BT NEXT PRO
P O C K E T G U I D E
Frequency: 2.4GHz - Max power: 100Mw
E NGLIS H

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BT NEXT PRO and is the answer not in the manual?

Questions and answers

Related Manuals for Midland BT NEXT PRO

Summary of Contents for Midland BT NEXT PRO

  • Page 1 BT NEXT PRO P O C K E T G U I D E Frequency: 2.4GHz - Max power: 100Mw E NGLIS H...

  • Page 2: Operation

    ON/OFF CONTROLS DESCRIPTION - LEGENDA Vol - Vol+ Button 3 Button 2 Button 1 LEGENDA OPERATION VISUAL FEEDBACK X” Blue led blinking Press X seconds Red led blinking Press x times Red/blue led blinking AUDIO FEEDBACK Purple led Sound alert Steady blue led Musical sound alert Steady red led...
  • Page 3 POWER ON Press 3 seconds 3” Blinking Musical sound alert Operating mode status Battery status POWER OFF Press 3 seconds at the same time 3” Blinking Musical sound alert...
  • Page 4 CONFERENCE Pairing to: Pairing to: MUSIC SHARE • Midland unit • Midland unit • Different brand unit Pairing to a Midland unit • Different brand unit (Universal Intercom) (passenger) (Universal Intercom) TO ENTER SETUP MODE TO EXIT SETUP MODE/INTERRUPT THE PAIRING...
  • Page 5 Status: Both units in setup mode Press 3 seconds (start procedure on both units at the same time) 3” Blinking Steady 1 second, pairing successful Steady, pairing complete Note: To pair other Midland units, follow the same procedure but press buttons 1 or 3.
  • Page 6 PAIRING TO A DIFFERENT BRAND UNIT Status: Setup mode 1st Unit Press 7 seconds (start procedure on both units at the same time) 7” Blinking fast (keep pressed) Blinking slowly (release) Steady, pairing complete 2nd Unit Follow the “phone” pairing procedure Note: to pair another Universal Intercom, follow the same procedure but press Button 3.
  • Page 7 PAIRING 4 UNITS IN CONFERENCE Status: Setup mode 7” 3” 3” 3” Note: the Conference mode allows the simultaneous communication amongst units. All units must be paired in a “chain” configuration: the Backwards button of the first unit must be paired to the Forwards button of the second unit and so on.
  • Page 8 PAIRING TO A PHONE/GPS Status: Setup mode Press 3 seconds Blinking Select device on the phone Steady 1 second, pairing successful Note: the unit paired to Vol- is in background to the 7” 3” 3” 3” intercom. To pair the unit and interrupt the intercom, repeat the procedure but press Vol+.

  • Page 9: To Change The Operating Mode

    OPERATING MODES A. Intercom mode: to talk to another unit. B. Phone mode: phone calls or manage music. C. FM radio mode: to listen to, seek and store FM radio stations. Note: Intercom and phone modes are possible only when the units are paired. TO CHANGE THE OPERATING MODE Status: Power on Press 3 seconds...
  • Page 10 A. MODALITÀ INTERCOM A. INTERCOM MODE PAIRING DESCRIPTION RIDER 2 (passenger) RIDER 1 RIDER 3 RIDER 4 RIDER 5 (Press 3 seconds (Press 3 seconds Universal Intercom) Universal Intercom) TO OPEN/CLOSE INTERCOM MANUALLY Status: Intercom mode Press once Sound alert Blinking Note: if you have paired another unit, push buttons 1 or 3 to open/close the intercom.
  • Page 11 TO OPEN/CLOSE INTERCOM USING THE VOICE Status: All modes Say “Hello” Sound alert Blinking Mute for 40 sec., 40” intercom is closed Sound alert Note: the voice activation is possible only if the unit is paired to button 2. ENABLING/DISABLING VOX Status: All modes Press 7 seconds 7”...
  • Page 12 TO OPEN/CLOSE UNIVERSAL INTERCOM Status: Intercom mode Press 3 seconds activates Universal intercom 3” Blinking Sound alert Press once to deactivate Universal Intercom Note: to open/close the audio from a different brand unit, use the voice dial command (for some models you have to send the command twice) Note: if you have another device as Universal Intercom, follow the same procedure but press button 3.
  • Page 13 TO ENABLE/DISABLE CONFERENCE Status: Intercom mode Press 7 seconds enables/disables Conference 7” Sound alert Conference status...
  • Page 14 TO OPEN/CLOSE CONFERENCE Status: Conference Press once opens/closes Conference to the unit paired to button 1 Press once opens Conference to all units paired Press once opens/closes Conference to unit paired to button 3 Note: The device paired to Vol+ is temporary discon- nected, while the one paired to Vol- is still active.
  • Page 15 B. PHONE MODE CONTROLS DESCRIPTIONS (Phone paired on Vol+) (Phone paired on Vol-) • Make a call • Make a call • Answer a call • Answer a call • End a call • End a call • Reject a call •...
  • Page 16 MUSIC Status: phone mode Select a music APP Press once Play/Pause Press once Song forward Press once Song backward 3” Press 3 seconds activates/interrupts music sharing with passenger (Music Share) SHORTCUT - Music Play/pause in Intercom/FM radio mode: press twice button 2.
  • Page 17 REMOTE MUSIC CONTROL VOL+/VOL- Status: all modes 3” Press 3 seconds Remote control Vol+/Vol- Note: if you have paired two multi-media devices, to control the music of the device paired on Vol-, you have to set the music control from Vol-; while to con- trol the music of the device paired on Vol+, set the music control from Vol+.

  • Page 18: Fm Radio Mode

    C. FM RADIO MODE CONTROLS DESCRIPTION Radio station up Memory up Radio station down Memory down FM radio On/Off...
  • Page 19 FM RADIO Status: FM Radio mode Press once On/Off Radio station up 3” Memory up Radio station down 3” Memory down...
  • Page 20 Vertrieb durch: BIHR S.A.S. www.bihr.eu. Vor Benutzung Bedienungsanleitung beachten. Importado por: MIDLAND IBERIA, SA. C/Cobalt, 48 - 08940 Cornellà de Llobregat, Barcelona - España. Antes de utilizar, lea atentamente el manual de uso. Distributed by: BIKEIT.
