INSTALLATION AND CARE GUIDE
WOODBRIDGE
Compliance with the following codes & standard:
• 2015 Uniform Plumbing Code
• 2018 International Plumbing Code
• 2018 International Residential Code
• CSA B45.5 / IAPMO Z124-2017- Plastic Plumbing Fixtures
ICC
TM
LISTED
READ ALL INSTRUCTIONS BEFORE UNPACKING THE PRODUCT
INSTRUCTIONS THAT, IF IGNORED COULD RESULT IN DEATH OR SERIOUS INJURY CAUSED BY INCORRECT HANDLING
OR INSTALLATION OF THE PRODUCT. THESE INSTRUCTIONS MUST BE OBSERVED FOR SAFE INSTALLATION.
This products must be installed by a fully insured and licensed plumber only. Installation of any our product by anyone other
than fully insured and licensed plumber shall void limited warranty. We recommends that such licensed plumber have experience
in the installation of products.
Limited warranty is void on any commercial installation
We are not responsible for local code compliance for this product. Building and plumbing codes may vary from state-to-state in
accordance to your location. We are not resonsible for providing any compliance certifications.
Under no circumstances we are shall not be liable for any and all incidental damages sustained in connection with this product
Neither manufacture, nor distributor, nor retailer is responsible for water damage or flood caused due to use of this product.
Under no circumstances We shall not be liable for any and all fees, cost of installation/reinstallation/removal, subsequent
damage or transportation in case of the product defect
Customer Service Phone: 562-229-0088. (Monday - Friday 9 AM - 5 PM Pacific Time)
R
CLAWFOOT BATHTUB
SCC Accredited
CB-P/S
ANSI
ACCREDITED
ISO/IEC 17065
OCPS
Product Certification Body
Accrédité
CCN
#1000
Or Email: help.woodbridge@gmail.com
( UPC )
®
( IPC )
®
®
( IRC )
PREFERED
EDUCATION
PROVIDER
2 PEOPLE ARE REQUIRED TO LIFT AND DURING
ENTIRE INSTALLATION OF THIS PRODUCT
122018 REV. 1
1
Advertisement
Table of Contents
Related Manuals for Woodbridge CLAWFOOT BATHTUB
Summary of Contents for Woodbridge CLAWFOOT BATHTUB
- Page 1 INSTALLATION AND CARE GUIDE WOODBRIDGE CLAWFOOT BATHTUB Compliance with the following codes & standard: ( UPC ) ® • 2015 Uniform Plumbing Code ( IPC ) ® • 2018 International Plumbing Code ® ( IRC ) • 2018 International Residential Code •...
- Page 2 TOOLS REQUIRED FOR INSTALLATION (NOT INCLUDED) OTHER TOOLS MAY BE REQUIRED Soft Cloth Silicone Tape Pencil/Marker Hacksaw Hammer or Blanket Measure Adjustable Channel Safety Glass Knife Level Caulk Gun Plumber’s Tape Wrench Lock Pliers Inspect the bathtub for any damages. If any damage is found please contact your retailer. 1.
- Page 3 CLAWFOOT BATHTUB INSTALLATION PROCEDURE 3. Thread a washer and nut onto each stub. Don’t fully tighten the nuts: The bar needs to be able to slide back and forth to allow adjustment until the foot is attached. 4. Fit the foot to the metal bar and tub , locking washer and bolt .
- Page 4 CLAWFOOT BATHTUB INSTALLATION PROCEDURE •Please find all parts before Diagram I start your Installation A, B, C : Pipes D E: Connector Overflow Tee G ,H,I : Sealer Connector K , L : Slip Nut Joint / Overflow Assembly Washer Beveled Cover / Overflow Plate...
- Page 5 CLAWFOOT BATHTUB INSTALLATION PROCEDURE 8. Installation of “ E” connector with “ F” . Please refer back to Diagram I for details. 9. Measure the distance between two measure and mark each pipe so that the end of the pipe reaches a little over halfway into the overflow tee.
- Page 6 CLAWFOOT BATHTUB INSTALLATION PROCEDURE Use Teflon Sealing Tape 11. Connect Overflow “ A” with “ D” and “ E” .Please apply Teflon Sealing tape. Please connect “ D” before “ E” . 12. The overflow tee will be attached at the points where the drain pipes intersect.
- Page 7 CLAWFOOT BATHTUB INSTALLATION PROCEDURE 15.Installation Finished (Item: B-0023, B-0024 May have pipe “ A ” and “ B ” more than 90º) 16. There are two locations that can install “ C ” and “ S” . 17. Attached the drain tube and flange to the waste and overflow tee with the sealing...
- Page 8 Abrasive sponges or cloth. Never use steel, wool, or wired brushes that will permanently scratch the surface. Retain these installation instructions for future reference! Thank you for using WoodBridge products! Please don't hesitate to contact us if you have any questions or concerns.
