- Page 1 Jabra GO 6430 ™ User manual www.jabra.com...
-
Page 2: Table Of Contents
PaiRinG the headSet with youR Mobile Phone ..........13 JabRa link 350 uSb Bluetooth® adaPteR SetuP and connection ............................14 InstallInG and rUnnInG the Jabra pC sUIte ....15 JabRa Pc Suite featuReS ......................15 inStallinG the JabRa Pc Suite ....................15 JabRa Pc Suite docuMentation ..................15 enablinG add-on featuReS ....................15... - Page 3 RechaRGe ................29 PoweR Save Mode .........................29 StayinG within RanGe ........................30 MicRoPhone noiSe blackout™ ..................30 7.10 naRRowband vS. wideband audio ................30 7.11 hiGh caPacity JabRa Go inStallationS ..............30 7.12 ManaGinG Bluetooth® connectionS and the PaiRinG table ....31 Jabra GO 6430 User manUal...
- Page 4 Bluetooth® adaPteR ........................32 chaRGinG the headSet with the tRavel chaRGeR .........32 coMMunicatinG with a Pc ....................32 the Jabra lInK 350 Usb Bluetooth® adapter ....33 JabRa link 350 uSb Bluetooth® adaPteR diaGRaM ..........33 PuRPoSe of the JabRa link 350 uSb Bluetooth® adaPteR......33 PaiRinG the JabRa link 350 uSb Bluetooth®...
-
Page 5: Introduction
Thank you for selecting a Jabra GO™ 6430 headset solution. We are sure that you will enjoy its wide range of features and find it comfortable to wear and easy to use. the Jabra GO headset features extremely compact and light-weight construction, touch-panel volume control, fast recharge, wideband audio and dual noise blackout™... -
Page 6: Important Warnings And Safety Information
Intellitone™ hearing protection to set the Intellitone™ level, use the Jabra Control Center application on your pC. see the Jabra pC suite online help for details (see also Chapter 5 Installing and Running the Jabra PC Suite for more information about the pC software). -
Page 7: Care And Maintenance
If your Jabra devices require cleaning, then consider the following advice: - the headset, headband, neckband and ear hook can be wiped clean with a dry cloth if needed. -
Page 8: Product Overview
5 Ear hook 6 Alternative, differently-shaped earbuds 7 USB cable 8 Installation CD with Jabra PC Suite Software and other tools 9 Warning & Declaration guide and quick-start guide 10 Startup poster Figure 1: Components included with Jabra Go 6430... -
Page 9: Headset Diagram
2 Power and data port 3 Jabra LINK 350 USB Bluetooth® Adapter cradle 4 USB plug 5 LED activity indicators 6 Multifunction button Figure 3: Jabra Go 6430 travel Charger (left) and Jabra lINK 350 uSB bluetooth® Adapter (right) Jabra GO 6430 User manUal... -
Page 10: Optional Accessories
4 14121-21 2 x replacement ear hooks/3 x replacement earbuds 5 100-65090000-49 travel kit (with Jabra GO travel charger, car charger, bluetooth adapter, mains power adapter and Usb cable) 6 100-63400000-59 extra Jabra lInK 350 Bluetooth® adapter variant supports microsoft OC... -
Page 11: System Setup And Connections
SySteM SetuP and connectionS this chapter explains how to assemble your Jabra GO solution and connect it to your other office equipment. chaRGinG the headSet to charge the headset, insert it into the travel Charger and connect the mini-Usb port on the travel Charger to a power source as illustrated below. -
Page 12: Assembling The Headset
Figure 6: Assembling and wearing the Jabra Go headset in various styles Choose a style and assemble the headset so that it will fit to your preferred ear. see Section 7.2: Assembling or Changing the Wearing Style for detailed instructions. -
Page 13: Pairing The Headset With Your Mobile Phone
4. your phone now looks to see if any nearby bluetooth® wireless technology devices are advertising themselves for pairing. Use your phone’s controls to identify and select the Jabra GO 6400 device. your phone may also ask for the headset’s pass code. the pass code for all Jabra devices is 0000 (four zeros). -
Page 14: Connection
Bluetooth® adaPteR SetuP and connection JabRa link 350 uSb to connect the Jabra lInK 350 Usb Bluetooth® adapter and set it up for use with your computer and headset: 1. plug the Usb Bluetooth® adapter into the free Usb port on your pC. -
