KYMCO 125 QUANON Specifications

125 QUANON
TECHNICAL
SPECIFICATIONS
Dimensions L/l/H (mm)
Weight
Type
Cooling system
Gearbox
Engine capacity
Power (kW / revs/min)
Maxi torque (Nm / revs/min)
Brake type
Tyres Front/Rear
AVAILABLE COLOURS
Technical specifications are provided for information only and are not contractual. Technical specifications are provided for information only and are not contr
See terms and conditions in Stores. KYMCO Assistance-Breakdown and KYMCO Insurance, only valid for Mainland France. KYMCO Financing, only valid for Belgium.
2080 x 710 x 1160
141 Kg
4-stroke - OHC
Air + Oil
5 Gears
124.1 cm3
9.6 / 10000
9.8 / 7500
FRONT: Disc
REAR: Disc
FRONT: 110 / 80-17
REAR: 140 / 70-17
Yellow/Black - Red/Black ck c
