- Page 1 Wall Mount Handrail HK28 User Guide 1602011(230511)
-
Page 2: Specifications
1. Overview Muzata wall mount handrails are designed for weldless installation. You can easily assemble all the parts without any cutting, welding, and the hassle of drilling on stainless steel. Everything you need is included in the package. 2. Specifications Muzata offers wall-mounted handrails in varying lengths as listed below. - Page 3 3. Items related (1) Package includes...
-
Page 4: Installation Steps
4. Installation Steps Locate bracket on the wall Step 1 - Step 2 - Measure and mark Place thumbtacks on the position of the brackets on the mark points. the wall. Step Step 4 - Connect Drill guide holes with thumbtacks with piece... - Page 5 Step 5 - Step 6 - Fix the bracket base ➋ Install the bracket ➋ with M5×40mm self tapping and leave some tighten room in ➎ screws this step. Assemble the handrails Step Step 2 - Cover Insert the connector connector cover onto the base and align it with the holes on and screw the set screws into...
- Page 6 Step 3 - Step 4 - Tighten the set Fix connector and ➒ ➑ screws until the connector ➓ handrail with M5×14mm bolts completely tapped handrails. Install handrails onto the bracket Step 1 - Fix the handrails onto Step 2 - Tighten the bracket brackets with M5×16mm bolts base screw.
- Page 7 7. About Muzata MUZATA has helped millions of families with their cable railing projects during the past years. We believe that home renovation should be easy and affordable. So we work with every effort to provide quality products...
