Epson WF-2650, WF-2660 Manual

Unpack

Unpack - Step 1
Unpack - Step 2
Note: Do not open ink cartridge packages until you are ready to install the ink. Cartridges are vacuum packed to maintain reliability.

Turn on and configure

Turn on and configure

Select your language, country, date, and time.
Note: You can change these settings later using the product's control panel. For more information, see the online User's Guide.

: Do not connect to your computer yet.

Install ink cartridges

Install ink cartridges
Remove only the yellow tape from each cartridge.

: Don't remove any other seals or the cartridges may leak.
Note:

The printer is designed for use with Epson ® cartridges only, not third party cartridges or ink.
The cartridges included with the printer are designed for printer setup and not for resale. After some ink is used for priming, the rest is available for printing.

Don't turn off the printer while it is priming or you'll waste ink.

Load paper

Connect the fax line

Connect a phone cord to a telephone wall jack and to the LINE port on your product. See the online User's Guide for more information.
Press (WF-2650) or Start (WF-2660) if you want to set up the fax, or press (WF-2650) or Close (WF-2660) to set it up later.

Install software

Note: If your computer does not have a CD/DVD drive or you are using a Mac, an Internet connection is required to obtain the printer software.

Make sure the printer is NOT CONNECTED to your computer.
Windows ®: If you see a Found New Hardware screen, click Cancel and disconnect the USB cable.
Insert the product CD

Follow the instructions on the screen to run the setup program. OS X: Make sure you install Software Updater to receive firmware and software updates for your product.
When you see the Select Your Connection screen, select one of the following:

Wireless connection Make sure you know your network name (SSID) and network password.
Direct USB connection Make sure you have a USB cable (not included).
Wired network connection (WF-2660) Make sure you have an Ethernet cable (not included).

When software installation is complete, restart your computer.

Any problems

Network setup was unsuccessful.

Make sure you select the right network name (SSID). The printer can only connect to a network that supports 2.4 GHz.
If you see a firewall alert message, click Unblock or Allow to let setup continue.
If your network has security enabled, make sure you enter your network password (WEP key or WPA passphrase) correctly. Password must be entered in the correct case.

There are lines or incorrect colors in my printouts.
Run a nozzle check to see if any of the print head nozzles are clogged. Then clean the print head, if necessary. See the online User's Guide for more information.

The printer's screen is dark.
Make sure your product is turned on and press any button to wake it from sleep mode.

Setup is unable to find my printer after connecting it with a USB cable.
Make sure it is securely connected as shown:
