Palsonic MODEL 6738 Owner's Manual

Palsonic MODEL 6738 Owner's Manual

Teletext 67cm cordless remote colour television
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
OWNER'S MANUAL
Type Tested
Electrical
Safety
AS/NZS 3250 Lic 4166
Standards Australia
APP No: N15956
TELETEXT
67CM CORDLESS REMOTE COLOUR TELEVISION
MODEL:6738
TELETEXT
This set is fitted with a teletext system that you can receive by tuning to
Channel 7. Please note that your selected page number may take a few
minutes to appear on the screen. This is not a fault. The broadcast of
the system is slow.
PALSONIC CORPORATION PTY LTD
1 JOYNTON AVENUE
WATERLOO NSW 2017 AUSTRALIA
TEL:(02)9313 7111
FAX:(02)9313 7555
www.palsonic.com.au
PALSONIC CUSTOMER SERVICE
TELEPHONE
AUSTRALIA:1300 657 888

Advertisement

Table of Contents
loading

Related Manuals for Palsonic MODEL 6738

Summary of Contents for Palsonic MODEL 6738

  • Page 1 Channel 7. Please note that your selected page number may take a few minutes to appear on the screen. This is not a fault. The broadcast of the system is slow. PALSONIC CORPORATION PTY LTD 1 JOYNTON AVENUE WATERLOO NSW 2017 AUSTRALIA...

  • Page 2: Above All

    This equipment has been designed and manufactured to meet the highest international standards, but, like any electrical apparatus which is operated at mains voltage, care must be taken if you are to obtain the best results and safety is to be assured. This is particularly important with audio and TV equipment.

  • Page 3: Power On/Off Switch

    SOUND II INDICATOR STEREO INDICATOR SOUND I INDICATOR EXTERNAL SPEAKERS EX./IN SPEAKER SWITCH AUDIO OUTPUT ANTENNA INPUT PUSH OPEN POWER SWITCH VIDEO OUTPUT VIDEO INPUT PROGRAM POWER INDICATOR AUDIO INPUT POWER CORD VOLUME STAND BY INDICATOR INFRARED SENSOR OPERATING INSTRUCTION: POWER ON/OFF SWITCH Press the Power Switch, the appliance will be in "STANDBY"...

  • Page 4: Tuning Channels

    The TV set tunes forty numbers and it is possible to put any channel on any number. There are two ways to choose the channel number you want-the single-number method and the double-number method. Single-digit Method (highest Program Number is 9) This allows numbers 0 ~ 9 ONLY and is useful for limiting the number of channels if you do not mind some channels on the wrong number (10 and 28 could be put on 1 and 0, for instance).
  • Page 5 VHF-1 lllllllll------- When the set finds a TV signal, it will stop searching automatically, and show the TV picture on the screen. The tuning is optimised for strong signals. Weak signals may need fine tuning for the best result. If you want another channel, press the SEARCH button again. The station may be fine-tuned with the FT (-/+) buttons for the best picture and sound if the auto-search result is not satisfactory.
  • Page 6 STORE PP STORE - STORE PP Press STORE button Press PP button Press STORE button again The settings of picture and sound will be stored in memory until you reset them. TELETEXT PAGE NUMBER STORE (Please read the Teletext section before using this procedure) The remote control unit has four colour-coded buttons.
  • Page 7 CLEAR The CLEAR button allows you to SKIP unwanted numbers so that you can tune 2, 7, 9, 10 without intermediate steps. The procedure is the same as STORE- just substitute CLEAR for STORE in the procedure: Press CLEAR, choose the number, press CLEAR again. The number attached to "CLEAR -"...
  • Page 8 TELETEXT- a short technical description This TV set displays Teletext information which includes stock market reports, TAB betting, weather forecasts, and other useful material. In Australia, the Teletext service is sent by the Seven Network, although other channels send subtitles for the hearing impaired with programs marked by (S) in the TV guides. The guides are not always correct! To get the full Austext service, the set must be tuned to the Channel 7 Network.
  • Page 9 Colour Memory - The set is fitted with a four-page memory to speed up operation and make it more convenient to use. If you are interested in Stock Market Reports or TAB betting, then the four most used pages would be set on these four colour-coded buttons and be instantly available.
  • Page 10 USING TELETEXT FOR THE FIRST TIME Using Teletext for the first time can be a bad experience. Follow these hints and tips to gain confidence. If something unexpected happens, read these tips first. It is very unlikely that the set is faulty, Your answer may be here. The most important button on the Remote Control is Button (14) (the blank screen symbol).
  • Page 11 indoor antenna, try moving it around. You will not be able to change channels unless you exit Teletext first. Press button (14) first - then change channels. The Seven Network sends Austext information in 800 pages. The main index for this is page 100.

