HD Color Video Camera
設置説明書
Installation Manual
Manuel d'installation
Manual de instalación
お買い上げいただきありがとうございます。
電気製品は、 安全のための注意事項を守らないと、 火災や人身事故にな
ることがあります。
この設置説明書には、 事故を防ぐための重要な注意事項と製品の取り扱いかたを示し
てあります。この設置説明書をよくお読みのうえ、 製品を安全にお使いください。お読
みになったあとは、 いつでも見られるところに必ず保管してください。
SRG-120DU
© 2015 Sony Corporation
Printed in China
4-576-960-02(1)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SRG-120DU and is the answer not in the manual?

Questions and answers

Related Manuals for Sony SRG-120DU

Summary of Contents for Sony SRG-120DU

  • Page 1 4-576-960-02(1) HD Color Video Camera 設置説明書 Installation Manual Manuel d’installation Manual de instalación お買い上げいただきありがとうございます。 電気製品は、 安全のための注意事項を守らないと、 火災や人身事故にな ることがあります。 この設置説明書には、 事故を防ぐための重要な注意事項と製品の取り扱いかたを示し てあります。この設置説明書をよくお読みのうえ、 製品を安全にお使いください。お読 みになったあとは、 いつでも見られるところに必ず保管してください。 SRG-120DU © 2015 Sony Corporation Printed in China...
  • Page 2 前面 / Front / Avant / Delante 背面 / Rear / Arrière / Detrás 底面 / Bottom / Dessous / Abajo...
  • Page 3            = 4.5 mm 〜 7 mm (  = 0.18 inches 0.27 inches) (  = 0,18 pouce 0,27 pouce) (  = 0,18 pulgadas 0,27 pulgadas) ネジ M3 fixing screw Vis de fixation M3 Tornillo de fijación M3 ...

  • Page 4: About The Manuals

    The green lamp lights when the camera is connected to an AC outlet using the supplied Sony product; AC adapter MPA-AC1 (hereafter referred to as the AC adapter) and AC power cord. It takes about 15 to 30 seconds to display the image after the lamp lights.
  • Page 5  VISCA OUT connector (mini DIN 8-pin, female) When you connect multiple cameras, connect it to the VISCA IN connector of the next camera in the daisy chain connection. Pin No. Function Pin No. Function DTR OUT RXD OUT DSR OUT TXD OUT No connection No connection...

  • Page 6: Zoom Buttons

    Note Press the MANUAL button and adjust the focus manually when shooting the following objects. ˎ ˎ White walls and other objects without contrast ˎ ˎ Objects behind glass ˎ ˎ Objects with horizontal stripes ˎ ˎ Objects on which bright lights are cast or reflected ˎ...

  • Page 7: Connecting Multiple Cameras

    Notes ˎ ˎ To obtain the VISCA cable, consult your Sony dealer. For detailed information on how to connect the camera and the VISCA command list, consult your Sony dealer or Sony Service Center. ˎ ˎ In the case of a VISCA RS-232 connection, make sure that the BOTTOM switch is set to OFF (VISCA (RS-232 serial control)).

  • Page 8: Installing The Camera Using The M3 Fixing Screw Holes

    To obtain the highest performance, it is recommended to setup a computer with a built-in chipset, not with ExpressCard. The ExpressCard-based USB3.0 host may result in lower performance. Supplied accessories AC adapter MPA-AC1 (Sony product) (1), AC power cord (1), Infrared remote commander (1), Safety Regulations (1), Installation Manual (this document) (1 set)
