Summarization of Contents
General Information
Important Safety Instructions
Read manual. Use by children from 8+ and reduced capability persons with supervision. Avoid hazards.
Unpacking and Installation
Remove pallet, packing, and protection foil. Ensure proper setup for safe operation and appliance longevity.
Electrical Connection
Operates on 220-240 V/50 Hz. Ensure accessible socket, correct earthing. Main connections require skilled electricians.
Cabinet Start-Up Procedure
Clean cabinet before use. Wait 2 hours if placed horizontally during transport before initial start-up.
Thermostat Settings and Operation
Located in the bottom panel. Pre-set settings typically don't need adjustment. Display shows current cabinet temperature.
Automatic and Manual Defrosting
Cabinet defrosts automatically at intervals. Manual defrost can be initiated by pressing a key. Defrosted water evaporates.
Shelf and Door Adjustments
Move shelves by squeezing guides. Ensure shelves are level. Door reversal is for single door models only.
Cleaning and Maintenance Guide
Periodically clean with mild soap. Avoid high-pressure water and harsh cleansers. Clean condenser using a vacuum cleaner.
Service and Disposal Information
Cooling system needs no supervision. Contact supplier for issues. Dispose of unit environmentally correctly per regulations.
DT-01 Technical Manual
Set Point Configuration
Check or change set point temperature using SET, 'v', or '^' keys. Value is stored automatically after setting.
Parameter Adjustment Procedures
Enter programming mode by pressing SET+'v'. Select, display, and change parameters. New values are stored automatically.
Keyboard Lock and Unlock
Press 'v' and '^' keys simultaneously for 3s to lock/unlock keyboard. Display shows 'oF' or 'on'.
Manual Defrost and Alarm Codes
Initiate manual defrost by pressing a key. Understand alarm codes like 'P1' (probe failure) and temperature alarms.
DT-01 Parameter List
Detailed list of DT-01 controller parameters including Set point, Differential, Min/Max set points, and various delays.
