Summarization of Contents
General Safety Information
Product Service Warning
Warning that service information is for experienced technicians only.
Important Safety Notice
Highlights critical safety parts and the need for manufacturer-specified replacements.
Disassembly Instructions
Removal of Rear Handle Cover
Instructions for removing the rear handle cover by unscrewing and pulling.
Removal of Terminal Screw
Steps to remove screws holding the cord, indicator light, and control circuit.
Removal of Temperature Selector Dial
Procedure to remove the temperature selector dial by turning and lifting.
Removal of Handle Cover (A)
Guidance on removing Handle cover (A) and related components.
Removal of Handle Assembly
Steps to detach the handle assembly and its associated parts.
Removal of Water Tank
Instructions for removing the water tank by unscrewing.
Removal of Heat-Insulated Plate
Process for removing the heat-insulated plate and packing.
Removal of Auto-Valve Assembly
Steps to remove the auto-valve assembly and disc bimetal.
Directions for Reassembly
Installation of Heat-Insulated Plate
Guidance on reinstalling the heat-insulated plate with dial orientation.
Installation of Temperature Selector Dial
Instructions for installing the temperature selector dial at maximum position.
Connection of the Cord
Procedure for correctly wiring the AC power cord and indicator light.
Schematic Diagram
Visual representation of the electrical circuit for reference.
Testing Procedures
Temperature Test Method
Detailed steps to test temperature control using an ohmmeter.
Steam Test
Procedure for testing the steam generation and function of the iron.
