Equalized monitor power amp

Advertisement

Quick Links

This symbol is intended to
alert the user to the pres-
ence of uninsulated "dan-
RISK OF ELECTRIC SHOCK
gerous voltage" within the
product's enclosure that may be of suf-
ficient magnitude to constitute a risk of
electric shock to persons.
IMPORTANT! FOR YOUR PROTECTION, PLEASE READ THE FOLLOWING:
WATER AND MOISTURE: Appliance should not be used near water (near a bathtub, washbowl,
kitchen sink, laundry tub, in a wet basement, or near a swimming pool, etc). Care should be taken
so that objects do not fall and liquids are not spilled into the enclosure through openings.
POWER SOURCES: The product should be connected to a power supply only of the type described
in the operating instructions or as marked on the appliance.
GROUNDING OR POLARIZATION: Precautions should be taken so that the grounding or polar-
ization is not defeated.
POWER CORD PROTECTION: Power supply cords should be routed so that they are not likely
to be walked on or pinched by items placed upon or against them, paying particular attention
to cords at plugs, convenience receptacles, and the point where they exit from the appliance.
SERVICING: The user should not attempt to service the appliance beyond that described in the
operating instructions. All other servicing should be referred to qualified service personnel.
FUSING: If your unit is equipped with a fuse receptacle, replace only with the same type fuse.
Refer to replacement text on the unit for correct fuse type.

SAFETY INSTRUCTIONS (EUROPEAN)

The conductors in the AC power cord are colored in accordance with the following code.
GREEN & YELLOW—Earth
U.K. MAIN PLUG WARNING: A molded main plug that has been cut off from the cord is
unsafe. NEVER UNDER ANY CIRCUMSTANCES SHOULD YOU INSERT A DAMAGED
OR CUT MAIN PLUG INTO A POWER SOCKET.

