Woodbridge CSQ-3247-A Installation Instructions Manual

Sauna room
Hide thumbs

Advertisement

Table of Contents

Installation Instructions
WOODBRIDGE
READ ALL INSTRUCTIONS BEFORE UNPACKING THE PRODUCT
INSTRUCTIONS THAT, IF IGNORED COULD RESULT IN DEATH OR SERIOUS INJURY CAUSED BY INCORRECT HANDLING
OR INSTALLATION OF THE PRODUCT. THESE INSTRUCTIONS MUST BE OBSERVED FOR SAFE INSTALLATION.
This products must be installed by a fully insured and licensed installer.
We are not responsible for local code compliance for this product. Building and plumbing codes may vary from state-to-
state inaccordance to your loca�on. We are not responsible for providing any compliance cer�fica�ons.
Underno circumstances we are liable for any and all incidental damages sustained in connec�on with this product.Neither
manufacturer, distributor or retailer is responsible for water damage or flood caused by the usage of this product.
Under no circumstances we are liable for any and all fees, cost of installa�on/reinstalla�on/removal, subsequent damages
or transporta�on in case of the product defect.
The connec�on instruc�ons in this manual are for general reference. The actual connec�ons may varyby the type of sauna
room you purchase.
SAUNA ROOM
R
www.woodbridgebath.com
Model:CSQ-3247-A
SAUNA ROOM
FOR INDOOR USE ONLY
120VAC 15 AMP DEDICATED CIRCUIT
TEAM ARE REQUIRED TO LIFT AND DURING
ENTIRE INSTALLATION OF THIS PRODUCT
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CSQ-3247-A and is the answer not in the manual?

Questions and answers

Related Manuals for Woodbridge CSQ-3247-A

Summary of Contents for Woodbridge CSQ-3247-A

  • Page 1 Installation Instructions SAUNA ROOM WOODBRIDGE Model:CSQ-3247-A SAUNA ROOM FOR INDOOR USE ONLY 120VAC 15 AMP DEDICATED CIRCUIT READ ALL INSTRUCTIONS BEFORE UNPACKING THE PRODUCT INSTRUCTIONS THAT, IF IGNORED COULD RESULT IN DEATH OR SERIOUS INJURY CAUSED BY INCORRECT HANDLING OR INSTALLATION OF THE PRODUCT. THESE INSTRUCTIONS MUST BE OBSERVED FOR SAFE INSTALLATION.

  • Page 2: Table Of Contents

    68 7/8″ 68 7/8″ CONTENTS A. Preview F. F.A.Q. B. General Safety Rules G. Maintenance C. Installation H. Transportation D. Operation I . Limited Warranty E. Tips for Use WARNING Visually inspect all heaters before assembling to make sure there's no damages! Contact your dealer or manufacturer for troubleshooting and replacement parts.

  • Page 3: Preview

    Choose an installation location for your indoor sauna: (1)Your sauna should be placed on a solid surface and dry area. (2)Your sauna should not be built into any structure. It is a self-contained and freestanding unit. (3)To allow easy access to the main power cord, ensure there’s a minimum of 3 inches of clearance from the top wall and all sides of the unit.

