Privacy Vinyl Fence Kit
INSTALLATION INSTRUCTIONS
• English .............................................................................. 1
• Français ............................................................................ 10
• Español ............................................................................. 19
barretteoutdoorliving.com
BOM-34106808
Advertisement
Related Manuals for Barrette BOM-34106808
Summary of Contents for Barrette BOM-34106808
- Page 1 BOM-34106808 Privacy Vinyl Fence Kit INSTALLATION INSTRUCTIONS • English ................1 • Français ................10 • Español ................19 Read all instructions prior to installing product. Refer to manufacturers safety instructions when operating any tools. barretteoutdoorliving.com To register your product, please visit:...
-
Page 2: Before You Begin
WARNING: • Improper installation of this product can result in personal injury. Always wear safety goggles when cutting, drilling and assembling the product. • Incorrect installation may cause harm to the product or individual. • Check local building codes to determine pool-safe fencing options. NOTICE: •... - Page 3 Mark the fence location using string and line Fig. 1 stakes (Fig. 1). NOTE: Plan gate placement, opening and hardware clearance before installing fencing. Post Location: Fig. 2 Measure the width of the fence panel (X) plus the width of the post (Y). This is the common center- to-center measurement (unless there is a cut-down panel) for post hole location (Fig.
- Page 4 When included in kit, place aluminum insert into Fig. 5 bottom rail, then insert bottom rail into bottom post route hole of rst post only (Fig. 5). Panels with 7" rails and 8x6 panels do not require aluminum inserts. NOTE: 8x8 panels will use aluminum inserts in the middle rail.
- Page 5 For Lattice Top Panels: Fig. 9 Top Rail a. Add the lattice insert over the top of the lattice Lattice Insert (Fig. 9). b. Place lattice into the middle rail followed by the top rail. c. Finally, add the completed top assembly into the route holes of the rst post (Fig.
- Page 6 For Open Top Panels with Pickets: Fig. 14 a. Attach middle rail into left side of post route only then guide rail over boards. Insert top rail into left post route holes of rst post only (Fig. 14). b. Insert pickets down through top and middle rail (Fig.
- Page 7 Insert the completed fence panel into the route Fig. 19 holes of the second fence post. Plumb and level the post and add concrete according to manufacturers instructions to top of hole (Fig. 19). Apply glue on inside rim of post tops then attach Fig.
- Page 8 Barrette Outdoor Living will at its option replace the product in question with new product of the same or equivalent value at no charge. Barrette Outdoor Living warrants these products against peeling, aking, splintering, corrosion, rusting or abnormal discoloration under normal use.
