BBPOS WisePad Q Manual

Hide thumbs Also See for WisePad Q:

Advertisement

Table of Contents

WisePad™ Q
mPOS Solution Combining Swipe, EMV Contactless,
EMV Chip and Pin Card Reading Functions
Support Operating System:
iOS, Android, Windows Phone 8, MS Windows
Index & Accessories (Fig.1)
LCD display
Secure PIN pad
for PIN input
CANCEL button
FRONT
Micro-USB port
for charging & operation
www.bbpos.com
Status light for tap card
Swipe card slot
For chip card reading
Power on / Setting,
up and down buttons
ENTER button
CLEAR button

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WisePad Q and is the answer not in the manual?

Questions and answers

Related Manuals for BBPOS WisePad Q

Summary of Contents for BBPOS WisePad Q

  • Page 1 WisePad™ Q mPOS Solution Combining Swipe, EMV Contactless, EMV Chip and Pin Card Reading Functions Support Operating System: iOS, Android, Windows Phone 8, MS Windows www.bbpos.com Index & Accessories (Fig.1) FRONT Status light for tap card Swipe card slot LCD display...

  • Page 2: Package Contents

    Index & Accessories (Fig.2) SIDE BACK For EMV contactless For chip card card reading reading Package Contents Device Quick start guide (QR code) Micro-USB cable Status LED Indicators in Transaction First Light ON Lights ON in consecutive order 4 Lights ON + “BEEP” Amount: Approved Processing…...

  • Page 3: Product Speci Cations

    Product Speci cations Features & Functions • EMV/PBOC Chip card reader (ISO 7816 Compliant Class A, B, C card) • NFC Reader (EMV contactless, ISO 14443A/B) • Secure PIN pad • Dual Track Magnetic Stripe Card Reader Display 1.8” LCD, 128x40 dot pixel with backlight Status Indicator 4 LEDs Communication Interface...

  • Page 4: Credit Card

    Troubleshooting Problems Recommendations • Please check if the device has power when Device cannot read your card successfully operating and ensure devices are connected. • Please ensure that there is no obstacle in the card slots. • Please check if the chip of the card is facing the right direction when inserting card.

  • Page 5: Quick Start Procedures

    Download and install o cial application from APP Store (Fig. 3.1). STEP 2 Press and hold “ ” to turn on WisePad™ Q until “bbpos” is displayed on the LCD. Turn on your smartphone/tablet Bluetooth Bluetooth® pairing function (Fig. 3.2).
  • Page 6 Sale Operation STEP 1 In Sale page (Fig. 3.5), enter amount and press “Charge”. Enter amount Charge Fig. 3.5 - Sale STEP 2 In Payment Method page (Fig. 4.1), press a payment method which you choose. Fig. 4.1 - Payment Method...
  • Page 7 When you press “Credit Card”, the APP and the device will go to Start Payment page (Fig. 4.2). Then, you can use one of below payment methods to start the transaction Change payment method Fig. 4.2 - Start Payment a. Insert EMV IC card. If you are required to input PIN (Fig. 4.3), please input via secure PIN pad and press “...
  • Page 8 b. Tap NFC card (Fig. 4.4). Success tapping will have beep sound and LED indication. (Please refer to NFC status indicators) ** Remarks: - If you would like to change to the other payment method in Start Payment page (Fig. 4.2), press “Change payment method”.
  • Page 9 Cardholder’s signature is required under these situations: i. Depends on card type. ii. If amount is exceed the limit. Under these situations, the APP will go to Signature page (Fig. 4.7). To sign on white area and then press “Con rm”. Sign here Con rm Fig.
  • Page 10 Microsoft Corporation in the United States and/or other countries. The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by BBPOS Limited is under license. Other trademarks and trade names are those of their respective owners. All details are subject to change without prior notice.