Page 15: Installing And Running The Jabra Pc Suite
Usb Bluetooth® adapter and a GO 6400 headset. to update the firmware of your Jabra GO 6430 solution, you need to update the firmware in two steps, first you update the Jabra lInK 350 Usb Bluetooth® adapter firmware and then you update the GO 6400 headset firmware via the travel charger. -
Page 16: Central Administration And Mass Deployment
MaSS dePloyMent If you are an It manager of an organization that is rolling out a large number of Jabra GO solutions, then you might wish to use the Jabra Control Center, which is part of the Jabra pC suite. -
Page 17: Daily Use - Calling, Answering And Hanging Up
In this case, when the call ends the target phone is the phone for which you accepted the call. for maximum convenience, set the target phone to the phone which you are most likely to use for outgoing calls. Jabra GO 6430 User manUal... -
Page 18: How To Make A Call
Tip: your voice tags may work better if you record them using the headset rather than your phone’s built-in microphone. this will make sure that the sound the phone “hears” coming from the headset when dialing will be the closest possible match to the recorded voice tag. Jabra GO 6430 User manUal... -
Page 19: How To Answer A Call
Note: If you are using an unsupported softphone, then you may need to use Jabra Control Center to activate the audio link from your pC to your headset before dialing. see the pC suite online help for details. -
Page 20: Hanging Up
- For softphones, your headset is likely to be your only option, but if other audio devices are connected to your pC, you may be able to switch to them by changing the audio preferences for Windows and/or your softphone program. Jabra GO 6430 User manUal... -
Page 21: Last Number Redial
Redial Jabra GO is able to send a redial command to the current target phone. this feature requires that the target phone supports the redial command; check your phones’ documentation for details. to use last-number redial with a phone that supports it: 1. -
Page 22: Listening To Music
Jabra Control Center and/or its icon in the Windows notification area to activate the audio link from the pC to the Jabra GO headset. provided no other phone lines are active, your headset will then begin to play all of the sounds generated by your pC, including music from your media player. -
Page 23: The Jabra Go Headset
Jabra GO headset in a variety of styles, each of which can be worn on either the left or right ear., as illustrated below. Figure 14: Wearing the Jabra Go headset in various styles Important: regardless of which wearing style you choose, always be sure to adjust the headset so that the microphone is positioned as close to your mouth as possible. -
Page 24: Replacing The Earbud
Pairing the Headset with a Jabra LINK 350 USB Bluetooth® Adapter to pair the headset to a Jabra lInK 350 Usb Bluetooth® adapter connected to your computer, place both units in pairing mode while they are close to each other. they will find each other automatically and then pair and connect to each other as needed. -
Page 25: Headset Controls And Signals
SiGnalS all Jabra GO headsets feature a collection of controls and indicators that enable you to manage and monitor your calls. these are: 1. Multifunction button this button is located near the back of the headset. through a combination of taps, double-taps, short presses and long presses, you will be able to execute all of the most-needed functions, including answering a call, hanging up, switching between held calls, and more. - Page 26 - slide your finger up the touch panel (away from your mouth) to increase the volume. - slide your finger down the touch panel to decrease the volume. - double-tap on the touch panel to mute or unmute the microphone. see also Section 6.6: Controlling the Speaker Volume and Microphone. Jabra GO 6430 User manUal...
- Page 27 (such as pairing failed) three quick tones followed by a lower long tone table 5: headset signal tones and their meanings Jabra GO 6430 User manUal...
- Page 28 Jabra Control Center program of the Jabra pC suite running on your pC. see the online help for complete details.
