Canon EF35mm f/2 IS USM Instructions

CT1-8586-002
EF35mm f/2 IS USM
Nomenclature
① ●
Distance scale
● ②
Distance index
● ③
Focusing ring
● ④
Focus mode switch
● ⑤
Image Stabilizer switch
⑥ ●
Lens mount index
⑦ ●
Contacts
nk you for purchasing a Canon product.
5mm f/2 IS USM is a wide-angle single focus lens that provide high image quality.
S" stands for Image Stabilizer.
USM" stands for Ultrasonic Motor.
Safety Precautions
Do not look at the sun or a bright light source through the lens or camera. Doing so could result in loss of
vision.
Looking at the sun directly through the lens is especially hazardous.
Whether it is attached to the camera or not, do not leave the lens under the sun without the lens cap
attached. This is to prevent the lens from concentrating the sun's rays, which could cause a fire.
❶ ●
ndling Cautions
f the lens is taken from a cold environment into a warm one, condensation may develop on the lens
surface and internal parts. To prevent condensation in this case, first put the lens into an airtight plastic bag
before taking it from a cold to warm environment. Then take out the lens after it has warmed gradually. Do the
ame when taking the lens from a warm environment into a cold one.
Do not leave the lens in excessive heat such as in a car in direct sunlight. High temperatures can cause the
ens to malfunction.
nventions used in this instruction
Warning to prevent lens or camera malfunction or damage.
Supplementary notes on using the lens and taking pictures.
your camera's instructions for details on mounting and detaching the lens.
●
After detaching the lens, place the lens with the rear end up to prevent the lens surface and contacts from
getting scratched.
●
If the contacts get soiled, scratched, or have fingerprints on them, corrosion or faulty connections can result.
The camera and lens may not operate properly.
●
If the contacts get soiled or have fingerprints on them, clean them with a soft cloth.
● If you remove the lens, cover it with the dust cap. To attach it properly, align the lens mount index and the ○
● ❶
index of the dust cap, and turn clockwise
etting the Focus Mode
● ❷
hoot in autofocus (AF) mode, set the focus mode switch to AF ❷.
hoot in manual focus (MF) mode, set the focus mode switch to MF, and focus by turning the focusing ring. The
sing ring always works, regardless of the focus mode ❸.
After autofocusing in ONE SHOT AF mode, focus manually by pressing the shutter button halfway and turning
the focusing ring. (Full-time manual focus)
nfinity Compensation Mark
ompensate for shifting of the infinity focus point that results from changes in temperature.
infinity position at normal temperature is the point at which the vertical line of the distance scale L mark is aligned
the distance index ❹.
For accurate manual focusing of subjects at infinity, look through the viewfinder or look at the magnified image*
on the LCD screen while rotating the focusing ring.
r cameras with Live View shooting capability.
mage Stabilizer
can use the Image Stabilizer in AF or MF mode.
function provides optimal image stabilization depending on shooting conditions
h as shooting still subjects and following shots).
et the STABILIZER switch to ON ❺.
you are not going to use the image stabilizer function, set the switch to OFF.
● ❷
ake sure the image in the viewfinder is stable, then press the shutter button the rest of the way down to take the
cture.
●
The Image Stabilizer cannot compensate for a blurred shot caused by a subject that moved.
❸ ●
●
The Image Stabilizer may not be fully effective if you shoot from a violently shaking vehicle or other
transportation.
●
The Image Stabilizer consumes more power than normal shooting, so fewer shots can be taken if you use
the function.
●
When shooting a still subject, it compensates for camera shake in all directions.
●
It compensates for vertical camera shake during following shots in a horizontal direction, and compensates
for horizontal camera shake during following shots in a vertical direction.
●
When you use a tripod, the Image Stabilizer should be turned off to save battery power.
●
The stabilizer is equally effective for handheld photography and photography with a monopod. The Image
Stabilizer effect may be reduced, however, depending on the shooting environment.
●
The Image Stabilizer also operates when the lens is used with extension tube EF12 II or EF25 II.
●
If you set the camera's Custom Function to change the assigned button to operate the AF, the Image
Stabilizer will operate when you press the newly assigned AF button.
ood (Sold Separately)
EW-72 hood can keep unwanted light out of the lens, and also protects the lens from rain, snow, and dust.
ttach the hood, align the hood's attachment position mark with the red dot on the front of the lens, then turn the
d in the direction of the arrow until the lens's red dot is aligned with the hood's stop position mark ❻.
emove the hood, hold down the button on the side and turn the hood in the direction of the arrow until the position
k on the hood aligns with the red dot ❼.
● ❸
hood can be reverse-mounted on the lens for storage.
●
Part of the picture may be blocked if the hood is not attached properly.
●
When attaching or detaching the hood, grasp the base of the hood to turn it. To prevent deformation, do not
● ❹
grasp the rim of the hood to turn it.
Infinity compensation mark
ilters (Sold Separately)
can attach filters to the filter mounting thread on the front of the lens.
Repère de compensation d'infini
●
Only one filter may be attached.
●
Use a polarizing Canon filter (67mm).
Unendlich-Markierung
●
To adjust the polarizing filter, first remove the lens hood.
Marca de Compensación de Infinito
xtension Tubes (Sold Separately)
can attach extension tube EF12 II or EF25 II for magnified shots. For shooting distance and magnification, see
Contrassegno compensazione infinito
extension tube specifications.
MF mode is recommended for accurate focusing.
he extenders cannot be used with this lens.
he close-up lenses cannot be used with this lens.
ASE (Sold Separately) LP1116
s device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This
1305SZ © CANON INC. 2012
2.3 6.5
PRINTED IN JAPAN
