VSD-LB/LC Control Panel Handling and Operating Manual VSD-LB/LC Control Panel Handling and Operating Manual Contents 1. General .................................. 4 2. Safety ..................................4 2.1 Symbols related to explanations in the operation guide ..................4 2.2 Staff education ................................4 2.3 Dangerous hazards if the safety rules are not observed....................4 2.4 Safety rules for operating personnel..........................
Page 4
VSD-LB/LC Control Panel Handling and Operating Manual Figure: 1 (Wall Type) 1-Main switch 2- Terminals 3- Auto-Man selector switch 4- Thermal magnetic circuit breaker 5- Star-Delta relay 6- Contactors 7-FC Magnetic switch 8- 24VDC Transformer 9- PLC 10- Isolation transformer thermal magnetic switc...
Page 5
VSD-LB/LC Control Panel Handling and Operating Manual Figure: 2 (Standing Type) 1-Main switch 2-Terminals 3-24VDC Transformer 4-Analog module 5- FC and Network contactors 6- Auto-Man selector switch 7- Thermal magnetic circuit breaker 8- Star delta relays 9- FC Magnetic switch...
Failure to comply with the rules in general can lead to VSD-LB control units are for pressure booster systems and the following negative facts: VSD-LC control units are for circulation pump systems to be •...
VSD-LB/LC Control Panel Handling and Operating Manual Through the screen; 5.Product information • Different language option (English, Turkish, Russian and Fr e nc h ) • Setting the system pressure value • Existing pressure value in the system • Selecting a replacement pump •...
Preset of the control panel was made in the factory. The 6.1 Pressure sensor factory setting can be recreated by the WILO Service. According to the installation and operating instructions, connect the 4/20 mA pressure sensor to the terminals 7.2 Control of motor rotation...
10. Authorized services WILO Pompa Sistemleri A.Ş. You can find a list of services authorized by: http://www.w lo.com.tr/anasayfa/serv s-destek/yetk l -serv sler/ There is a life-threatening hazard due to electric shock when working on electrical devices.
VSD-LB/LC Control Panel Handling and Operating Manual 13. Screen Views and Explanations Screen View Descriptions 12.1 Screen saver In order to enter the workpage it is required to click to the screen saver. Main page After being touched by the opening screen saver, the mainpage is opened and the mainpage changes according to the system operation mode.
VSD-LB/LC Control Panel Handling and Operating Manual Screen View Descriptions Settings Settings You can access the Settings page by clicking the button on the Main Menu page. All settings related to the system can be accessed from this page. Service settings can be accessed by entering a password, other settings can be made without a password.
Page 12
VSD-LB/LC Control Panel Handling and Operating Manual Screen View Descriptions Clock & Date The Clock & Date settings page is accessed by pressing the button on the previous page of the system auto shutdown settings. After the time and date values entered on the left side of the page, press the button .
Page 13
VSD-LB/LC Control Panel Handling and Operating Manual Screen View Descriptions Pressure Set Settings The system operation set value is entered from the Set Value page. Set value page is accessed by pressing the Set Value button on the settings page.
VSD-LB/LC Control Panel Handling and Operating Manual Screen View Descriptions Operating Modes Operating modes page is the first page opened after the service password is entered. Operating mode is selected from this page, control panel can be operated in two modes as Circulation and Booster. The selected mode is highlighted with green color.
Page 15
VSD-LB/LC Control Panel Handling and Operating Manual Screen View Descriptions Sensor Settings The Sensor Settings page is accessed by pressing the button on the previous Select Circulation Mode screen. That's Sensor's Maximum The value's is written in the system in how many bar sensors are used. (For example 16 if a 16 bar sensor is used).
Page 16
VSD-LB/LC Control Panel Handling and Operating Manual Screen View Descriptions PID Settings The PID Settings page is accessed by pressing the button on the previous FC Operation Settings-2 page. The PID values determine how the acceleration and deceleration of the frequency converter device will take place and how the system will behave in order to achieve setpoint.
Page 17
VSD-LB/LC Control Panel Handling and Operating Manual Screen View Descriptions Δ TC mode After selecting the operation mode , the select circulation mode is opened ∆ T-c (Figure-a) . Press the button on the page to select TC mode. In this mode, the system is used to provide water circulation from the heating (burner) or cooling (cooling) units.
Page 18
VSD-LB/LC Control Panel Handling and Operating Manual Screen View Descriptions RPM mode This mode can only be operated when there is only one pump in the system. This mode is used to run the pump at a certain speed (Figure-a). The number of revolutions written on the motor label is entered in the Speed setting screen under the Service settings menu.
Page 19
VSD-LB/LC Control Panel Handling and Operating Manual Screen View Descriptions Booster Working Mode From this page; In case of need, the auxiliary pump is set up with the mains or the driver. You can press button to change. Sleep Settings This function can only be used actively in booster systems.
Page 20
VSD-LB/LC Control Panel Handling and Operating Manual Screen View Descriptions Language Selection Language The language selection page is accessed by pressing the button under the menu. Settings Panel Settings The panel settings page is accessed by pressing the button Panel Settings...
VSD-LB/LC Control Panel Handling and Operating Manual 13. Fault causes and possible solutions Definition of Problem Possible reasons Solution recommendation Acceleration and deceleration times are Change acceleration not compatible deceleration ramp times over the drive. The pump goes into trouble when was...
Page 22
VSD-LB/LC Control Panel Handling and Operating Manual Definition of Problem Possible reasons Solution recommendation Triangle mark on screen seem. The screen can not communicate with Check the communication cable, please the PLC, the PLC program is deleted try to reload the program if the problem or there is a problem with communication cables.
Page 23
VSD-LB/LC Kontrol Panosu Kullanma ve İ let m Kılavuzu...
Page 24
VSD-LB/LC Kontrol Panosu Kullanma ve İ let m Kılavuzu...
Page 25
06.2017 WILO Pompa S stemler A. . Orhanlı Mah. Fettah Ba aran Cad. No: 91, 34956, Tuzla, İstanbul T 0216 250 94 00 F 0216 250 94 01 w lo@w lo.com.tr www.w lo.com.tr P oneer ng for You www.wilo.com.tr...