-
Page 29: Battery Indicators And Recharge
/ disable power save mode from the Jabra Control Center (it is disabled by default). If the sound is distorted with power save mode enabled, disable it, then turn the headset off and then back on again. -
Page 30: Staying Within Range
If you are talking through the Jabra lInK 350 Usb Bluetooth® adapter, then your call will be kept open for up to 120 seconds after you go out of range and then disconnected. -
Page 31: Managing Bluetooth® Connections And The Pairing Table
Jabra GO headset is able to hold up to 8 devices in its pairing table. If you add a ninth device, the headset will automatically remove an item from the table to make room for the new one. -
Page 32: Using The Travel Charger
Charger includes compartments for storing the headset on one side and the Jabra lInK 350 Usb Bluetooth® adapter on the other. these make it easy to bring a full Jabra GO solution with you and also prepare the headset to be charged. -
Page 33: The Jabra Link 350 Usb Bluetooth® Adapter
Jabra GO headset and Usb Bluetooth® adapter: 1. attach the Usb Bluetooth® adapter to your pC and turn on the pC (see also the section 4.4: Jabra lINK 350 uSB Bluetooth® Adapter Setup and Connections). -
Page 34: Jabra Link 350 Usb Bluetooth® Adapter Visual Indicators
- On the headset: the led flashes blue 5 times and then turns off. 6. your headset and Usb Bluetooth® adapter are now paired and connected. Figure 20: Jabra Go headset paired with both a mobile phone and the Jabra lINK 350 uSB bluetooth® Adapter Bluetooth® adaPteR viSual indicatoRS JabRa link 350 uSb the Jabra lInK 350 Usb Bluetooth®... -
Page 35: The Jabra Link 350 Usb Bluetooth® Adapter Mfb
JabRa link 350 uSb the Jabra lInK 350 Usb Bluetooth® adapter includes a single button, which you can use for many purposes depending on which state the adapter is in (e.g., waiting, active, call-on-hold) and the type of gesture you use on the button (i.e., tap or press). -
Page 36: Faqs And Troubleshooting
- make sure that the Usb Bluetooth® adapter is selected as the current audio device both in the Windows sound control panel and in the application you are using. - make sure the audio link to the pC is open (e.g. by right-clicking on the Jabra device service icon in the Windows notification area on your pC). - Page 37 Wi-fi. to ensure good sound quality, only the free channels are used. Q IS IT POSSIBLE TO LISTEN IN ON CALLS WITH THE JABRA GO 6430? a the risk of unauthorized access to communication via a Bluetooth® headset is very limited. Jabra GO 6430 uses 128 bit encryption.
-
Page 38: Getting Assistance
GettinG aSSiStance If you are having problems with your headset solution that are not addressed by the information in this manual, then please feel free to contact Jabra technical support at any the locations listed below. 11.1 euRoPe Web (for the latest support info and online User manuals): www.jabra.com... -
Page 39: Technical Specifications
85 db(a). these are also compliant with directive 2003/10/eC of the european parliament and Council of 6 february 2003. the tt4 protection level is compliant with pertinent australian recommendation. Jabra GO 6430 User manUal... -
Page 40: Headset Battery
(hsp 1.1), hands-free (hfp 1.5), device identification (dIp 1.3) Bluetooth® pairing table: Up to 8 trusted devices Simultaneous Bluetooth® connections: Up to 2 Bluetooth® audio bandwidth: narrowband or wideband Firmware update: downloadable from pC Jabra GO 6430 User manUal... -
Page 41: Travel Charger
12.6 tRavel chaRGeR Dimensions: 34mm x 83.5mm x 26.5mm Storage compartments: holds both Jabra GO headset and Jabra lInK 350 Usb Bluetooth® adapter Capacity: 5v / 500 ma Power and data port: mini Usb Connectivity:... -
Page 42: Certifications And Safety Approvals
Users are not permitted to make changes or modify the device in any way. Changes or modifications not expressly approved by Jabra will void the user’s authority to operate the equipment. this equipment has been tested and found to comply with the limits for a Class b digital device, pursuant to part 15 of the fCC rules. -
Page 43: Glossary
(puts the phone “on hook”). Jabra® PC Suite a collection of pC programs that enable you to configure your Jabra device, update its firmware and control supported softphones using the buttons on your headset. the Jabra pC suite also includes drivers for various softphones on the market. - Page 44 Softphone driver establishes a control link between a softphone and your Jabra headset, so you can answer and end, mute and un-mute, and hold and resume calls using the buttons on your headset. the actual call control functions available from your headset depend on the capabilities of the softphone and the Jabra headset model.
- Page 45 © 2009 GN Netcom A/S. All rights reserved. Jabra is a registered ® trademark of GN Netcom A/S. All other trademarks included herein are the property of their respective owners. The Bluetooth word ® mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by GN Netcom A/S is under license.
