- Page 1 JABRA EVOLVE 65 User Manual jabra.com/evolve65 Downloaded from www.Manualslib.com manuals search engine...
- Page 2 © 2014 GN Netcom A/S / GN Netcom US, Inc. All rights reserved. ® Jabra is a registered trademark of GN Netcom A/S. All other trademarks included herein are the property of their respective ® owners. The Bluetooth word mark and logos are owned by the Bluetooth SIG, Inc.
-
Page 3: Technical Specifications
1. WELCOME .......... 4 2. JABRA EVOLVE 65 OVERVIEW ... 5 2.1 STEREO VARIANT 2.2 MONO VARIANT 2.3 OPTIONAL ACCESSORIES (STEREO AND MONO) 3. HOW TO WEAR ........7 3.1 STEREO AND MONO 3.2 ADJUST THE HEADBAND 3.3 POSITION THE MICROPHONE 3.4 STORING THE MICROPHONE... -
Page 4: Welcome
1. WELCOME Thank you for using the Jabra Evolve 65. We hope you will enjoy it! JABRA EVOLVE 65 FEATURES ƒ Connects to PC via Jabra Link 360 bluetooth adapter or USB cable ƒ Connects to mobile devices via Bluetooth ƒ... -
Page 5: Jabra Evolve 65 Overview
2. JABRA EVOLVE 65 OVERVIEW 2.1 STEREO VARIANT Magnetic microphone groove Adjustable headband Volume up Busylight indicator Multi-function button Volume down USB connect & Battery charging port indicator Microphone boom-arm Bluetooth indicator On/off/connect switch JABRA EVOLVE 65 Downloaded from www.Manualslib.com... -
Page 6: Mono Variant
Volume up Busylight indicator Multi-function button Volume down USB connect & Battery charging port indicator Microphone boom-arm Bluetooth indicator On/off/connect switch 2.3 INCLUDED ACCESSORIES (STEREO AND MONO) Carry pouch USB cable JABRA EVOLVE 65 Downloaded from www.Manualslib.com manuals search engine... -
Page 7: How To Wear
3. HOW TO WEAR 3.1 LEFT OR RIGHT WEARING STYLE The Jabra Evolve 65 can be worn on the left or right by flipping the microphone to the other side (270° limit). 270° JABRA EVOLVE 65 Downloaded from www.Manualslib.com manuals search engine... -
Page 8: Adjust The Headband
3.2 ADJUST THE HEADBAND Adjust the headband to find the most comfortable fit. 3.3 POSITION THE MICROPHONE It is recommended to position the microphone close to your mouth (0.5 inches). JABRA EVOLVE 65 Downloaded from www.Manualslib.com manuals search engine... -
Page 9: Storing The Microphone
The microphone is bendable for personal preference. 3.4 STORING THE MICROPHONE When listening to music or outdoors, the microphone can be magnetically stored in the headband groove. JABRA EVOLVE 65 Downloaded from www.Manualslib.com manuals search engine... -
Page 10: How To Charge The Battery
The headset can still be used for calls while charging using a USB cable connected to a PC. It takes approx. 3 hours to charge the battery. JABRA EVOLVE 65 Downloaded from www.Manualslib.com manuals search engine... -
Page 11: How To Connect
5.1 CONNECT TO PC (USING JABRA LINK 360) 1. Ensure the headset is switched on. 2. Plug the Jabra Link 360 dongle into a USB port on your PC. The headset and Jabra Link 360 are already pre-connected. JABRA EVOLVE 65 Downloaded from www.Manualslib.com... -
Page 12: Connect To Mobile Device
2. Hold (3 secs) the On/off/connect switch in the connect position until you hear the voice guided instructions. The Bluetooth indicator will flash blue. 3. Follow the voice guided instructions to connect. JABRA EVOLVE 65 Downloaded from www.Manualslib.com manuals search engine... - Page 13 5.3 CONNECT TO PC (USING USB CABLE) 1. Ensure the headset is switched on. 2. Plug the headset into a USB port on your PC using the supplied USB cable. JABRA EVOLVE 65 Downloaded from www.Manualslib.com manuals search engine...
-
Page 14: How To Use
6. HOW TO USE Volume up Busylight indicator Multi-function button Volume down USB connect & Battery charging port indicator Bluetooth indicator On/off/connect switch JABRA EVOLVE 65 Downloaded from www.Manualslib.com manuals search engine... -
Page 15: Everyday Use
Volume down buttons on/off Enable/disable Simultaneously press and hold Busylight (3 secs) the Volume up and function Volume down buttons Mute/unmute Press and hold (2 secs) the microphone Volume down button JABRA EVOLVE 65 Downloaded from www.Manualslib.com manuals search engine... -
Page 16: Multiple Call Handling
Multi-function button Press and hold Put current call on hold (2 secs) the and answer incoming call Multi-function button Double-tap Reject incoming call, the Multi- when on a call functionbutton JABRA EVOLVE 65 Downloaded from www.Manualslib.com manuals search engine... -
Page 17: 6.3 Busylight
Volume up and Volume down buttons at the same time. ENABLE/DISABLE BUSYLIGHT FUNCTION To enable/disable the busylight function, press and hold (3 secs) both the Volume up and Volume down buttons at the same time. JABRA EVOLVE 65 Downloaded from www.Manualslib.com manuals search engine... -
Page 18: How To Care For Your Headset
7. SUPPORT 7.1 FAQ View the FAQs on Jabra.com/evolve65 7.2 HOW TO CARE FOR YOUR HEADSET ƒ Always store the headset with the power off and safely protected. ƒ Avoid storage at extreme temperatures (above 55°C/131°F or below -10°C/14°F). This can shorten battery life and may adversely affect the headset. -
Page 19: Specifications
8. TECHNICAL SPECIFICATIONS JABRA EVOLVE 65 HEADSET SPECIFICATION Mono headset: 79 g Headset weight: Stereo headset: 111 g Mono headset: L 154.4 mm x W 58.6 mm x H 170.4 mm Headset dimensions: Stereo headset: L 155.5 mm x W 58.6 mm x H 170.5 mm... - Page 20 Bluetooth range: Up to 100m (300 feet), Class 1 Bluetooth profiles: A2DP (v1.2), Hands free profile (v1.6) Simultaneous Bluetooth connections: Bluetooth audio bandwidth HD voice (wideband), A2DP Visual indicators: Multicolor LED JABRA EVOLVE 65 Downloaded from www.Manualslib.com manuals search engine...
- Page 21 JABRA EVOLVE 65 Downloaded from www.Manualslib.com manuals search engine...
