OWNER'S MANUAL
PURE FLAT AV STEREO TELEVISION
51CM CORDLESS REMOTE COLOUR TELEVISION
MODEL: 5110PF
Type Tested
Electrical
Safety
AS/NZS 3250 Lic 4166
Standards Australia
APP No: N15899
PALSONIC CORPORATION PTY LTD
1 JOYNTON AVENUE
WATERLOO NSW 2017 AUSTRALIA
TEL:(02)9313 7111
FAX:(02)9313 7555
www.palsonic.com.au
PALSONIC CUSTOMER SERVICE
TELEPHONE
AUSTRALIA:1300 657 888

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MODEL 5110PF and is the answer not in the manual?

Questions and answers

Related Manuals for Palsonic MODEL 5110PF

Summary of Contents for Palsonic MODEL 5110PF

  • Page 1 51CM CORDLESS REMOTE COLOUR TELEVISION MODEL: 5110PF Type Tested Electrical Safety AS/NZS 3250 Lic 4166 Standards Australia APP No: N15899 PALSONIC CORPORATION PTY LTD 1 JOYNTON AVENUE WATERLOO NSW 2017 AUSTRALIA TEL:(02)9313 7111 FAX:(02)9313 7555 www.palsonic.com.au PALSONIC CUSTOMER SERVICE TELEPHONE...

  • Page 2: Table Of Contents

    Congratulations on your purchase of this Palsonic colour television receiver. We recommend that you thoroughly read this manual before use to fully enjoy the many functions and excellent effects of this receiver. Retain this manual in an easily accessible location for future reference.

  • Page 3: Introduction Features

    INTRODUCTION Features 51cm pure flat picture tube Hyperband English/Chinese on-screen menu display 100 preset channels Auto-search, manual search Intellectualized I C-bus control Sleep timer, Auto Power-Off & blue background display Full function remote control Four picture mode setting AUDIO/VIDEO input & output terminals S-VIDEO terminal Advanced picture improvement circuit 1.

  • Page 4: Notes For Operation

    NOTES FOR OPERATION Do not let the TV set be in stand-by condition for a long period of time. When it is not in use, please turn off the power supply and remove the power plug. When it is to be left unattended for a prolonged period of time, it is recommended to disconnect the connection to the outdoor aerial, to avoid thunder strike.

  • Page 5: Installation Antenna Connection

    Installation Antenna Connection To ensure a bright-coloured and clear picture, you should use an outdoor aerial or CATV cable. If the signals are strong enough, you may use an indoor aerial. Note: In case of using the Twin-lead aerial feeder (300 ) for UHF/VHF aerial, use a 300-75 ohm adaptor (not supplied) When using the coaxial cable (not...

  • Page 6: Appearance Front View

    Appearance Front view POWER SWITCH (2) Video 2 input terminals TV/AV CHANNEL UP {VIDEO, AUDIO L/MONO, R} MENU CHANNEL DOWN VOLUME DOWN VOLUME UP Note: Functions of MENU, TV/AV, are also provided to the remote controller. Back View Antenna input MONITOR output terminals {VIDEO, AUDIO L/MONO, R} S-VIDEO...

  • Page 7: Remote Controller

    Appearance Remote Controller...

  • Page 8: Operation

    OPERATION Turning the Power On/Off The following describes how to turn the TV on/off using the TV's main switch and the remote controller. To turn the power on/off 1. Press the POWER switch, the red power indicator lights up. If no picture appears on the screen, press the button or any one of 0~9 number buttons on the remote controller to turn the set on.

  • Page 9: Tuning In

    OPERATION Tuning in There are two ways to preset channels: to preset channels automatically and to preset channels manually. Below we will describe how to preset the channels by making use of the menu. To preset channels (Auto search) Use the AUTO SEARCH function to preset all the active channels in your local area automatically.

  • Page 10: To Preset Channels (Manual Search)

    OPERATION Tuning in (continued) Use the MANUAL SEARCH function if desired channels can not be preset with the AUTO- SEARCH or if you would like to preset channels to specific position numbers one by one. It is convenient to set the channel numbers to the same position numbers using MANUAL SEARCH and SKIP functions.

  • Page 11: To Skip Unnecessary Position Numbers

    OPERATION Tuning in (continued) To skip unnecessary position numbers and MFT (Manual Fine Tuning) To skip a position number After presetting the channels, you can skip unnecessary position numbers so that only the channels you want to watch are selected. POS.MEMORY POSITION 1.
  • Page 12 OPERATION Tuning in (continued) The setting of colour and sound system Press the SYS button, the colour and sound system COLOR AUTO will be displayed on the screen. SOUND BG SELECT ADJUST If the colour is abnormal, press the button to select COLOR, then press the COLOR AUTO button to select the proper colour system.

  • Page 13: Channel Selection

    OPERATION Channel selection You can watch TV programmes being broadcast on the preset channels. To watch a TV programme You can select your desired TV program by one of the following methods. Using the direct select buttons To select a one-digit position number, press the -/-- button to display "-"...

  • Page 14: Convenient Picture Controls

    OPERATION Convenient Picture Controls Selectable picture To select the picture mode You can select the picture quality instantly among three preset modes and one user-set mode. Press the P.S button to select the desired picture quality. MEMORY1, MEMORY2, MEMORY3 and MEMORY 4 (user-set) MEMORY 1 can be selected cyclically.

  • Page 15: Convenient Sound Controls

    OPERATION Convenient Sound Controls Adjusting the volume and muting the sound To adjust the sound volume Adjust the sound volume with the VOL buttons. Press the VOL button to decrease the sound. Press the VOL button to increase the sound. VOLUME ! ! ! ! ! ! ! .

  • Page 16: Other Functions

    OPERATION Other functions Sleep timer and to select the language for the OSD SLEEP timer Making use of the Sleep timer function allows you to have the set automatically turned off after a preset time. Press the SLP button every time, the time displaying on the screen will change in the sequence below: SLEEP:30MIN.

  • Page 17: Connecting Other Equipment

    CONNECTING OTHER EQUIPMENT External Equipment Connections The following describes how to use and connect the TV with other AV equipment. Refer to the owner’s manual of the equipment to be connected as well. To connect AV input terminal You can connect video equipments such as a VTR and video camera to this TV and enjoy the high quality picture and sound.

  • Page 18: To Connect Monitor Output Terminals

    CONNECTING OTHER EQUIPMENT To connect AV input terminal (continued) To select the video input, press TV/AV the button on the TV set or AV button on the remote controller repeatedly until you see the corresponding input indication on the screen. To return to aerial input, press the AV button until it displays program number, or press channel select button or the CH button.

  • Page 19: Others

    OTHERS Troubleshooting Guide Before calling service personnel, please check the following chart for a possible cause to the trouble you are experiencing. Check the following items Symptoms No power, red indicator is not lit up Be sure the power cord is plugged in. Contrast, colour, tint are not correctly Poor colour, poor tint adjusted...
  • Page 20 PALSONIC CORPORATION PTY LTD 1 JOYNTON AVENUE WATERLOO NSW 2017 AUSTRALIA TEL:(02)9313 7111 FAX:(02)9313 7555 www.palsonic.com.au PALSONIC CUSTOMER SERVICE TELEPHONE AUSTRALIA: 1300 657 888 604-21F83-00...