  • Page 4: General Safety Rules

    B.GENERAL SAFETY RULES B.1 IT IS ILLEGAL TO INSTALL THIS UNIT WITHOUT FIRST OBTAINING A PERMIT FROM THE LOCAL ELECTRICAL INSPECTION AUTHORITY. ● There must be a reliable grounding device in the power supply and circuit used when the equipment is working, a reliable grounding wire in the socket to avoid a large amount of water vapor produced by the equipment due to overuse, which may cause static induction, voltage increase, short circuit, smoke, tripping and other hazards;...
  • Page 5 B.3 Safety Precautions ● Do not dry clothes or leave towels in the sauna. ● Do not touch the heater with your fingers or metal tools when the light is on. ● Do not splash water or other liquids on the heater. ●...
  • Page 6 MAIN COMPONENTS FRONT PANEL WITH LEFT PANEL RIGHT PANEL BASE PLATE BACK PANEL TOP PANEL GLASS DO0R +HEATER +HEATER SEAT SUPPORT SEAT PANEL BACKREST DUST COVER WOODHANDLE OXYGEN BAR TEA CUP HOLDER FIXINGS, FITTINGS AND TOOLS M3.5*15MM M3.5*25MM M4*50MM M4*40MM M6*40MM SCREW FOR OXYGEN BAR SCREW FOR TEA...
  • Page 7 C.INSTALLATION C.1 Product explosion diagram and heating element layout. Front Panel with Dust Cover Power Supply Box Top Panel Glass Door Right Panel Heater Seat Right Panel Heater Controller Panel Wood Handle Seat Front Right Seat Front Panel Heater Left Panel Heater Left Panel Side glass Panel Heater Backrest...
  • Page 8 Assembly diagram Step 1:Install Bottom Step 2:Install Back Panel Step 3:Install Left panel Step 4:Install Right Panel Step 5:Install Seat Support Step 6:Install Plug Step 7:Install Seat Step 8:Install Backrest Step9:Install Front Panel Step10:Install glass door Step 11:Install Top Panel Step 12:Install Wood Handle and Side glass www.woodbridgebath.com...
  • Page 9 C.2 Circuit Diagram Control Line Backup Line Backup Line Oxygen Bar Line Temperature Sensor Color Light This circuit diagram is applicable to (FOR CARBON ENERG INFRARED MODEL SAUNAS) C.3 Attention before installation ● Do not share the same plug with other appliances. ●...
  • Page 10 ● Leg Support Install(Screw Fixed) ● Seat Install(Screw Fixed) ● Seat Backrest(Screw Fixed) ● Install Top(Screw Fixed Top+Electric Connection) Open Dust Cover Plate and Install the top on the sauna room Open components(Top Panel)and(Dust Cover Plate) www.woodbridgebath.com...
  • Page 11 Install Heater Plug Install Power Box connection terminal Install Dust Cover Plate Install components(Top Panel)and(Dust Cover Plate) www.woodbridgebath.com...
  • Page 12 ● Installing cup holder. Attach cup holders in the fore left corner and the fore right corner(when sitting in the sauna). ● Installing doorknob. 1.Align the inside doorknob against holes on the inside of the door. 2.Hold it at an angle against the door. 3.Insert the screw into the hole located on the inside of the door.
  • Page 13 C.5 How to replace the heater Warning: only qualified person can replace the heater. ● How to replace the carbon fiber heater: 1.Take off wooden frame of carbon heater, then 2.Take out carbon heater carefully. Find out the screw off carbon heater from wooden frame. connector between carbon heater and sauna wall.
  • Page 14 ● How to replace the carbon tube(Example: The following picture shows other products, but the replacement method is the same) a.Remove the 2 fixed screws from the wooden fence. b.Remove the screws from the black mesh cover and remove the mesh cover. c.Pull out the wire connectors on both sides of the heating element from the inside of the sauna room (do not forcefully pull to prevent breakage, you can hold the white wire and shake it left and right to pull it out), cut off the connecting wire of the heating element.
  • Page 15 d.Remove the metal wire clips from both ends of the heater and remove the damaged heating tube. e.Install a new heating tube and insert the line card. f.Connect the two wires of the heating element and wrap them with high temperature insulation tape. g.Install the mesh cover and install the wooden fence on the back.
  • Page 16 C.6 Oxygen lonizer Installation ● Press the ion button: it extremely purifies the air and removes toxic substances including the dust odors and mold. ● Press the ozone button: ozone may kill virus, and will bedeoxidized into oxygen in the end without secondary pollution, which the chemical agents can not achieve.

  • Page 17: Operation

    D.OPERATION NOTE: Before the sauna is turned on, remove plastic protective covering from the CONTROL PANELS. Please check and confirm that the connections to the POWER SUPPLY, HEAT EMITTERS, and TEMPERATURE SENSOR are connected properly. The power supply voltage and frequency must match the requested voltage and frequency of the sauna(120VAC 15AMP Dedicated Circuit).
  • Page 18 D.3 Operation of control panel a.Press the key . The power indicator turns on. Temperature display indicates the temperature in the room. Press the key again .The power indicator turns off. b.Press the TIME Key to adjust the time. If the time indicates 00, the room stops heating. c.Press the TIME Key together can switch between C and F, the heat indicator turns on.

  • Page 19: Tips For Use

    D.4 Open the ceiling vent to allow a flow of fresh if required. E.TIPS FOR USE ● Set the temperature to a comfortable level, normally 40 to 50°C.(104 to 122°F) ● Allow approximately 8-15 minutes for the sauna to warm up. ●...
  • Page 20 F.FREQUENTLY ASKED QUESTIONS MAKE SURE TO SHUT OFF THE ELECTRICITY BEFORE DOING IT. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly, qualified persons in order to avoid a hazard. F.1 Heater has problem. Problem Explanation Solution...

  • Page 21: Maintenance

    ● Disclaimers Woodbridge shall not be liable for loss of use of sauna or other Woodbridge products or other secondary or incidental or consequential costs, expense or damages-which may include the removal of permanent deck or other custom fixtures. Under no circumstances shall Woodbridge or any of its representatives be held liable for injury to any person or damage to any property, however arising.
  • Page 22 ATTENTION OF USING SAUNA 1.Sauna use may cause blood pressure to fall, so people with low blood pressure should talk to their doctor to make sure sauna use is safe. 2.People who have heart disease or have recently had a heart attack should also talk to their doctor first. 3.who after consuming alcohol or suffering from high blood pressure, heart disease, infectious or contagious diseases, skin conditions, or who are physically unfit for sauna &...
  • Page 23 IMPORTANT! DO NOT USE: Abrasive cleaners such as: acid, ammonia, bleach, and similar solutions. Use of such solutions may cause corrosion, finish peeling, and/or dull the surface. DO NOT USE: Abrasive sponges or cloth. Never use steel, wool, or wired brushes that will permanently scratch the Please don't hesitate to contact us if you have any questions or concerns.