REPLACEMENT PARTS LIST

Parts list for HT760M Power Amplifier
Binding Post, 2-way, Red/Black .................................................03-10450
Cover, Black 18GA Steel ............................................................10-82005
Chassis ......................................................................................10-07509
Fan, 24VDC 80mm.....................................................................70-02408
Fan Guard, 80x80mm ................................................................03-90080
Handle, 2-space rack .................................................................10-11120
Knob, Black, 1.25" DIA ..............................................................07-09001
Stand-off, Al, 1.5" Hex, 6-32......................................................03-63315
Toroid insulator pad 3.8" OD .....................................................03-15004
Front cover .............................................................................10-07501-2
Rear label ..................................................................................77-07508
Power cord (120V) ....................................................................05-01603
Power cord (230V) ....................................................................05-01903
10 Amp Circuit breaker (120V) ..................................................70-28110
6 Amp Circuit breaker (230V) ....................................................70-28106
Toroid (120V) ............................................................................15-75160
Toroid (230V) ............................................................................15-75260
C1, Capacitor 10KµF 63V, Poly 20% .........................................42-10363
C2B, Capacitor 10KµF 63V, Poly 20%.......................................42-10363
R30, 1/4W Resistor 47K, .35" prep. 5% Carbon......................50-47045
Parts list for Printed Cicuit Card
Ref. Des. Description
A1
IC Op Amp NE5532
Linear Output
A2
IC Op Amp MC4558
CP1 Dual HFREQ
A3
IC Op Amp NE5532
Linear Output
A4
IC Op Amp NE5532
Linear Output
A5
IC Op Amp MC4558
CP1 Dual HFREQ
A6
IC Op Amp MC4558
CP1 Dual HFREQ
A7
IC Op Amp MC4558
CP1 Dual HFREQ
A8
IC Op Amp NE5532
Linear Output
BP1
Binding Post Red/Black Combo
BP2
Binding Post Red/Black Combo
BR1
Diode Bridge AC/DC PCB MTG
C3
Capacitor 1000µF 35V
Electrolytic 20%
C4
Capacitor 1000µF 35V
Electrolytic 20%
C5
Capacitor 0.047µF 100V
Poly 10%
C6
Capacitor 0.047µF 100V
Poly 10%
C7
Capacitor 220µF 50V
Electrolytic 20%
C8
Capacitor 10µF 50V
Electrolytic 20%
C9
Capacitor 0.047µF 100V
Poly 10%
C10
Capacitor 0.047µF 100V
Poly 10%
C11
Capacitor 0.047µF 100V
Poly 10%
C15
Capacitor 0.047µF 100V
Poly 10%
C16
Capacitor 0.047µF 100V
Poly 10%
C17
Capacitor 0.047µF 100V
Poly 10%
C18
Capacitor 470µF 25V
Electrolytic 20%
C100
Capacitor 27PF 500V
Ceramic 5%
C101
Capacitor 27PF 500V
Ceramic 5%
C102
Capacitor 22µF 50V
Electrolytic 20%
C104
Capacitor 27PF 500V
Ceramic 5%
C105
Capacitor 0.047µF 100V
Poly 10%
C110
Capacitor 0.001µF 100V
Poly 10%
C111
Capacitor 22µF 50V
Electrolytic 20%
C115
Capacitor 27PF 500V
Ceramic 5%
C116
Capacitor 56PF 500V
Ceramic 5%
C117
Capacitor 120PF 500V
Ceramic 5%
C118
Capacitor 10µF 63V
Electrolytic 20%
C119
Capacitor 0.047µF 100V
Poly 10%
C120
Capacitor 0.001µF 100V
Poly 10%
C121
Capacitor 0.068µF 100V
Poly 10%
C200
Capacitor 27PF 500V
Ceramic 5%
C201
Capacitor 27PF 500V
Ceramic 5%
C202
Capacitor 22µF 50V
Electrolytic 20%
C204
Capacitor 27PF 500V
Ceramic 5%
C205
Capacitor 0.047µF 100V
Poly 10%
C210
Capacitor 0.001µF 100V
Poly 10%
C211
Capacitor 22µF 50V
Electrolytic 20%
C215
Capacitor 27PF 500V
Ceramic 5%
C216
Capacitor 56PF 500V
Ceramic 5%
C217
Capacitor 120PF 500V
Ceramic 5%
C218
Capacitor 0.047µF 100V
Poly 10%
C219
Capacitor 0.047µF 100V
Poly 10%
C220
Capacitor 0.001µF 100V
Poly 10%
C221
Capacitor 0.068µF 100V
Poly 10%
This symbol is
CAUTION
intended to alert the
user to the presence of
important operating
DO NOT OPEN
and maintenance (servicing) instruc-
tions in the literature accompanying
the appliance.
BLUE—Neutral
BROWN—Live
Carvin P/N
Ref. Des. Description
D1
Diode 1N4003
Rect Gen 1A 200V
D2
Diode 1N4003
Rect Gen 1A 200V
D3
Diode 1N4003
Rect Gen 1A 200V
D4
Diode 1N4003
Rect Gen 1A 200V
D5
Diode 1N4003
Rect Gen 1A 200V
D6
Diode 1N4003
Rect Gen 1A 200V
D7
Diode 1N4003
