- Page 1 RSP Supply Inc. | https://www.rspsupply.com User’ s Guide Shop online at omega.com e-mail: info@omega.com For latest product manuals: omegamanual.info LV800 SERIES Capacitance Point Level Sensors...
- Page 2 Approach Directives. OMEGA will add the CE mark to every appropriate device upon certification. The information contained in this document is believed to be correct, but OMEGA accepts no liability for any errors it contains, and reserves the right to alter specifications without notice.
- Page 3 RSP Supply Inc. | https://www.rspsupply.com LV 8 0 0 S E R I E S This manual contains the information necessary to ensure a safe and successful installation. Please read and comply with the section on page 9 of this manual pertaining to SAFETY. Doing so will ensure proper oper- ation of the equipment and the safety of all personnel.
- Page 4 RSP Supply Inc. | https://www.rspsupply.com P R E - I N S TA L L AT I O N C O N S I D E R AT I O N S Choosing a Location: (See Figure 2) 1) Material Flow - When selecting a location for the LV800, choose a point in the vessel where the probe will be out of the direct flow of incoming and outgoing material to prevent any mechanical damage that may be caused by the pres-...
- Page 5 RSP Supply Inc. | https://www.rspsupply.com M E C H A N I C A L I N S TA L L AT I O N E L E C T R I C A L I N S TA L L AT I O N Standard, Food Grade and Stub Probe Mounting: Factory Wiring: (See Figures 3 &...
- Page 6 RSP Supply Inc. | https://www.rspsupply.com Power Input: (See Figure5) 2-Step Calibration- probe exposed to material The LV800 is designed to accept either 115VAC or 230VAC 1) While the probe is not covered with material, rotate “Sense (factory set). Verify the intended voltage supply is compatible Adjust”...
- Page 7 RSP Supply Inc. | https://www.rspsupply.com LV800 Figure 7 Delay: A potentiometer is provided for setting the time delay between the time material is "sensed" (Yellow LED on) and the time the relay contact output changes (Red LED on). Units have a 1- turn potentiometer.
- Page 8 RSP Supply Inc. | https://www.rspsupply.com T R O U B L E S H O O T I N G M A I N T E N A N C E PROBLEM: Sensor will not sense material Fuse Replacement: CAUSE/SOLUTION: The fuse incorporated into the LV800 PCB is not intended for 1) Verify power is applied to the sensor.
- Page 9 RSP Supply Inc. | https://www.rspsupply.com M E C H A N I C A L S DIMENSIONS ARE SHOWN IN INCHES WITH MILLIMETER EQUIVALENT IN BRACKETS Standard Probe Stub Probe...
- Page 10 RSP Supply Inc. | https://www.rspsupply.com S A F E T Y S P E C I F I C AT I O N S 115VAC ( ± 15%); 2.5VA; 50/60Hz / 230VAC ( ± 15%); 2.5VA; 50/60Hz Power: General Safety Altitude: 6562 ft (2000 m) max Installation Category: II...
- Page 11 Department will issue an Authorized Return (AR) number immediately upon phone or written request. Upon examination by OMEGA, if the unit is found to be defective, it will be repaired or replaced at no charge. OMEGA’s WARRANTY does not apply to defects resulting from any action of the purchaser, includ- ing but not limited to mishandling, improper interfacing, operation outside of design limits, improper repair, or unauthorized modification.
