500484
GB-0612.2
If you have technical questions please state ident. no., which is on the machine sign. We recommend that you write this
number here:
Type: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Year: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Changes of technical details in relation to specifi-
cations and sketches in this instruction are subject
to alteration.
epoke
Instruction manual
TK, TMK
Valid from ident. no. xxxx0200
Valid from ident. no.:
TK:
TKG12
TK12E
TK12E-275
TKB9-280
TKB12-280
TMK:
TMK10
TMK10-275
TMK7
TMK7GT
This instruction answers important questions regar-
ding safety, operation, maintenance and technical
data.
®
Ident. no.: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
11010200
12100200
12110200
11070200
11080200
14000200
14050200
14040200
14060200
Published and printed by
Epoke
A/S,
®
Documentation department

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TMK10 and is the answer not in the manual?

Questions and answers

Related Manuals for Epoke TMK10

Summary of Contents for Epoke TMK10

  • Page 1 Ident. no.: ..........Instruction manual TK, TMK Valid from ident. no. xxxx0200 Valid from ident. no.: TKG12 11010200 TK12E 12100200 TK12E-275...

  • Page 3: Table Of Contents

    Certificates 2.1.10 Oil (TKG12) ......8.1.1 EU certificate of conformity TK ... 27 2.1.11...

  • Page 4: Identification

    • Design changes to the spreader which are not perfor- 1.1.2 Technical documentation med or approved by the manufacturer. This technical documentation contains: • Use of non-EPOKE original spare parts • An instruction book • Inadequate monitoring of parts which are exposed to • List of spare parts wear.

  • Page 5: Model And Type Specification

    TMK7 facture of machines, see item 8. TMK7GT Type: 1.6.1 Directives applied (89/392/EEC - 14.06.1989) (91/368/EEC - 20.06.1991) Ident. no.: 11010200 (TKG12) (93/44/EEC - 14.06.1993) 12100200 (TK12E) (93/68/EEC - 22.07.1993) 12110200 (TK12E-275) 98/37/EF - 22.06.1998 11070200 (TKB9-280) 14000200 (TMK10) 1.6.2 Standards applied...

  • Page 6: Descriptions

    TK, TMK ® GB-0306.1 2 Descriptions 2.0.2 Information on restrictions on use 2.0.2.1 Normal use 2.0.0 General Machines for winter service are machines for Important instructions are highlighted in each section. removing winter obstacles in traffic areas, and spreaders are machines for defined spreading Explanations of symbols of thawing materials or sand on surfaces carrying traffic.

  • Page 7: General

    Permitted axle load ..... . .1500 kg All EPOKE spreaders and equipment can be Supporting load on draweye ....640 kg operated by one person.

  • Page 8: Reference To Safety Measures For Specific Operating Conditions

    TK, TMK ® GB-0306.1 2.1.3 Reference to safety measures for specific operating conditions 2.1.3.1 Safety measures • The tow plate of the spreader must be vertical when the vehicle is loaded. • The depth of the tyre tread pattern must be min. 1.6 For information on air pressure in the road tyres, see section 2.3.2.

  • Page 9: Work Safety

    • Only the spare parts approved and recommended by the manufacturer must be used. Please use the original Epoke-spare parts only. • After repair, safety devices must be correctly fitted again. • It is not allowed to drive without safety devices.

  • Page 10: Guidelines For Chains

    Chocks must be avoided, especially in cold weather. 2.1.10 Oil (TKG12) Only the original chains supplied by the manufacturer. The chains must never be twisted, and no knots must be When using liquids, skin contact and inhalation of vapours tied, see fig.

  • Page 11: Product Descriptions

    TK, TMK epoke ® GB-0306.1 2.2 Product descriptions 2.2.0.1 Machine overview 2.1.1 1.1.1 2.2.1 2.1.2 1.1.3 2.2.2 2.2.3 3.7.1 3.7.2 3.4.1 2.2.1 3.4.2 2.2.3 1.1.1 TK 3.4.1 Spring base 1.1.3 TMK 3.4.2 Spring base stop Spring base adjustment 2.1.1 Rubber edges 2.1.2 Flexible rubber front protects the rubber edged...

  • Page 13: Product Description

    The dosing unit is situated under the mixer shaft, consists In the TK series, the design of the TKG12 differs from the of the spring-supported rubber base and the delivery TK12E by being equipped with a 4-step gear between the drum, whose function is to dose the material to the road wheel and drum.

  • Page 14: Dosage System

    TK, TMK epoke ® GB-0306.1 2.2.4...
  • Page 15 The pressure is varied by the adjust- ment handle at the rear of the spreader. 3 Possibility for demounting defect impellor springs. 9 Gearing (TKG12): The spreader is supplied with a 4- speed gearbox. 4 The delivery roller is provided with cams (A) which...

  • Page 16: Technical Data

    TK, TMK epoke ® GB-0612.2 2.3.1 Technical data Model TKG 12 TK12E TK12E-275 TKEB9-280 TKB12-280 Hopper capacity, m Track gauge, mm 1500 1500 1500 1800 1800 Total width, mm 2494 2494 2750 2800 2800 Spreading width - min., mm 2200...

