Quick Installation Guide

For product or function details, please visit www.tendacn.com

Dual Band Gigabit WiFi Router

AC19/AC23

(AC23 is used for illustration in this guide)

Package contents

• Wireless router * 1

• Power adapter * 1

• Ethernet cable * 1

• Quick installation guide * 1

To get the App for management, scan

the QR code, or search for Tenda WiFi

in App Store/Google Play

Need help?

Do you have a question about the AC19 and is the answer not in the manual?

Questions and answers

Summary of Contents for Tenda AC19

Page 1 • Wireless router * 1 • Power adapter * 1 • Ethernet cable * 1 To get the App for management, scan • Quick installation guide * 1 the QR code, or search for Tenda WiFi in App Store/Google Play...
Page 2 2. Connect the WAN port of the new router to the LAN port of 3, and IPTV/4 for AC19; port 1, 2, IPTV/3 for AC23) of the new router your modem or the Ethernet jack using an Ethernet cable. The using an Ethernet cable.
Page 3 Method 2: Connect your wired device (such as a computer) to a LAN port (port 1, 2, 3, and IPTV/4 for AC19; port 1, 2, PTV/3 for AC23) of the router using an Ethernet cable. The LAN LED Iindicator lights up.
Page 4 1. Start a web browser on a device that has connected to the router, and visit tendawif i.com. tendawif i.com tendawif i.com Tenda Router Quick Setup Wiz Start If you cannot log in to the web UI of the router, refer to Q1 in FAQ.
Page 5 2. Click Start. Tenda Router Quick Setup Wizard Start...
Page 6 3. The router detects your internet connection type automatically. Set required parameters and click Next. Please select your connection type. As detected, your connection type may be: PPPoE Connection Type: PPPoE ISP User Name: Enter the user name from your ISP . ISP Password: Enter the password from your ISP .
Page 7 4 . Customize your WiFi name (SSID), WiFi password and the login password as needed, and click Next. WiFi Settings Tenda_XXXXXX Not Required WiFi password of 8-32 characters Set the WiFi password as the login password of the admin account. Login password of 5-32 characters Not Required Next...
Page 8 Done. You’re all set! You can now connect to Tenda_XXXXXX To change settings of other features,click the "More" button below. More IV. Access the internet WiFi-enabled devices: Connect your WiFi-enabled devices to the WiFi network of the router using the WiFi name and WiFi password you set.
Page 9: Led Indicators
LED indicators LED indicator Status Description The router is starting. If the indicator still light solid on after the router Solid on completes startup, it indicates that the router is connecting to the internet successfully. The router works properly, but fails to connect to Blinking the internet.
Page 10 Jack, ports and buttons IPTV/3 WPS/RST POWER AC23 Description Jack/Port/Button Power jack. POWER Used to connect to the included power adapter. Used to start the WPS negotiation process, or to reset the router. WPS: Press the button of the router for 1 to 3 seconds. Within 2 minutes, enable the WPS function of the other WPS-supported WPS/RST device to establish a WPS connection.
Page 11 IPTV/4 WPS/RST POWER AC19 Description Jack/Port/Button Used to connect to a USB 2.0 device. Used to start the WPS negotiation process, or to reset the router. WPS: Press the button of the router for 1 to 3 seconds. Within 2...
Page 12 If you use a computer to log in to the web UI of the router, ensure that it is connected to a LAN port (port 1, 2, 3, and IPTV/4 for AC19; port 1, 2, IPTV/3 for AC23) of the router properly by an Ethernet cable. And it is set to Obtain an IP address automatically and Obtain DNS server address automatically.
Page 13 By default, the WiFi name for 2.4 GHz is the same with 5 GHz. To change it, please follow the instructions in Q4. Technical Support Shenzhen Tenda Technology Co., Ltd. 6-8 Floor, Tower E3, NO.1001, Zhongshanyuan Road, Nanshan District, Shenzhen, China. 518052...
Page 14 RJ45 cable. Declaration of Conformity Hereby, SHENZHEN TENDA TECHNOLOGY CO., LTD. declares that the radio equipment type AC23 is in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address: http://www.tendacn.com/en/service/download-cata-101.html...
Page 15 FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
Page 16 Copyright © 2019 Shenzhen Tenda Technology Co., Ltd. All rights reserved. Tenda is a registered trademark legally held by Shenzhen Tenda Technology Co., Ltd. Other brand and product names mentioned herein are trademarks or registered trademarks of their respective holders. Speci cations are subject to change without...