  • Page 12: Remote Control Unit

    REMOTE CONTROL UNIT The remote control unit allows almost everything to be adjusted from the armchair. 1 STAND BY PP 8 19 RECALL DIGITAL BUTTON 20 6,7 PR(+/-) 14 TV 12 DIGITAL SELECT OR PAGE MUTE 9 13 AV VOLUME UP/DOWN 5 25 BALANCE LEFT/RIGHT 10 SLEEP BRIGHTNESS UP/DOWN 2...
  • Page 13 BUTTON LIST The trick is to push the buttons slowly; it takes a moment to register. Be careful that the button does not lock down. Some buttons behave differently in TV and Teletext. The following list is grouped according to TV or Teletext. If the description of a button is missing in one list, it will be found in the other.

  • Page 14: Digital Keyboard

    20. DIGITAL KEYBOARD In single-digit mode, press these buttons to select any of 0~9 channels. In double-digit mode, press these buttons to select any of 00~39 channels. 25. BALANCE LEFT/RIGHT ( Press these two buttons to balance the Sound between left and right. The left button reduces the volume of the right speaker;...
  • Page 15 press "+" press "+" S100 S102 S101 press "-" press "-" 15. TELETEXT ( This button activates Teletext and puts the Teletext display on the screen. 16. CANCEL (X) This button is used to return to TV while Teletext is searching for a page. The search continues in the background, and when the page is found it puts the page number on the upper left of the TV picture.
  • Page 16 The Model 6738 is fitted with full performance Stereo Theatre Sound where the internal speakers are ducted to the front of the set for maximum stereo effect. The Model 6738 is fitted with separate bass and treble controls available on the front panel and these should be used to give the most enjoyable results tailored to your own taste in sound.
  • Page 17 AUDIO OUTPUT AND DISPLAY ON SCREEN Transmission Mode Display on Screen Audio Output STEREO : MONO Ineffective Mono STEREO Stereo Stereo MONO Mono (Forced) Sound I DUAL I Dual. Sound DUAL II Sound II CONNECTING A VCR TO THE TV SET This TV set has AUDIO/VIDEO input and output sockets on the back panel which allow direct connection to a VCR using the AV Button (13).

  • Page 18: Connection Diagrams

    CONNECTION DIAGRAMS 1. VIDEO PLAYBACK/RECORD This is the usual connection where Audio/Video is taken out of the VCR and is connected IN to the TV set. The material being played on the VCR can be viewed on the TV screen by pressing the AV Button (13).
  • Page 19 3. DUBBING The figure below shows how to connect TWO VCRs to the TV for dubbing one from the other. Press AV button on the remote control unit to select AV mode before dubbing, "AV" will be displayed on the screen. The TV set will act as a monitor to help you edit while dubbing. NOTE: The set MUST remain in AV mode and MUST NOT be switched off during the session.

  • Page 20: Connecting External Speakers

    CONNECTING EXTERNAL SPEAKERS You can connect speakers to the EXTERNAL SPEAKER terminals on the TV set to enhance sound from the TV. Note: Before connecting the external speakers, turn off your TV set. 1 Connect Speaker Leads While pressing the button, insert the wire into the hole as shown below, and then release the button.

  • Page 21: Troubleshooting

    TROUBLE SHOOTING If any problem arises in the operation of your set, first check through this list of symptoms and correction. Should the problem be unsettled, unplug the set and contact your dealer. Try these adjustment Check these things Symptoms Press POWER BUTTON Be sure power cord is plugged in.

  • Page 22: Specifications

    Specifications : CCIR PAL, B/G; NTSC PLAYBACK Colour System: : VHFL 0-3; VHFH 4-11; UHF 21-69 Receivers Channel : S1-S41 (OPTION) Cable Channel : WST FLOF TELETEXT Teletext : FULL REAL STEREO Stereo : AC 240V, 50Hz Power supply : 67cm Flat Square Picture Tube : 2 x 7W Max : 2 x 5W 10% THD Audio Output : VHF/CATV/UHF 75 ohm...
  • Page 23 PALSONIC CORPORATION PTY LTD 1 JOYNTON AVENUE WATERLOO NSW 2017 AUSTRALIA TEL:(02)9313 7111 FAX:(02)9313 7555 www.palsonic.com.au PALSONIC CUSTOMER SERVICE TELEPHONE AUSTRALIA: 1300 657 888 604-71263-00...
