- Page 1 CK07 User Guide 1602031(231011)
-
Page 2: Specifications
You can install it by yourself without a contractor. You can use Muzata CK07 for multi-angle stairs as well as level railings. The T316 stainless steel material of CK07 makes it ideal for both indoor and outdoor projects, even seaside projects. 2. Specifications... - Page 3 3. Items related Listed below are all of the accessories and tools related to the Muzata CK07. Please note that not all items are essential. Some may not be included in your package. If you need them, you may need to purchase them separately.
-
Page 4: Installation Steps
4. Installation steps We will install the tensioner on right end post as an example. Actually you can install it on either side according to your need. For level railing Step 1 - Locate hole positions with drill guide ➑; drill through holes on the intermediate posts with a 9/32"... - Page 5 Step 2 - While pass the cable through all ➎ intermediate posts, put in the level protector sleeves ➏. Step 3 - Swage fixed end and cable.(For ❷ vinyl-coated wire rope, please cut off the outer coating first.）...
- Page 6 Step 4 - Locate fixed end on the left end ❷ post, and mark holes. Step 5 - Install fixed end on the left end ❷ post by screws ❸.
- Page 7 Step 6 - Locate tensioner on the right end ❶ post, and mark holes. Step 7 - Install tensioner on the right end ➊ post by screws ❸.
- Page 8 Step 8 - Loosen 3/4 of the tensioner ❶ extend the turnbuckle. Step 9 - Pull the cable straight, mark the cable at the flattened part (point A), and cut at point A with cutter ➒.
- Page 9 Step 10 - Swage tensioner and cable ➊ ➎ with hydraulic crimper ➒. Step 11 - Clamp the terminal of the tensioner with a plier, and use bent wrench ❶ to tighten the cable. ➍...
- Page 10 Step 12 - Fix tensioner with two nuts to ❶ prevent loosening. Step 13 - Follow the sequence to install other cable runs.
- Page 11 For stair railing Step 1 - Locate the hole positions and drill 30-degree through holes on intermediate posts with a 5/16" drill bit ⓫. Step 2 - While pass the cable through all ➎ intermediate posts, put in angle protector sleeves ➐.
- Page 12 Step 3 - Swage fixed end and cable with ❷ ➎ hydraulic crimper . (For vinyl-coated wire ➒ rope, please cut off the outer coating first.） Step 4 - Locate fixed end on the left end ❷ post, and mark holes.
- Page 13 Step 5 - Install fixed end on the left end ❷ post by screws ❸. Step 6 - Locate tensioner on the right end ➊ post, and mark holes.
- Page 14 Step 7 - Install tensioner on the right end ➊ post by screws ❸. Step 8 - Loosen 3/4 of the tensioner ❶ extend the turnbuckle.
- Page 15 Step 9 - Pull the cable straight, mark the cable at the flatten part (point A) and cut at point A with cutter ➒. Step 10 - Swage tensioner and cable ➊ ➎ with hydraulic crimper ➒.
- Page 16 Step 11 - Clamp the terminal of the tensioner with a plier, and use bent ❶ wrench to tighten the cable. ➍ Step 12 - Fix tensioner with two nuts to ❶ prevent it from loosening.
- Page 17 Step 13 - Follow the sequence to install other cable runs. Please note that installation videos are available on our product pages for further details if needed. 5. Tips (1) Ensure that your posts and handrail are properly installed before you start cable installation. (2) You might have to buy extra materials than expected in case some materials might not be reusable after operation mistakes.
- Page 18 7. About Muzata Muzata has helped millions of families with their cable railing projects during the past years. We believe that home renovation should be easy and affordable. So we work with every effort to provide quality products and professional service, to make Muzata a reliable brand.
