Summarization of Contents
General Notes
Intended Use
Describes the intended purpose and basic functionalities of the optris Xi infrared camera.
Warranty
Details the warranty period, terms, and conditions for the optris Xi infrared camera.
Scope of Delivery
Lists all items included in the package for the optris Xi infrared camera.
Maintenance
Provides guidance on the proper maintenance and cleaning procedures for the IR camera.
Model Overview
Presents an overview of the different Xi series camera models and their specifications.
Technical Data
General Specifications
Outlines general specifications such as environmental rating, dimensions, weight, and cable types.
Measurement Specifications
Details the measurement performance, including temperature ranges, spectral response, and detector.
Optical Specifications
Covers optical details like lenses, field of view, and resolution for precise measurements.
Mechanical Installation
Dimensions
Provides detailed dimensional drawings and mounting information for the Xi camera.
Air Purge Laminar
Details the air purge accessory for keeping the lens clean and improving measurement accuracy.
Water Cooling
Details the optional water cooling system for high-temperature applications and its components.
Shutter
Explains the optional shutter mechanism for protecting the camera optics and its operation.
Combination of Air Purge, Water Cooling and Shutter
Describes how to combine air purge, water cooling, and shutter accessories for integrated functionality.
Outdoor Protective Housing
Covers the use of an outdoor protective housing for camera operation in external environments.
Electrical Installation
Process Interface
Explains the connection and configuration of the process interface for data output and control.
Example for Fail-Safe Monitoring with PLC
Illustrates a practical example of setting up fail-safe monitoring using a PLC.
USB Cable Extension for Xi 400/640
Details how to extend the USB cable length for flexible camera placement.
Functions
Ethernet Xi 80/410/410 MT/1M
Covers the Ethernet interface setup, connectivity, and data transfer for specific Xi models.
Autonomous Operation Xi 80/410/410 MT/1M
Explains how to configure the camera for standalone operation without PC connection.
Use of Shutter
Describes the functionality and operation of the optional shutter mechanism for lens protection.
Software PIX Connect
Installation and Initial Start-up
Guides through the installation process and initial setup of the PIX Connect software.
Software Window
Provides an overview of the PIX Connect software's main window and its components.
Basis Features of the Software PIX Connect
Highlights the main features and capabilities of the PIX Connect software for IR camera control.
Emissivity
Definition
Defines emissivity and its importance in infrared thermometry for accurate temperature readings.
Determination of Unknown Emissivity
Describes methods for determining unknown emissivity values for accurate measurements.
Characteristic Emissivity
Explains factors affecting emissivity and how to use emissivity tables for reference.
