R
WOODBRIDGE
FREESTANDING FAUCET
PREPARATION FOR INSTALLATION
5-1/8"
8-1/2"
6-1/4"
ATTENTION!
Dimensions may vary by up to 3/8". It is highly recommended to pull
all dimensions of actual model for installation and measuring purposes.
ATTENTION!
Measurements in inches are rouned to the nearest 1/8".
TECHNICAL DATA
Max flow rate 3.2 GMP at 80 PSI
Max hand shower flow rate 1.8 GPM AT 80 PSI
Customer Service Phone: 562-229-0088. (Monday - Friday 9 AM - 5 PM Paci c Time)
Or Email: help@woodbridgebath.com
200101 REV. 1
www.woodbridgebath.com
1
Advertisement
Related Manuals for Woodbridge F0014BN
Summary of Contents for Woodbridge F0014BN
- Page 1 WOODBRIDGE FREESTANDING FAUCET PREPARATION FOR INSTALLATION 5-1/8" 8-1/2" 6-1/4" ATTENTION! Dimensions may vary by up to 3/8". It is highly recommended to pull all dimensions of actual model for installation and measuring purposes. ATTENTION! Measurements in inches are rouned to the nearest 1/8".
- Page 2 WOODBRIDGE FREESTANDING FAUCET PARTS & COMPONENTS TOOLS REQUIRED FOR INSTALLATION Basin Wrench Adjustable Wrench Teon Tape Silicone Sealant Screwdriver OTHER TOOLS MAY BE REQUIRED www.woodbridgebath.com...
- Page 3 WOODBRIDGE FREESTANDING FAUCET INSTALLATION INSTRUCTIONS Put the base cover over the pipe. Screw the pipe to the base. Install the flexible hose now and ensure the flexible hoses Fix the faucet body to the pipe. are hand tightened into place.(DO NOT USE SPANNER TO TIGHTEN AS IT CAN DAMAGE THE O-RING).
- Page 4 WOODBRIDGE FREESTANDING FAUCET www.woodbridgebath.com...
