Kamar L0181 User Manual

User manual
L0181
Work lamp square 16xLED + strap LED
Technical data
• Product dimensions: 108x135mm
• Cable: 250mm
• Working voltage: 12/24V
• Approvals, certificates:
ECE R10, IP67
• Power consumption: 21,5W
• LED quantity: 16+9 LED
• Material of execution:
Housing: AL.
Lens: PC
• Working temperature: from -40°C to +60°C
Functions
• Work light and flood
• For automo ve use only
• LED Headlight is intended for vehicles with 12/24V installation
• Reverse polarity protection
Mounting method
• Installation only in specialized workshops or professional service
• Lamps must be installed only in accordance with the UNECE regulations
Wire connection
FUNCTION
Ground
Work light white
LED strip
Warnings
• Use as intended
• Use in airy places
• Do not touch the lamp during operation and immediately after it is turned off, the lamp may get warm
Any unauthorized interference with the lamp (associated with its depressurization, interference with the electronic system, etc.) is associated with the loss of
•
warranty
• The device must be installed and kept out of reach of children
• Do not cut off tinned ends.
Marking on the product or in the related texts indicates that it should not be disposed of with other household waste at the end of its useful life. To avoid damaging the environment and human health by uncontrolled disposal, please
separate the product from another type of waste and recycle it responsibly to promote the reuse of material resources as a permanent practice. For information on where and how to safely recycle this product, household users should
contact the retailer where they purchased the product. Users in companies should contact their supplier and check the terms of the purchase agreement.The product should NOT be disposed of with other commercial waste.
We reserve the right to change technical data and possible errors. Photos/drawing and
technical data are only illustrative, and given product may slightly differ from them. Coping the
part or the entire package without the written authorization is forbidden. All rights reserved.
WIRES COLOR
Black
Red
Yellow
The connection between the lamp and vehicle's installation should be isolated with heat-shrink
tube, to avoid getting water and moisture to the copper wire of the lamp, which can damage
electronic components and flood the lamp with water.
Important! Do not look directly at the light. It can cause the eye damage
Correct disposal of the product (used electrical and electronic equipment)
Importer: KAMAR Knapkiewicz S.K.A.
Terms of warranty:
- we provide a guarantee for a period of 24 months from the date of sale,
- any unauthorized interference with the item entails the loss of the guarantee.
al. Armii Krajowej 254
85-689 Bydgoszcz, Poland
Country of origin: PRC
www.myKAMAR.com