Rect Gen 1A 200V
D8
LED Red small
#204HD 3mm T-1.0
D9
LED Yellow small #204YD 3mm T-1.0
D10
Diode 1N4003
Rect Gen 1A 200V
D11
Diode 1N4003
Rect Gen 1A 200V
D12
Diode 1N4003
Rect Gen 1A 200V
D13
Diode 1N4003
Rect Gen 1A 200V
D100
Diode 1N4003
Rect Gen 1A 200V
D101
Diode 1N4003
Rect Gen 1A 200V
D102
LED Green small #204GD 3mm T-1.0
D103
LED Red small
#204HD 3mm T-1.0
D104
LED Red small
#204HD 3mm T-1.0
D106
Diode 1N4003
Rect Gen 1A 200V
D107
Diode 1N4003
Rect Gen 1A 200V
D108
Diode 1N4003
Rect Gen 1A 200V
D109
Diode 1N4003
Rect Gen 1A 200V
Carvin P/N
D200
Diode 1N4003
Rect Gen 1A 200V
60-55320
D201
Diode 1N4003
Rect Gen 1A 200V
60-45580
D202
LED Green small #204GD 3mm T-1.0
60-55320
D203
LED Red small
#204HD 3mm T-1.0
60-55320
D204
LED Red small
#204HD 3mm T-1.0
60-45580
D205
Diode 1N4003
Rect Gen 1A 200V
60-45580
D206
Diode 1N4003
Rect Gen 1A 200V
60-45580
D207
Diode 1N4003
Rect Gen 1A 200V
60-55320
D208
Diode 1N4003
Rect Gen 1A 200V
03-10400
D209
Diode 1N4003
Rect Gen 1A 200V
03-10400
H1-A
Header 4 Pin AMP 9A 600V PCB MTG
60-35041
H1-B
Header 4 Pin AMP 9A 600V PCB MTG
47-10235
H2
Header 2 Pin Vert Panduit PCB MTG
47-10235
H2-A
Header 4 Pin Vert SHS 2.5mm PCB MTG
46-47312
H2-B
Header 4 Pin Vert SHS 2.5mm PCB MTG
46-47312
H3-A
Header 10 Pin Vert SHS 2.5mm PCB MTG
47-22151
H3-B
Header 10 Pin Vert SHS 2.5mm PCB MTG
47-10051
H4-A
Header 10 Pin Vert SHS 2.5mm PCB MTG
46-47312
H4-B
Header 10 Pin Vert SHS 2.5mm PCB MTG
46-47312
H5
Header 2 Pin Vert Panduit PCB MTG
46-47312
H6-A
Header 4 Pin AMP 9A 600V PCB MTG
46-47312
H6-B
Header 4 Pin AMP 9A 600V PCB MTG
46-47312
H7
Header 9 Pin AMP 9A 600V PCB MTG
46-47312
J100
XLR Jack Female Neutrik Vert PCB MTG
47-47125
J101
Phone Jack, 1/4" 7 Pin Plastic, 24mm Tall
45-27052
J102
Phone Jack, 1/4" 3 Pin Plastic, 24mm Tall
45-27052
J200
XLR Jack Female Neutrik Vert PCB MTG
47-22051
J201
Phone Jack, 1/4" 7 Pin Plastic, 24mm Tall
45-27052
J202
Phone Jack, 1/4" 3 Pin Plastic, 24mm Tall
46-47312
K100
Relay 24V12A SPDT SIEMENS PCB MGT
46-10212
K200
Relay 24V12A SPDT SIEMENS PCB MGT
47-22051
L100
Inductor 3.3µH Air Core Spool
45-27052
L200
Inductor 3.3µH Air CoreSpool
45-56052
OP1
Opto Isolator VTL5C2
45-12052
OP2
Opto Isolator VTL5C2
47-10061
P100
Pot. B10Kx2 41Clk Brkt Rot Knurled 90°
46-47312
P101
Pot. Trimmer 5K Vert PCB MTG
46-10212
P200
Pot. B10Kx2 41Clk Brkt Rot Knurled 90°
46-68312
P201
Pot. Trimmer 5K Vert PCB MTG
45-27052
Q1
Transistor Darlington NPN MPSA14
45-27052
Q2
Transistor 2N5400 PNP AMP TO-92
47-22051
Q100
Transistor Darlington NPN MPSA14
45-27052
Q101
Transistor TIP31C 3A 100V NPN TO-220
46-47312
Q102
Transistor MPSW42 HV 1.0W NPN T0-237
46-10212
Q103
Transistor CENW92 HV PNP 1.0W TO-92
47-22051
Q104
Transistor TIP32C 3A 100V PNP TO-220
45-27052
Q105
Transistor TIP31C 3A 100V NPN TO-220
45-56052
Q106
Transistor TIP31C 3A 100V NPN TO-220
45-12052
Q107
Transistor MJL21194 NPN 16A 250V 200W
46-47312
Q108
Transistor MJL21194 NPN 16A 250V 200W
46-47312
Q109
Transistor MJL21193 PNP 16A 250V 200W
46-10212
Q110
Transistor MJL21193 PNP 16A 250V 200W
46-68312
LIMITED WARRANTY
Your Carvin product is guaranteed against failure for ONE YEAR unless otherwise stated. Carvin
will service and supply all parts at no charge to the customer providing the unit is under warranty.
Shipping costs are the responsibility of the customer. CARVIN DOES NOT PAY FOR PARTS OR SER-
VICING OTHER THAN OUR OWN. A COPY OF THE ORIGINAL INVOICE IS REQUIRED TO VERIFY
YOUR WARRANTY. Carvin assumes no responsibility for horn drivers or speakers damaged by this
unit. This warranty does not cover, and no liability is assumed, for damage due to: natural disasters,
accidents, abuse, loss of parts, lack of reasonable care, incorrect use, or failure to follow instruc-
tions. This warranty is in lieu of all other warranties, expressed or implied. No representative or person
is authorized to represent or assume for Carvin any liability in connection with the sale or servicing
of Carvin products. CARVIN SHALL NOT BE LIABLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES.
When RETURNING merchandise to the factory, you may call for a return authorization number.
Describe in writing each problem. If your unit is out of warranty, you will be charged the current
FLAT RATE for parts and labor to bring your unit up to factory specifications.
HELP SECTION

