" TRANSPARENT " CABINET
THANK YOU FOR PURCHASING OUR PRODUCT
Please scan the QR code to refer to the installa
Note: Please contact us if you encounter any problems
with the install on,missing or replacement parts,and
tell us your "ORDER ID," we will solve the issue for you
as soon as possible.
online video:https://buylikepro.com/pages/glass-display-cabinet-with-5-shelves-support
Customer Service Email: help@EverythingSupport.com
TEL:(855)208-0668(MON-FRI 9:00am-6:00pm Eastern Time)
DOUBLE DOOR
TEMPERED GLASS
WINE CABINET / DISPLAY CABINET
(
NV028DX
)
Advertisement
Related Manuals for RoomTec NV028DX
Summary of Contents for RoomTec NV028DX
- Page 1 DOUBLE DOOR “ TRANSPARENT ” CABINET TEMPERED GLASS WINE CABINET / DISPLAY CABINET NV028DX THANK YOU FOR PURCHASING OUR PRODUCT Please scan the QR code to refer to the installa Note: Please contact us if you encounter any problems with the install on,missing or replacement parts,and tell us your “ORDER ID,”...
- Page 2 Good to know about tempered glass ! IMPORTANT Handle with care! A damaged edge or scratched surface can in exceptional cases cause the glass to crack suddenly.However, it won't shatter into sharp fragments, only into small pieces. Avoid collisions from the side-This is the mostfragile part of the glass. WARNING : Furniture tipping-over could result in injury or death to the installer.
-
Page 3: Installation Instructions
Installation Instructions Need two adults. Buffer layer. Contact us for help. The display case must be permanently attached to the wall. During installation, use cardboard or carpet as a buffer layer to prevent the glass corner from colliding with hard objects such as the floor. - Page 5 Anti-tipping device X2 Connector A X8 Connector B X8 Screwdriver X1 Nut X40 Screw X42 Gasket X40 Gasket X32 1840*285*4mm ① Door clip set X2 Lock X1 Horn guard X6 Back glass X2 1840*345*4mm 1818*383*5mm 772*315*5mm 805*365*18mm ④ ② ③ ⑤...
-
Page 6: Detailed View
Step 1 Double door ⑥ Guide hole ⑥ Bottom panel Detailed View Guide hole Buffer layer. Step 2 Step 3 Guide hole ⑥ Back glass ① Please wear gloves. Detailed View ⑥... - Page 7 Step 4 ① Detailed View ② Make sure that the installation is done by two adults. ① ② Need to squeeze in Side glass ⑥ Detailed View...
- Page 8 Step 5 ① ② Make sure that the installation is done by two adults. ② ⑥ ⑥ Detailed View ⑥...
- Page 9 Step 6 Need to squeeze in. ① ① ② Make sure the sides and bo�om are flush. ⑥ The product should be vertical and horizontal,otherwise installation may fail. To avoid possible accidents, please keep children away during installation.
- Page 10 Step 7 Detailed View ② ① ① ① ② ② ⑥ Detailed View...
- Page 11 Step 8 ① ① ② ② ⑥ ② ⑥ ⑥ Detailed View Step 9 ⑤ Guide hole Top panel ⑤ Detailed View...
- Page 12 Step 10 Detailed View ⑤ ⑤ ② ② ⑤ ② ⑥ Step 11 ⑤ ⑤ ④ ④ ④ ④ ④ Shelf glass ⑥ ⑥...
- Page 13 Step 12 When installing tempered glass, make sure the cornersdo not hit the floor to prevent the tempered glass from exploding due to force changes. Detailed View Buffer pad. ⑤ ③ ④ ③...
- Page 14 Step 13 ⑤ ④ ③ Detailed View ③ Detailed View Buffer pad.
- Page 15 Step 14 ⑤ Detailed View ② ③ ⑥ ③ After installing the cabinet, check and tighten all screws.
- Page 16 INSTALLATION TROUBLESHOOTING TIPS Door clip adjustment Handle indication Door stopper installation is difficult Please protect your hands with tools to avoid scratches Anti-tipping device THANK YOU FOR PURCHASING OUR PRODUCT Please scan the QR code to refer to the installa on video. Note: Please contact us if you encounter any problems with the install on,missing or replacement parts,and tell us your “ORDER ID,”...
