- Page 1 CR73 User Guide 1602015 (230616)
-
Page 2: Specifications
1. Overview Muzata CR73 is a great choice for building your cable railing project. It is completely invisible cable railing kit that can be applied to 4"x4" or 6"x6" or 8"x8" wood posts. With its well-designed compact body, it will satisfy your needs for one post solution at the corner. - Page 3 3. Items related Listed below are all of the accessories and tools related to the Muzata CR73. Please note that not all items are essential. Some may not be included in your package. If you need them, you may need to purchase them...
-
Page 4: Installation Steps
4. Installation steps We will install the tensioner on the right end post as an example. Actually you can install it on either side according to your need. 4.1 For level railing Step 1 - Locate hole positions with 3" cable spacing. Step 2 - ➒... - Page 5 Step 3 - Drill 1 37/64" deep holes with drill guide ➒ on the end posts with a 13/32" drill bit. Step 4 - While pass the cable through from right ➎ to left posts, put in adhesive washers for end ➐...
- Page 6 Step 5 - ➊ Swage the ferrule with hydraulic ➓ crimper Step 6 - ➊ Tighten screw-in sleeve with the ➏ socket wrench on the left post.
- Page 7 Step 7 - ❷ Pull the cable against the right post and mark point A against the inside of the right post. Step 8 - Mark point B at 1 17/64" against the right side of point A. Cut the cable at point B with cable ➓...
- Page 8 Step 9 - ➊ Swage the ferrule with hydraulic ➓ crimper Step 10 - ➊ Tighten the screw-in sleeve with ➏ the socket wrench on the right post.
- Page 9 Step 11 - ➎ Install the adhesive washers ➐ level protector sleeves Step 12 - Follow the sequence to install other cable runs.
- Page 10 4.2 For angle railing Step 1 - Locate hole positions with 3" cable spacing. Step 2 - Drill 30 degrees through holes with drill ➒ guide on all intermediate posts with a 9/32" ➌ drill bit...
- Page 11 Step 3 - Drill 30 degrees 1 37/64" deep holes with ➒ drill guide on the right and left posts with a 13/32" drill bit. Step 4 - ➎ Put the adhesive washers into the cable pull cable through intermediates posts and angle protector sleeves ➑...
- Page 12 Step 5 - ➊ Swage the ferrule with hydraulic ➓ crimper Step 6 - ➊ Tighten screw-in sleeve with the ➏ socket wrench on the left post.
- Page 13 Step 7 - ❷ Pull the cable against the right post and mark point A against the inside of the right post. Step 8 - Mark point B at 1 17/64" against the right side of point A. Cut the cable at point B with cable ➓...
- Page 14 Step 9 - ➊ Swage the ferrule with the hydraulic ➓ crimper Step 10 - ➊ Tighten screw-in sleeve with the ➏ socket wrench on the right post.
- Page 15 Step 11 - ➎ Install the adhesive washers ➑ angle protector sleeves Step 12 - Follow the sequence to install other cable runs. Please note that installation videos are available on our product pages for further details if needed.
- Page 16 5. Tips (1) Ensure that your posts and handrails are properly installed before your start cable installation. (2) You might have to buy extra materials than expected in case some materials might not be reusable after operation mistakes. (3) The recommended post spacing between two wood posts is 4ft-6ft, no more than 6ft.
- Page 17 7. About Muzata MUZATA has helped millions of families with their cable railing projects during the past years. We believe that home renovation should be easy and affordable. So we work with every effort to provide quality products and professional service, to make Muzata...