1) WILL NOT TURN ON

Check the power to the unit. Check for tripped main circuit breakers, unplugged extension cords
or power-strip switches that may be turned off. Check the amps circuit breaker on the rear panel.
If the black curved center button is in the out position, push it in to reset. If the breaker contin-
ues to trip, check your speaker cables and total speaker impedance. If the amps circuit breaker
will not reset, then the amp will require servicing.

2) MAINTAINING YOUR EQUIPMENT

Avoid spilling liquids or allowing any other foreign matter inside the unit. The panel of your unit can
be wiped from time to time with a dry or slightly damp cloth in order to remove dust and bring back
the new look. As with all pro gear, avoid prolonged use in caustic environments (salt air). When
used in such an environment, be sure the amplifier is adequately protected by rack, covers, etc..
CAUTION
RISK OF ELECTRIC SHOCK
Carvin P/N
Ref. Des. Description
60-40030
Q200
Transistor Darlington NPN MPSA14
60-40030
Q202
Transistor MPSW42 HV 1.0W NPN T0-237
60-40030
Q203
Transistor CENW92 HV PNP 1.0W TO-92
60-40030
Q204
Transistor TIP32C 3A 100V PNP TO-220
60-40030
Q205
Transistor TIP31C 3A 100V NPN TO-220
60-40030
Q206
Transistor TIP31C 3A 100V NPN TO-220
60-40030
Q207
Transistor MJL21194 NPN 16A 250V 200W
60-75320
Q208
Transistor MJL21194 NPN 16A 250V 200W
60-75340
Q209
Transistor MJL21193 PNP 16A 250V 200W
60-40030
Q210
Transistor MJL21193 PNP 16A 250V 200W
60-40030
R1
1/4W Resistor 2.2K
.35" prep. 5% Carbon
60-40030
R2
1/4W Resistor 3.3K
.35" prep. 5% Carbon
60-40030
R3
1/4W Resistor 100K .35" prep. 5% Carbon
60-40030
R4
1/4W Resistor 150Ω .35" prep. 5% Carbon
60-40030
R5
1/4W Resistor 39K
.35" prep. 5% Carbon
60-75330
R6
1/4W Resistor 39K
.35" prep. 5% Carbon
60-75320
R7
1/4W Resistor 470K .35" prep. 5% Carbon
60-75320
R8
1/4W Resistor 470K .35" prep. 5% Carbon
60-40030
R9
1/4W Resistor 22K
.35" prep. 5% Carbon
60-40030
R10
1/4W Resistor 22K
.35" prep. 5% Carbon
60-40030
R11
1/4W Resistor 20K
.35" prep. 5% Carbon
60-40030
R12
1/4W Resistor 6.8K
.35" prep. 5% Carbon
60-40030
R13
1/4W Resistor 2.2M .35" prep. 5% Carbon
60-40030
R14
1/4W Resistor 20K
.35" prep. 5% Carbon
60-75330
R15
1/4W Resistor 10K
.35" prep. 5% Carbon
60-75320
R16
Not Used
60-75320
R17
1/4W Resistor 22K
.35" prep. 5% Carbon
60-40030
R18
1/4W Resistor 1K
.35" prep. 5% Carbon
60-40030
R19
1/4W Resistor 10K
.35" prep. 5% Carbon
60-40030
R20
1/4W Resistor 10K
.35" prep. 5% Carbon
60-40030
R22
1/4W Resistor 5.6K
.35" prep. 5% Carbon
60-40030
R23
1/4W Resistor 470K .35" prep. 5% Carbon
23-08604
R24
1/4W Resistor 10K
.35" prep. 5% Carbon
23-08604
R25
1/4W Resistor 1K
.35" prep. 5% Carbon
23-10002
R26
1/4W Resistor 4.7K
