NuTone SENSONIC SS-326G Installation Instructions Manual

Two-Way, Weather Resistant,
Indoor/Outdoor Rock Speaker
Models: SS-326G (Granite), SS-326R (Rust), SS-326C (Canyon)
I
mpedance: 8 Ohms nominal, Power Handling Capacity: 50 Watts RMS
Overall dimensions: 13
Features:
• Meets or exceeds Electronic Industry Association (EIA) standard RS-
426-A for power testing
• 6 1/2" Polypropylene cone woofer and 3/4" Titanium
dome tweeter
• Power handling capacity: 50 Watts RMS
• Weather resistant
• Frequency response: 45-20,000 Hz (-6dB)
• Sensitivity: @ 1 Meter with 1 Watt input: 87 dB
• Nominal Impedance: 8 Ohms
• Stainless steel hardware
• Overload protected
INTRODUCTION
The SS-326G/SS-326R/SS326C are weather resistant, two-way
rock speakers consisting of a 6 1/2" woofer and a 3/4" Titanium
dome tweeter.
SELECTING AN AUDIO AMPLIFIER
Select an amplifier of RMS power rating of 50 Watts or less.
CONNECTING THE AMPLIFIER
It is best to use some type of conduit to run the speaker wires
from the amplifier/receiver inside the house to its location,
outdoors. Choose a convenient location for your speaker so that
it blends well with your landscape. Always observe polarity
while connecting speaker wires to your stereo or A/V receiver.
Make sure there are no frayed, cut or punctured wires.
TESTING THE SYSTEM
When all connections have been completed, play music through
an amplifier and a music source such as a CD player. Initially,
keep the volume control on the amplifier at very low setting.
Keep tone controls, if any, at mid position. Slowly increase the
volume from the amplifier. Sound should be heard from the
speaker(s). If not, refer to the Troubleshooting Guide.
CAUTION: Do not paint the cabinet and/or the grille of your
speaker.
" H " W " D (approx.)
x 12 x 8
READ & SAVE THESE INSTRUCTIONS!
INSTALLATION INSTRUCTIONS
SS-326G
SS-326C
SS-326R
