2. Undo the retaining screw.
3. Lift out the foam block with its tools.
4. Lift out the spare wheel.
The lower foam block does not need to be lifted
out.
Tools - returning into place
The tools and jack* must be returned to their
correct places after use. The jack must be
cranked together to the correct position in
order to have space.
The foam block and spare wheel must be
replaced in the reverse order to taking out.
Note that there is an arrow on the upper foam
block. It must point forwards in the car.
IMPORTANT
The tools and jack* must be stored in the
intended location in the car's cargo area
when not in use.
Changing wheels
Removing
Set up the warning triangle, see page 217 if a
wheel must be replaced at a busy location. The
car and jack* must be on a firm horizontal sur-
face.
1. Apply the parking brake and engage first
gear, or position P if the car has an auto-
matic gearbox.
06 Maintenance and service
Wheels and tyres
WARNING
Check that the jack is not damaged, that the
threads are thoroughly lubricated and that it
is free from dirt.
NOTE
Volvo recommends only using the jack* that
belongs to the car model in question.
2. Take out the spare wheel*, jack* and wheel
wrench* that are located under the cargo
area floor in the cargo area. If another jack
is selected, see page 228.
3. Place chocks in front of and behind the
wheels which will remain on the ground.
Use heavy wooden blocks or large stones.
*
Option/accessory, for more information, see Introduction.