.35" prep. 5% Carbon
23-11004
R28
1/4W Resistor 220Ω .35" prep. 5% Carbon
23-11004
R31
1/4W Resistor 100K .35" prep. 5% Carbon
23-11010
R100
1/4W Resistor 10K
.35" prep. 5% Carbon
23-11010
R101
1/4W Resistor 10K
.35" prep. 5% Carbon
23-11010
R102
1/4W Resistor 22K
.35" prep. 5% Carbon
23-11010
R103
1/4W Resistor 22K
.35" prep. 5% Carbon
23-10002
R104
1/4W Resistor 2.2K
.35" prep. 5% Carbon
23-08604
R105
1/4W Resistor 220Ω .35" prep. 5% Carbon
23-08604
R106
1/4W Resistor 470K .35" prep. 5% Carbon
23-08609
R107
1/4W Resistor 470K .35" prep. 5% Carbon
21-40000
R108
1/4W Resistor 1K
.35" prep. 5% Carbon
21-06457
R109
Not Used
21-06453
R110
1/4W Resistor 470K .35" prep. 5% Carbon
21-40000
R111
1/4W Resistor 470Ω .35" prep. 5% Carbon
21-06457
R112
1/4W Resistor 1.5K
.35" prep. 5% Carbon
21-06453
R115
1/4W Resistor 10K
.35" prep. 5% Carbon
70-05712
R116
1/4W Resistor 10K
.35" prep. 5% Carbon
70-05712
R117
1/4W Resistor 2.2K
.35" prep. 5% Carbon
15-00165
R118
1/4W Resistor 47K
.35" prep. 5% Carbon
15-00165
R119
1/4W Resistor 4.7K
.35" prep. 5% Carbon
60-50253
R120
1/4W Resistor 100Ω .35" prep. 5% Carbon
60-50253
R121
1/4W Resistor 100Ω .35" prep. 5% Carbon
71-10301
R122
1/4W Resistor 4.7K
.35" prep. 5% Carbon
71-25000
R123
1/4W Resistor 680Ω .35" prep. 5% Carbon
71-10301
R124
1/4W Resistor 4.7K
.35" prep. 5% Carbon
71-25000
R125
1/4W Resistor 2.2K
.35" prep. 5% Carbon
60-00014
R126
1/4W Resistor 1K
.35" prep. 5% Carbon
60-54000
R127
1/4W Resistor 680Ω .35" prep. 5% Carbon
60-00014
R128
1/4W Resistor 2.2K
.35" prep. 5% Carbon
60-31000
R129
1/2W Resistor 4.7Ω 0.5 prep. 5% Carbon
60-00042
R130
1/4W Resistor 150Ω .35" prep. 5% Carbon
60-00092
R131
1/2W Resistor 4.7Ω 0.5 prep. 5% Carbon
60-32000
R132
5W Resistor 0.22Ω Vert 5% Sand Bar
60-31000
R133
5W Resistor 0.22Ω Vert 5% Sand Bar
60-31000
R134
5W Resistor 0.22Ω Vert 5% Sand Bar
60-21194
R135
5W Resistor 0.22Ω Vert 5% Sand Bar
60-21194
R136
1/4W Resistor 1K
.35" prep. 5% Carbon
60-21193
R137
1/4W Resistor 10K
.35" prep. 5% Carbon
60-21193
R138
1/4W Resistor 100K .35" prep. 5% Carbon
REFER SERVICING TO QUALIFIED SER-
VICE PERSONNEL! THIS UNIT CON-
TAINS HIGH VOLTAGE INSIDE!
Carvin P/N
Ref. Des. Description
60-00014
R139
1/4W Resistor 100K .35" prep. 5% Carbon
60-00042
R140
1/4W Resistor 33K
.35" prep. 5% Carbon
60-00092
R144
2W Resistor 10Ω
0.8 prep. 5% Metal
60-32000
R150
2W Resistor 10Ω
0.8 prep. 5% Metal
60-31000
R200
1/4W Resistor 10K
.35" prep. 5% Carbon
60-31000
R201
1/4W Resistor 10K
.35" prep. 5% Carbon
60-21194
R202
1/4W Resistor 22K
.35" prep. 5% Carbon
60-21194
R203
1/4W Resistor 22K
.35" prep. 5% Carbon
60-21193
R204
1/4W Resistor 2.2K
.35" prep. 5% Carbon
60-21193
R205
1/4W Resistor 220Ω .35" prep. 5% Carbon
50-22035
R206
