'S MANUAL
Caution
Appearance
LCD
Battery cover
Operation
Replacing battery
Specifications
PU3
Clip
