Installation Instruction for Barrel Sauna
READ ALL INSTRUCTIONS BEFORE UNPACKING THE PRODUCT
INSTRUCTIONS THAT, IF IGNORED COULD RESULT IN DEATH OR SERIOUS INJURY CAUSED BY INCORRECT HANDLING
OR INSTALLATION OF THE PRODUCT. THESE INSTRUCTIONS MUST BE OBSERVED FOR SAFE INSTALLATION.
Limited warranty is void on any commercial installation
We are not responsible for local code compliance for this product. Building and plumbing codes may vary from state-to-state in
accordance to your location. We are not resonsible for providing any compliance certifications.
Under no circumstances we are shall not be liable for any and all incidental damages sustained in connection with this product
Neither manufacture, nor distributor, nor retailer is responsible for water damage or flood caused due to use of this product.
Under no circumstances We shall not be liable for any and all fees, cost of installation/reinstallation/removal, subsequent
damage or transportation in case of the product defect
Model:OBS1812-A
OBS1818-A
2 PEOPLE ARE REQUIRED TO LIFT AND DURING
ENTIRE INSTALLATION OF THIS PRODUCT
Or Email: help@woodbridgebath.com
www.woodbridgebath.com
20230809 REV.1
1
Advertisement
Table of Contents
Related Manuals for Woodbridge OBS1812-A
Summary of Contents for Woodbridge OBS1812-A
- Page 1 Installation Instruction for Barrel Sauna Model:OBS1812-A OBS1818-A READ ALL INSTRUCTIONS BEFORE UNPACKING THE PRODUCT INSTRUCTIONS THAT, IF IGNORED COULD RESULT IN DEATH OR SERIOUS INJURY CAUSED BY INCORRECT HANDLING OR INSTALLATION OF THE PRODUCT. THESE INSTRUCTIONS MUST BE OBSERVED FOR SAFE INSTALLATION.
-
Page 2: Electrical Requirements
Your barrel sauna will include the following: 1 One bath staves* 2 Half back piece x 1 3 Half clear glass x 1 4 Front piece( 2 side panel + 1 wooden frame) 5 Doorknob assembly(1 Glass door + 2 handle pieces + 2 black pad) 6 Two benches（Includes 2 support) 7 Wooden floor mat x 3 8 Cradles*... -
Page 3: Product Information
Product information OBS1812-A : L = 47-1/4″ Product Name: Barrel Sauna OBS1818-A : L = 70-7/8″ Model: OBS1812-A / OBS1818-A Size: Φ70-7/8 x 70-7/8 / Φ70-7/8 x 47-1/4 Φ70-78″ 10″ 10″ 47″ 4″ LOCATING THE SAUNA Because the traditional sauna experience involves a heating-cooling-resting regimen, it is important to plan ahead before installing your sauna. -
Page 4: Back View
All panels are require to assemble according to the No.remark. BACK VIEW www.woodbridgebath.com... - Page 5 FLOOR ASSEMBLY Step1: Placing the cradles on the ground, For optimal assembly, it is important that the cradles are parallel to each other. Image 1 Image 2 Cradles requirements: barrel saunas require 2 cradles Step2: Fasten the drain stave directly in the center of the cradles using 2 screws so the stave extends over the end cradles by approximately 4”(5.7) .
- Page 6 Make sure the stave sits perpendicular to the cradles of the middle before continuing. Image 7 Image 8 Image 9 Continue adding staves to each side of the center stave, tapping each into place with a rubber mallet (11). As you are adding staves, fasten every other stave to each cradle making sure each notch lines up with the others (12)and that each stave is perpendicular to the cradle.And fix them with screws.
- Page 7 Step3: Take the three front end pieces, including the door and two side pieces, and line them up so that both left and right pieces are align with the middle pieces. Gently position the two wing sections into place on either side of the door panel - you may use a rubber mallet to achieve a snug fit. Secure the wings to the door section with screws through the predrilled holes on the horizontal support beam.
- Page 8 ROOM ASSEMBLY continued..With the front and half back pieces level and placed, begin placing staves up the sides of the sauna. Tap each board with a rubber mallet (24). Hammer a nail through every second or third stave into the front and back end panels to keep them from falling out (25).
- Page 9 Image 32 Image 33 Image 34 BENCHES AND SUPPORTS Note: You may choose to install benches and supports after the entire room has been assembled, but you may find installation easier with the space and light afforded at this point. Each barrel sauna includes two pre-assembled benches that are side specific.
- Page 10 ROOM ASSEMBLY…CONTINUED All the sauna room are finished the assemble test before package.So just keep to tap the staves to the top of the sauna room according to the Number we remarked. Finally you find that there is a difference in the size of the remaining space between staves, and the radius produced by the staves will actually be slightly larger than the radius of the barrel end plate (40).
-
Page 11: Band Assembly
BAND ASSEMBLY Each band assembly includes the following components: (43) • Stainless steel band w/brackets • nuts (2) • Threaded rod • Black vinyl caps Position the bands around your sauna, evenly spaced (44). Insert the threaded rod through the bracket and tighten the nuts by hand evenly until no longer able (45). - Page 12 Install door and door handle Each door assembly includes the following components: (43) Install the hinges between door and front piece(50),then install the door handle.(51-52) Image 51 Image 52 Image 53 Image 54 www.woodbridgebath.com...
- Page 13 ASPHALT SHINGLE ROOF AND DECORATION PANEL INSTALL... The install of the asphalt shingle will includes the following components： Image 55 Position the wooden panel on the middle of the sauna room with Nail.(54)Then set the first layer asphalt shingle roof(55) and keep to set the second till to the top of the sauna room.(56-58). Install the decoration panel on the front and the back end with screws.(59-60) Image 57 Image 56...
- Page 14 FINAL THINGS Once assembly is complete, sweep and vacuum the inside of the sauna. Wipe down the entire interior with a damp cloth to remove any remaining dirt, dust and debris. Note: If the sauna has absorbed moisture in storage, the staves may shrink as the high heat evaporates that moisture.
-
Page 15: Warranty
WARRANTY WOODBRIDGE Caution: will void the warranty. contractorwillvoid this limited warranty. RESPONSIBILITIES OF OTHERS by proper inspection and testing prior to installation. DISCLAIMER WOODBRIDGE Customer Service Phone: 562-229-0088 www.woodbridgebath.com... -
Page 16: Important Safety Rules
Abrasive sponges or cloth. Never use steel, wool, or wired brushes that will permanently scratch the surface. Retain these installation instructions for future reference! Thank you for using WOODBRIDGE products! Please don't hesitate to contact us if you have any questions or concerns.