1/4W Resistor 470K .35" prep. 5% Carbon
50-33035
R207
1/4W Resistor 470K .35" prep. 5% Carbon
50-10055
R208
1/4W Resistor 1K
.35" prep. 5% Carbon
50-15025
R209
Not Used
50-39045
R210
1/4W Resistor 470K .35" prep. 5% Carbon
50-39045
R212
1/4W Resistor 470Ω .35" prep. 5% Carbon
50-47055
R215
1/4W Resistor 10K
.35" prep. 5% Carbon
50-47055
R216
1/4W Resistor 10K
.35" prep. 5% Carbon
50-22045
R217
1/4W Resistor 2.2K
.35" prep. 5% Carbon
50-22045
R218
1/4W Resistor 47K
.35" prep. 5% Carbon
50-20045
R219
1/4W Resistor 4.7K
.35" prep. 5% Carbon
50-68035
R220
1/4W Resistor 100Ω .35" prep. 5% Carbon
50-22065
R221
1/4W Resistor 100Ω .35" prep. 5% Carbon
50-20045
R222
1/4W Resistor 4.7K
.35" prep. 5% Carbon
50-10045
R223
1/4W Resistor 680Ω .35" prep. 5% Carbon
R224
1/4W Resistor 4.7K
.35" prep. 5% Carbon
50-22045
R225
1/4W Resistor 2.2K
.35" prep. 5% Carbon
50-10035
R226
1/4W Resistor 1K
.35" prep. 5% Carbon
50-10045
R227
1/4W Resistor 680Ω .35" prep. 5% Carbon
50-10045
R228
1/4W Resistor 2.2K
.35" prep. 5% Carbon
50-56035
R229
1/2W Resistor 4.7Ω 0.5 prep. 5% Carbon
50-47055
R230
1/4W Resistor 150Ω .35" prep. 5% Carbon
50-10045
R231
1/2W Resistor 4.7Ω 0.5 prep. 5% Carbon
50-10035
R232
5W Resistor 0.22Ω Vert 5% Sand Bar
50-47035
R233
5W Resistor 0.22Ω Vert 5% Sand Bar
50-22025
R234
5W Resistor 0.22Ω Vert 5% Sand Bar
50-10055
R235
5W Resistor 0.22Ω Vert 5% Sand Bar
50-10045
R236
1/4W Resistor 1K
.35" prep. 5% Carbon
50-10045
R237
1/4W Resistor 10K
.35" prep. 5% Carbon
50-22045
R238
1/4W Resistor 100K .35" prep. 5% Carbon
50-22045
R239
1/4W Resistor 100K .35" prep. 5% Carbon
50-22035
R240
1/4W Resistor 33K
.35" prep. 5% Carbon
50-22025
R244
2W Resistor 10Ω
0.8 prep. 5% Metal
50-47055
R250
2W Resistor 10Ω
0.8 prep. 5% Metal
50-47055
S1
Switch DPDT Push, Vert Small PCB MTG
50-10035
S2
Switch DPDT Push, Vert Small PCB MTG
S3
Switch DPDT Push, Vert Small PCB MTG
50-47055
S4
Switch DPDT Push, Vert Small PCB MTG
50-47025
VR1
Voltage Regulator 7815 +15V 2A
50-15035
VR2
Voltage Regulator 7915 -15V 2A
50-10045
VR3
Voltage Regulator 7915 -15V 2A
50-10045
50-22035
50-47045
50-47035
50-10025
50-10025
50-47035
50-68025
50-47035
50-22035
50-10035
50-68025
50-22035
52-47005
50-15025
52-47005
55-02205
55-02205
55-02205
55-02205
50-10035
50-10045
50-10055
Carvin P/N
50-10055
50-33045
54-10015
54-10015
50-10045
50-10045
50-22045
50-22045
50-22035
50-22025
50-47055
50-47055
50-10035
50-47055
50-47025
50-10045
50-10045
50-22035
50-47045
50-47035
50-10025
50-10025
50-47035
50-68025
50-47035
50-22035
50-10035
50-68025
50-22035
52-47005
50-15025
52-47005
55-02205
55-02205
55-02205
55-02205
50-10035
50-10045
50-10055
50-10055
50-33045
54-10015
54-10015
25-02201
25-02201
25-02201
25-02201
60-78150
60-79150
60-79150

