PORTABLE RADIO
CITY BOY 52

Advertisement

loading
Need help?

Need help?

Do you have a question about the CITY BOY 52 and is the answer not in the manual?

Questions and answers

Related Manuals for Grundig CITY BOY 52

Summary of Contents for Grundig CITY BOY 52

  • Page 1 PORTABLE RADIO CITY BOY 52...
  • Page 2 PORTABLE RADIO CITY BOY 52 __ Preparation Remove the battery compartment cover on the back of the device. Insert two batteries (LR 03/AM 4/AAA) in the battery com-part- ment. Make sure the polarity of the batteries is as marked on the bottom of the compartment.
  • Page 3 CONTROLS _______________________ ON/OFF Switches the device on and off. Manual and automatic tuning. VOL. g Volume control. MEM. Memory function button. 1, 2, 3, 4, Buttons for selecting and storing preset stations. Button for selecting the second level of preset sta- tion buttons 1, 2, 3, 4, 5.
  • Page 4 RADIO MODE _____________________ Radio reception and station selection Press »ON/OFF« to switch on the device. Use »VOLUME« to adjust the volume. 87.6 Press »A« or »S« to select the frequency. Press briefly to tune in increments, or hold down for fast tuning. –...

  • Page 5: Storing Stations

    If the FM stereo signal is too weak, press »STEREO/MONO« to switch to »MONO« reception. Press »UBS ON« to ”boost” the bass tones. Press »ON/OFF« to switch off the device. Storing stations Up to 10 preset stations are available. Five stations can be stored on the first level using the »1, 2, 3, 4, 5«...
  • Page 6 To store the first 5 stations, press »1, 2, 3, 4« or »5«, and then »MEM.«. – Display: The »MEMO« symbol disappears. – or – MEMO To store on preset numbers 6 to 10, press »+ 5« and then »1, 2, 3, 4«...
  • Page 7 GENERAL INFORMATION _________ Disabling the buttons If you press »LOCK ON« you can protect the device from unintentio- ∂ nal pressing of the buttons. If this function is selected »∂ « appears in ∂ display. re-enable buttons, press »LOCK OFF« again. Stereo earphones Excessive volume can be dangerous to yourself and other road users.
  • Page 8 Safety and technical data This device is designed for the playback of audio signals. Any other use is expressly prohibited. Protect the device from humidity. Never open the device casing. The manufacturer accepts no liability for damage resulting from improper handling. The type plate is located on the back of the device.
