  • Page 1 A SSEMBLY CABINET WITH DRAWERS AND DOORS...

  • Page 2: Table Of Contents

    • Take out any old shelving and/or closet rods. Patch and repaint walls. • Tape the page(s) of your custom Elfa design to the corresponding wall. Upper Cabinets • Refer to your design for placement of your Elfa. Lay out all the products Lower Cabinets by type, size and wall.

  • Page 3: Tips Before Installing

    Easy Installation & Assembly Tips Before Installing Overall Process For Installing Any Garage+ by Elfa Space • Always start by mounting your Top Track. • If lighting is part of your solution, run Lighting Cables through your Hanging Standards using the Cable Organizers and pull connector ends through the correct slots (bend ends back so they don’t fall back through the slots) according your Space...

  • Page 4: Lower Cabinets

    Cabinet Frame with lockin Easy Installation & Assembly SKU 10093458 SKU 1010017 Art.no. 4700098 Art.no. 47000 Lower Cabinets Cabinet Frame Cabinet Fram SKU 10093458 SKU 10100175 Lower Cabinet Frames Art.no. 4700098 Art.no. 4700099 U 10093458 SKU 10100175 Cabinet Frame Cabinet Frame w SKU 10093458 SKU 10100175 .no.
  • Page 5 Easy Installation & Assembly Lower Cabinets Lower Cabinets can be hung in the Standards with Cabinet Standard Mounting Kit, freestanding and movable with Casters, or freestanding with Adjustable Feet. Hardware included in Lower Cabinet Frame packaging: A. 4x (Corner protectors marked E.
  • Page 6 Easy Installation & Assembly Lower Cabinets Assemble the Cabinet continued A. TR B. x1 connector x2 +screw x2 Applicable when using Cabinet Standard Mounting Kit (not included in Lower Cabinet Frame package). The hooks of the Hangers will stick out the back of of the Cabinet. Position the Top of the Cabinet. B.
  • Page 7 Easy Installation & Assembly Lower Cabinets Assemble the Cabinet continued Add Doors as shown. ©2024 The Container Store Inc. All rights reserved. WF462445 10/24...
  • Page 8 Assemble the Spacer. Easy Installation & Assembly Lower Cabinets Lower Cabinet with short doors and spacer Add a Spacer for a Lower Cabinet with Short Doors and Top Drawer art to assembling the abinet frame according instructions for Lower abinet for Doors. Lower Cabinet with short doors and spacer ssemble the Spacer.
  • Page 9 Easy Installation & Assembly Lower Cabinets Assemble the Cabinet continued Add Support Feet Install the Support Feet (qty 2) included with Cabinet Standard Mounting Kit or install Adjustable Cabinet Feet (qty 4) when not hanging from Standards. ©2024 The Container Store Inc. All rights reserved. WF462445 10/24...
  • Page 10 Easy Installation & Assembly Lower Cabinets Mount Cabinet in Standards NOTE: Fully secure Standards to wall before mounting Cabinet. TIP: Cabinets will be lighter to lift if Shelves and Doors are installed after hanging the Cabinets. Need illustration of cabinet being hung on Standards at top of solution Push back and down...
  • Page 11 Easy Installation & Assembly Lower Cabinets Add Cabinet Casters or Adjustable Feet (if applicable) for a Freestanding Solution Locking Casters go on front Secure Casters with included hardware as shown. Locking Casters go on the front. Attach feet to all 4 corners as shown. Adjust to level. ©2024 The Container Store Inc.
  • Page 12 Easy Installation & Assembly D D R R A A W Lower Cabinet for Drawers W E E R R C C A A B B I I N N E E T T D D R R A A W W E E R R C C A A B B I I N N E E T T D D R R A A W W E E R R C C A A B B I I N N E E T T...
  • Page 13 Easy Installation & Assembly Lower Cabinet for Drawers Assemble Drawer Cabinet continued The first side is in place. Add the other side the same way as Add Corner protectors marked (BL) and the first. (BR) using 2 (B) bolts. Add 2 (B) bolts to the back corners.
  • Page 14 Easy Installation & Assembly Lower Cabinet for Drawers Assemble Drawer Cabinet continued Important! 1) Assemble the locking rod into the rail with locking hooks on the Cabinet Top. 2) Insert the rail into the holder mounted on the backplate. Add 2 (C) screws in holes indicated to secure the Set the Cabinet upright.
  • Page 15 Easy Installation & Assembly Lower Cabinet for Drawers Assemble Drawer Cabinet continued Bring top all the way down flush with the sides. Add both parts (E) to the inside, upper, front corners as shown. Handles are optional Handles are optional Insert screw for Handle into insert the screw for Handles into bottom hole.
  • Page 16 Easy Installation & Assembly Lower Cabinet for Drawers Assemble Drawer Cabinet continued Add 2 (C) screws to secure the bottoms of the Handles. Completed front with Handles. Add 6 (C) screws to the lower part of the backplate. Add 2 (C) screws to secure the top of the backplate. ©2024 The Container Store Inc.
  • Page 17 Easy Installation & Assembly Lower Cabinet for Drawers Assemble Drawer Cabinet - Adding Casters NOTE: See page 27 for hanging Lower Cabinet on Standards. Align Casters with holes on bottom of Cabinet. Secure each Caster with 4 screws provided. NOTE: The 2 Casters with brakes go on the front.
  • Page 18 Easy Installation & Assembly C C a a b b i i n n e e t t D D r r a a w w e e r r s s C C a a b b i i n n e e t t D D r r a a w w e e r r s s Lower Cabinet for Drawers C C a a b b i i n n e e t t D D r r a a w w e e r r s s 1.

  • Page 19: Drawers

    4. Assemble an End Cap on each side of the front, to secure the front to the drawer. Easy Installation & Assembly Lower Cabinet for Drawers 4. Assemble an End Cap on each side of the front, to secure the front to the 4.
  • Page 20 Easy Installation & Assembly . Remove the inner part of the slides by pulling the black plastic part on the 7. Remove the inner part of the slides by pulling the black plastic part on the inner slide and slide it out. inner slide and slide it out.
  • Page 21 Easy Installation & Assembly Lower Cabinet for Drawers Assemble Drawer Cabinet - Adding Drawers 1. Mount the outer part of the slides on the desired location in the Side Panels of 1. Mount the outer part of the slides on the desired location in the Side Panels of the Cabinet.
  • Page 22 Easy Installation & Assembly 2. Slide drawer onto the Slides in the Cabinet and make sure to press the drawer until fl ush with the Cabinet front. First time installation requires a little more force. Assembly the drawers from bottom and up. Lower Cabinet for Drawers Assemble Drawer Cabinet - Adding Drawers continued NOTE: First time installation requires a little more force.
  • Page 23 Easy Installation & Assembly 2. Slide drawer onto the Slides in the Cabinet and make sure to press the drawer until fl ush with the Cabinet front. First time installation requires a little more force. Assembly the drawers from bottom and up. Lower Cabinet for Drawers Assemble Drawer Cabinet - Adding Drawers continued NOTE: First time installation requires a little more force.
  • Page 24 Easy Installation & Assembly 2. Slide drawer onto the Slides in the Cabinet and make sure to press the drawer until fl ush with the Cabinet front. First time installation requires a little more force. Assembly the drawers from bottom and up. Lower Cabinet for Drawers Assemble Drawer Cabinet - Adding Drawers continued NOTE: First time installation requires a little more force.