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HT760M and is the answer not in the manual?

Questions and answers

Summary of Contents for CARVIN HT760M

  • Page 1 Care should be taken is authorized to represent or assume for Carvin any liability in connection with the sale or servicing so that objects do not fall and liquids are not spilled into the enclosure through openings.
  • Page 2 SAVE THE CARTON & ALL PACKING MATERIALS. In the event you have to re-ship your unit, always use the original carton and packing material. This will provide the best possible protec- tion during shipment. CARVIN and the shipping company are not liable for any damage caused HT760M by improper packing.
  • Page 3 4. DUAL 9-BAND GRAPHIC EQUALIZERS former between the amplifier input and the signal source. Controling feed-back in a monitor system and fine tuning your sound are easy with the HT760M’s two 12. LIMITERS on-board EQ’s. For feed-back, find the offending frequency (usually in the upper bands) and push the slider down to cut the level of that frequency, thus allowing more gain (volume) before feed-back.
  • Page 4 4 OHMS/CH 375W 2 OHMS/CH MADE INTHE 500W 8 BRIDGED 750W 4 BRIDGED www.carvin.com SERIAL NUMBER www.carvin.com SERIAL NUMBER The channel PARALLEL switch OFF (OUT). For single input operation, push Single speaker or the PARALLEL button IN. system connected in BRIDGE mode.

Table of Contents