  • Page 17: Dimensioned Sketch

    TK, TMK ® GB-0306.1 2.3.2 Dimensioned sketch TKG12, TK12E 2494 mm - TKG12/TK12E 2750 mm - TKE12E-275 2800 mm - TKEB9-280 1500 / 1800 2216 / 2522 TMK10 / TMK7 1966 mm - TMK7, TMK7GT 2494 mm - TMK10...

  • Page 18: Diagrams

    2.5 Corrosion protection 3. Disconnect supply cables (electricity). 4. Disconnect guide chains. All Epoke-products were sandblasted with steel balls, zinc 5. Disconnect the spreader. dusted with 1-component epoxyester (does not apply to 6. There must be no persons between the spreader and non-corrosion-resistant components), first coated with 2- the vehicle.

  • Page 19: Operating Levers

    TK, TMK min. amount. Position “sand” and max. gives greatest possible amount. TKG12, TK12E Quantity control: The quantity control is done in differring the pressure of the spring base against the delivery roller. The pressure is varied through the handle at the rear of the spreader.

  • Page 20: Instructions For Initial Operation Fill Up With Oil Before Use

    TK, TMK epoke ® GB-0306.1 5.2 Instructions for initial operation Gritting Do not drive with engaged delivery roller without material 5.2.1 Fill up with oil before use in the hopper in order to prevent unnecessary wear of the Fill up the gearbox with oil before starting a new machine rubber base.

  • Page 21: Instructions For Preparations

    TK, TMK ® GB-0306.1 5.4 Instructions for preparations .4.2 Remote control 5.4.1 Attachment to the towing vehicle 5.4.2.1 Correct installation Safety chains for tow-behind with short driving gear Direct current requirements for the electric control system Limits the impact angle, meaning that the right and left of the spreader: 11V - 32V.

  • Page 22: Procedure In Case Of Failure

    Spring base: Defect springs are to be replaced. When the 6.2.1 Cleaning spring base is wide open, the points of the springs must All Epoke spreaders have been sandblasted, zinc dust be in line. primed and primed before being painted with laquer, and they are therefore extremely well-protected against rust.

  • Page 23: Inspection List - Mechanical

    TK, TMK ® GB-0306.1 6.3.1 Date: Machine: Inspection list - mechanical Signed: Measure size and test size. To be checked Interval Result of Comment Pos. inspection Operational means and con- sumption means 1 Flanged bearings: At the delivery roller and...
  • Page 24 TK, TMK epoke ® GB-0306.1 6.3.1 Date: Machine: Inspection list - mechanical Signed: Measure size and test size. Comment To be checked Interval Result of Pos. inspection Operational means and con- sumption means 11 Coupling 100 h Check that the ratchet is working freely, alternatively clean and grease all parts.

  • Page 25: Oil And Grease

    TK, TMK ® GB-0309.2 6.3.4 Oil and grease 6.7 Reference to suitable spare parts Oil: TKG/TKB spreaders: Change gearbox oil before starting a new machine and before starting a new season (3 litres - ISO 68) Påfyldningsprop Oliestandsskrue Aftapningsprop Rubber base 8x210 (A), 12x210 (B) - See spare parts manual.

  • Page 26: Steel Chains

    TK, TMK epoke ® GB-0306.1 7.1.2 Steel chains Control at use Tested Inspection Date Signed Result Date Signed Chains should only be repaired and heat-treated by the original manufacturer or authorised workshops, see section 2.1.4.

  • Page 27: Dry Matter Container

    TK, TMK ® GB-0306.1 7.1.6 Dry matter container Control at use (Visual inspection) Tested Inspection Date Signed Result Date Signed • Visual checks should include checks for exterior damage, deformities, wear and tear and corrosion. • Implementing safety devices.

  • Page 28: Draw Bar

    TK, TMK epoke ® GB-0306.1 7.1.12 Draw bar Control at use Tested Inspection Date Signed Result Date Signed • TThe drawbar is adjustable in height. Important: When adjusting height, self-locking nuts must only be used once, i.e. always use new self-locking nuts. Nut (M14 DIN 985 A2) torque is 120 Nm.

  • Page 29: Tyre List

    TK, TMK ® GB-0612.2 7.1.20 Tyre list Machine type Identnr. Torque Size of tyre Profi le Epoke no. Air pressure at 50 moment km/h TKG12 1101 TKB9-280 1107 TKB12-280 1108 TK12E 1210 3.00-4” T-991 82251314 72.5 TK12E-275 1211 6.00-9”...

  • Page 30: Certificates Eu Certificate Of Conformity Tk

    ® DK-0612.2 8.1.1 TK...

  • Page 31: Eu Certificate Of Conformity Tmk

    ® DK-0612.2 8.1.2 TMK...

  • Page 32: Certificate Of Quality Management System

    The company has held the certificate since April 21, 1993, and it is applicable to the Epoke product range, including grass mowers, spreaders, sweepers, snow ploughs, which have all been subject to ISO 9001 testing.
