Linear Technology DC1757A Demo Manual

Ltc3789egn high efficiency 12v/12a buck-boost converter

Advertisement

Quick Links

DESCRIPTION
Demonstration circuit 1757A is a high efficiency syn-
chronous buck-boost DC/DC converter with a 6V to 36V
input voltage range. It can supply a 12A maximum load
current with a 12V output. The demo board features the
LTC
®
3789EGN controller. The constant frequency current
mode architecture allows a phase-lockable frequency of up
to 600kHz, while an optional output current feedback loop
provides support for applications such as battery charging.
With a wide input range, wide output range and seamless
transfers between operation modes, the LTC3789 is ideal
for automotive, telecom, distributed DC power systems
and battery-powered applications.
PERFORMANCE SUMMARY
PARAMETER
Input Voltage Range
Output Voltage, V
OUT
Maximum Output Current, I
Typical Output Ripple
Typical Efficiency
Typical Switching Frequency
QUICK START PROCEDURE
Demonstration circuit 1757A is easy to set up to evalu-
ate the performance of the LTC3789. Refer to Figure 1 for
the proper measurement equipment setup and follow the
procedure below:
1. With power off, connect the input power supply to V
(6V to 36V) and GND (input return).
2. Connect the 12V output load between V
(Initial load: no load).
Arrow.com.
Downloaded from
(T
CONDITIONS
V
= 6V to 36V, I
IN
V
= 6V to 36V, V
OUT
IN
V
= 36V, I
IN
V
= 12V, V
IN
OUT
DEMO MANUAL DC1757A
12V/12A Buck-Boost Converter
The light load operation mode of the converter is de-
termined with the MODE/PLLIN pin. Use JP2 jumper to
select pulse-skipping mode or forced continuous mode
(CCM) operation. The switching frequency is pre-set
at about 200kHz. The converter can also be externally
synchronized to an external clock through the MODE/
PLLIN pin (PLLIN terminal on the board). To shut down
the converter, force the RUN pin below 1.2V (JP1: OFF).
The power good output (PGOOD terminal) is low when the
output voltage is outside of the ±10% regulation window.
Design files for this circuit board are available at
http://www.linear.com/demo
L, LT, LTC, LTM, Linear Technology and the Linear logo are registered trademarks of Linear
Technology Corporation. All other trademarks are the property of their respective owners.
= 25°C)
A
= 0A to 12A
OUT
= 12V
OUT
= 12A (20MHz BW)
OUT
= 12V, I
= 12A
OUT
OUT
3. Connect the DVMs to the input and outputs.
4. Turn on the input power supply and check for the proper
output voltages. V
5. Once the proper output voltages are established, ad-
IN
just the loads within the operating range and observe
the output voltage regulation, ripple voltage and other
and GND
parameters.
LTC3789EGN
High Efficiency
VALUE
6V to 36V
12V ±2%
12A
109mV
P–P
97.9%
200kHz
should be 12V ±2%.
OUT
dc1757af
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the DC1757A and is the answer not in the manual?

Questions and answers

Summary of Contents for Linear Technology DC1757A

  • Page 1 Design files for this circuit board are available at and battery-powered applications. http://www.linear.com/demo L, LT, LTC, LTM, Linear Technology and the Linear logo are registered trademarks of Linear Technology Corporation. All other trademarks are the property of their respective owners. PERFORMANCE SUMMARY = 25°C)
  • Page 2: Quick Start Procedure

    DEMO MANUAL DC1757A QUICK START PROCEDURE Note: When measuring the output or input voltage rip- Additional Notes: ple, do not use the long ground lead on the oscilloscope 1. On DC1757 board, two Coilcraft XAL1010 inductors are probe. See Figure 2 for the proper scope probe technique.
  • Page 3: Parts List

    DEMO MANUAL DC1757A QUICK START PROCEDURE = 6V = 12V = 24V = 36V LOAD CURRENT (A) Figure 3. Efficiency vs load current (V = 12V, CCM) PARTS LIST ITEM REFERENCE PART DESCRIPTION MANUFACTURER/PART NUMBER Required Circuit Components CAP ., C0G, 100pF , 50V, 10% 0603 AVX, 06035A101KAT2A CAP ., X7R, 0.01μF , 50V, 10% 0603...
  • Page 4 DEMO MANUAL DC1757A PARTS LIST L1, L2 Inductor, 1.5μH COILCRAFT, XAL1010-152ME Q2, Q4, Q6 Mosfet N-channel INFINEON, BSC027N04LS G Q3, Q5, Q9 Mosfet N-channel INFINEON, BSC010NE2LS RFB1 RES., CHIP ., 113k, 0.1W, 1% 0603 YAGEO, RC0603FR-07113KL RFB2 RES., CHIP ., 8.06k, 0.1W, 1% 0603...
  • Page 5: Schematic Diagram

    Information furnished by Linear Technology Corporation is believed to be accurate and reliable. However, no responsibility is assumed for its use. Linear Technology Corporation makes no representa- tion that the interconnection of its circuits as described herein will not infringe on existing patent rights.
  • Page 6 Linear Technology Corporation (LTC) provides the enclosed product(s) under the following AS IS conditions: This demonstration board (DEMO BOARD) kit being sold or provided by Linear Technology is intended for use for ENGINEERING DEVELOPMENT OR EVALUATION PURPOSES ONLY and is not provided by LTC for commercial use. As such, the DEMO BOARD herein may not be complete in terms of required design-, marketing-, and/or manufacturing-related protective considerations, including but not limited to product safety measures typically found in finished commercial goods.
