I NS TA L L AT I O N M ANU A L F O R T C M M O DE L S
( C O N VEN I ENC E M E R C H A ND I S E R )
TCM-78AC-GF-SD
(C ON V EN IENC E M ERCHANDISE R )
TCM M ODELS
............ www.truemfg.com ............
2001 East Terra Lane • O'Fallon, Missouri 63366-4434
(636)-240-2400 • FAX (636)272-2408 • INT'L FAX (636)272-7546 • (800)325-6152
Parts Department (800)424-TRUE • Parts Department FAX# (636)272-9471

TABLE OF CONTENTS

Safety Precautions -------------------
Proper Disposal ---------------------
Connecting Electricity ----------------
Adapter Plugs -----------------------
Ownership ------------------------------ 4
Required Tools -------------------------- 4
Uncrating ------------------------------ 4
Location -------------------------------- 5
Leveling Cabinet ------------------------ 5
Conductors and Circuits ------------------- 6
Temperature Control Adjustment ---------- 9
Cleaning Condenser Coil ------------- 10-11
Stainless Steel Equipment Care & Cleaning -12-13
Warranty (U.S.A. & CANADA ONLY!) -------14
CONGRATULATIONS!
You have just purchased the finest commercial
refrigeration available. You can expect many years
of trouble-free operation.
TRUE MANUFACTURING CO., INC.
1
2
3
3
#912629

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TCM-78AC-GF-SD and is the answer not in the manual?

Questions and answers

Related Manuals for True TCM-78AC-GF-SD

Summary of Contents for True TCM-78AC-GF-SD

  • Page 1: Table Of Contents

    (636)-240-2400 • FAX (636)272-2408 • INT’L FAX (636)272-7546 • (800)325-6152 Parts Department (800)424-TRUE • Parts Department FAX# (636)272-9471 I NS TA L L AT I O N M ANU A L F O R T C M M O DE L S...

  • Page 3: Safety Information

    You have selected one of the finest commercial refrigeration units made. It is manufactured under strict quality controls with only the best quality materials available. Your TRUE cooler when properly maintained will give you many years of trouble- free service.

  • Page 4: Risk Of Child Entrapment

    True Food Service Equipment, Inc. SAFETY INFORMATION DANGER! RISK OF CHILD ENTRAPMENT PROPER DISPOSAL OF THE REFRIGERATOR Refrigerant Disposal Child entrapment and suffocation are not problems of the past. Junked or abandoned display cases Your old refrigerator may have a cooling system are still dangerous...

  • Page 5: How To Connect Electricity

    USE OF EXTENSION CORDS / ADAPTER PLUGS TRUE will not warranty any display case that has been connected to an extension cord. Because of potential safety hazards under certain conditions, we strongly recommend against the use of an adapter plug. NEVER USE AN EXTENSION CORD! NEVER USE AN ADAPTER PLUG! NEMA plug confi...

  • Page 6: Installation / Operation Instructions Ownership

    INSTALLATION / OPERATION INSTRUCTIONS OWNERSHIP To ensure that your unit works properly from the Before you start to install your TRUE unit, carefully first day, it must be installed properly. We highly inspect it for freight damage. If damage is...

  • Page 7: Location

    Cabinet warranties are void if OEM power cord is tampered B. Proper leveling of your TRUE cooler is critical to with. TRUE will not warranty any units that are connected to operating success (for non-mobile models). Effective an extension cord.

  • Page 8: Conductors And Circuits

    True Food Service Equipment, Inc. INSTALLATION / OPERATION INSTRUCTIONS CONDUCTORS AND CIRCUITS Wire Gauge for 2% Voltage Drop in Supply Circuits. 115 Volt Distance In Feet To Center of Load Amps 100 120 140 160 Wire Gauge for 2% Voltage Drop in Supply Circuits.

  • Page 9: Electrical Instructions & Start-Up

    Refer to cabinet data plate for this voltage. Do not use electrical appliances inside the food storage TRUE requires that a sole use circuit be dedicated for the compartments of the appliances unless they are of the unit. Failure to do so voids warranty.

  • Page 10: Sealing The Cabinet To The Floor

    After cove base trim has dried, fill in TRUE recommends either of the following methods. cracks and joints with a caulking material. B. Using a vinyl cover base trim as produced by E.
  • Page 11 True Food Service Equipment, Inc. INSTALLATION / OPERATION INSTRUCTIONS TEMPERATURE CONTROL ADJUSTMENT FOR HIGH ALTITUDE ONLY! TERMS: STEP 5 • Cut-out - Temperature sensed by Make sure to reconnect the pink wire the controller that shuts the compres- to the proper spade terminal when sor off.

  • Page 12: Maintenance, Care & Cleaning

    True Food Service Equipment, Inc. MAINTENANCE, CARE & CLEANING CLEANING THE CONDENSER COIL TOOLS REQUIRED: STEP 6 • Phillips Screwdriver After brushing condenser coil vacuum • " Stiff Bristle Brush dirt from coil, and interior floor. • Adjustable Wrench • Vacuum Cleaner...

  • Page 13: Important Warranty Information

    5. When finished be sure to replace the louvered grill. The grill protects the condenser. 6. Reconnect the electrical power to the unit. If you have any questions, please call TRUE Manufacturing at 636-240-2400 or 855-372-1368 for the Service Department. World Headquarters Service Department Availability Monday-Thursday 7:00 a.m. to 7:00 p.m., Friday 7:00 a.m.

  • Page 14: Stainless Steel Equipment Care And Cleaning

    True Food Service Equipment, Inc. MAINTENANCE, CARE & CLEANING STAINLESS STEEL EQUIPMENT CARE AND CLEANING CAUTION: Do not use any steel wool, abrasive or chlorine based products to clean stainless steel surfaces. Stainless Steel Opponents • There are three basic things which can break down your stainless steel’s passivity layer and allow corrosion to rear its ugly head.
  • Page 15 True Food Service Equipment, Inc. MAINTENANCE, CARE & CLEANING STAINLESS STEEL EQUIPMENT CARE AND CLEANING Recommended cleaners for certain situations / environments of stainless steel A) Soap, ammonia and detergent medallion applied with a cloth or sponge can be used for routine cleaning.
  • Page 16 TRUE and upon proper installation and start-up in accordance with the instruction packet supplied with each TRUE unit. TRUE’s obligation under this warranty is limited to a period of three (3) years from the date of original installation or 39 months after shipment date from TRUE, whichever occurs first.
